AUDAC SX408A User Manual & Installation Manual

Active subwoofer system

Advertisement

Quick Links

SX408A
AUDAC
PROFESSIONAL AUDIO EQUIPMENT
SX408A
Active Subwoofer System
User Manual &
Installation Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SX408A and is the answer not in the manual?

Questions and answers

Summary of Contents for AUDAC SX408A

  • Page 1: User Manual

    SX408A AUDAC PROFESSIONAL AUDIO EQUIPMENT SX408A Active Subwoofer System User Manual & Installation Guide...
  • Page 2 A U D A C P R O F E S S I O N A L A U D I O E Q U I P M E N T User Manual & Installation Guide  AUDAC http://www.audac.eu info@audac.eu...
  • Page 3: Table Of Contents

    BALANCED INPUT CONNECTIONS ....................................8 SATELLITE OUTPUT CONNECTIONS ....................................9 POWER SWITCH ..........................................10 MAINS POWER CONNECTION ......................................10 BLOCK DIAGRAM ..........................................11 SX408A SET SOLUTIONS ........................................12 FESTA 400 ............................................12 CONGRESS 400 ........................................... 13 ADDITIONAL INFORMATION ......................................14 PERSONAL NOTES..........................................15...
  • Page 4: Introduction

    RJ45 connector. This all makes the SX408A a simple but complete solution for a wide variation of fixed audio installations. The balanced input connections are just as the satellite speaker output connections made with euro block terminal connectors.
  • Page 5: Environment

    Chapter Environment Do not place this unit in an enclosed environment such as a bookshelf or closet. Ensure that there is adequate ventilation to cool the unit. Do not place the unit in environments which contain high levels of dust, heat, moisture or vibration.
  • Page 6: Safety Requirements

    Safety Requirements Always handle the unit with care. Only use a grounded socket outlet and a power cord with grounding plug to plug in the unit. This unit is not a toy. It should not be operated by children. Do not stick objects through the openings. Do not open the unit (risk for electrical shock).
  • Page 7: Overview Rear Panel

    Chapter Overview rear panel Amplifier indicator LED’s RJ45 Remote control connection Satellite outputs volume control Subwoofer volume control Balanced input connections Satellite output connections POWER switch MAINS power connection...
  • Page 8: Rear Panel Description

    This LED illuminates whenever there is a signal present at the input connectors. Clip LED: The SX408A has a built-in limiter that prevents the outputs from overdriving. When the Clip LED lights up frequently, the level must be reduced, because the maximum power is reached.
  • Page 9: Satellite Volume Control

    3) Satellite volume control With this dial, the output level of the satellite channels can be set. The attenuation of the signal can be set between 0dB and -50dB by rotating the dial. 4) Subwoofer volume control With this dial, the output level of the subwoofer channel can be set. The attenuation of the signal can be set between 0dB and -50dB by rotating the dial.
  • Page 10: Satellite Output Connections

    Balanced: Unbalanced: Shield Sleeve 6) Satellite output connections On these euro terminal output connections is the amplified output signal present with a frequency above 120Hz. Connect these to the satellite speakers. A total of 4 speakers with an impedance of 8 Ohm can be connected to these output connections. The total impedance load should not be lower than 4 Ohms.
  • Page 11: Power Switch

    The input connection is performed using IEC power connectors. The SX408A is factory default set to be used on 220 – 240 Volt AC mains networks. But it can be switched to be used on 110 – 120 Volt AC mains networks.
  • Page 12: Block Diagram

    Chapter Block Diagram...
  • Page 13: Sx408A Set Solutions

    FESTA 400 4 x WX502 + SX408A Make sure that the WX502 loudspeakers which will be used in combination with the SX408A are set to 8 Ohm impedance. This can be done by turning the power tap adjustment screw on the rear of the speaker to 8 Ohm.
  • Page 14: Congress 400

    These switches are meant to convert the speaker for use in 100V or low impedance applications. Set these switches to Low Impedance to be used in combination to the SX408A. After this is done, the speaker can be assembled again as it was originally.
  • Page 15: Additional Information

    Additional Information Crossover: Lowpass: -3dB 120Hz -6dB 146Hz -24dB/Oct Highpass: -3dB 110Hz -6dB 83Hz 12dB/Oct Input impedance: 30k Ohm single ended 30k Ohm balanced differential Sensitivity: 400 mV clip led on 570 mV max output signal Max input level : 1V limited by limiter Rated power: Sub: 100W 8 Ohm...
  • Page 16: Personal Notes

    Personal notes...
