Refrigerator Compartment
A. Fan and antibacterial and antiodour filter (depending
on the model)
B. Lamp or LED light (depending on the model)
C. Shelves
D. LED lights (depending on the model)
E. Crisper drawer cover
F. Crisper(s)
G. Rating plate (located at side of crisper)
H. Control panel
N. Dairy compartment
O. Door trays
P . Bottle holder (if provided)
Q. Bottle bin
Least cold zone
Intermediate zone
Coldest zone
Fruit and vegetable zone
Freezer Compartment
I. Top drawer (freezing area)
L. Middle and bottom drawers (storage area for frozen
and deep frozen food)
M. Ice cube tray (if provided)
Note: All shelves, door trays and racks are removable.
The ideal temperatures for preserving foods are already
factory-set.
Carefully read the user handbook provided before
using the appliance.
The characteristics, technical data and images may
vary according to the model.
DESCRIPTION OF PRODUCT
Fast Cool Function
Press the "Temperature" button for 3 seconds to cool the
refrigerator compartment quickly, or 6 hours before placing large
quantities of fresh food in the freezer compartment. When the
function is active, the yellow light is on and the three green lights
are off. This function is automatically deactivated after 30 hours, or
manually by pressing the button again for 3 seconds. When the
function is not active, the yellow light is off and the indication of the
set temperature is shown by the green lights.
Note: Do not place fresh food to be frozen in direct contact with
already frozen food.
On / Off
Press to activate/deactivate the appliance.
Note: This operation does not disconnect the
appliance from the power supply.
What to do if...
The appliance could be in off mode.
There may be an appliance power supply problem.
The control panel is switched off, the appliance does not work.
The inside light does not work.
The light may need replacing.
The temperature inside the compartments is not low enough.
There could be various causes (see "Cures")
There is water on the bottom of the refrigerator compartment. The defrost water drain is blocked.
The front edge of the appliance, at the door striker seal, is hot. This is not a defect It prevents condensation from forming.
Malfunction alarm
One or more indicator lights flash.
The alarm indicates a fault in a technical component.
D
GB
F
NL
E
P
I
GR
S
N
Fan (where provided)
The fan is factory set to ACTIVE.
The fan can be deactivated by pressing the
button on the base (as shown in the figure). If
the room temperature exceeds 27°C or if
water droplets form on the glass shelves, the
fan must be on in order to guarantee the
correct preservation of food. Deactivation of the fan enables energy
consumption to be optimised.
Possible causes:
DK
FIN
Refrigerator compartment temperature
The three green lights indicate the set refrigerator compartment
temperature.
A different temperature can be set using the "Temperature "
button.
The following adjustments are possible:
LED's on
Set temperature
High (least cold)
Medium-high
Intermediate
Medium-low
Low (coldest)
Cures:
Activate the appliance with the On/Off button
Make sure:
- there is not a power outage
- the plug is properly inserted in the power socket and the mains double-pole switch (if present) is in the correct position
(i.e. allows the appliance to be powered)
- the household electrical system protection devices are efficient
- the power cable is not broken.
Models with lamp: disconnect the appliance from the power supply, check the lamp and, if necessary, replace it with a
new one (see the section "Lamp or LED replacement").
Models with LED lights: contact the authorised Service Centre.
Make sure:
- the doors close properly
- the appliance is not installed near a heat source
- the set temperature is adequate
- the circulation of air through the vents at the bottom of the appliance is not obstructed
Clean the defrost water drain hole (see the section "Appliance Maintenance and Cleaning")
No remedy is necessary.
Call the authorised Service Centre.
The appliance continues to maintain minimum preservation conditions.
GB
5019 608 01100
