Summary of Contents for Central Machinery CENTRAL MACHINERY 92274
Page 1
Copyright 2004 by Harbor Freight Tools . All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. For technical questions, please call 1-800-444-3353.
When unpacking, check to make sure all the parts shown on the Parts Lists on page 13 are included. If any parts are missing or broken, please call Harbor Freight Tools at the number shown on the cover of this manual as soon as possible.
Keep your work area clean and well lit. Cluttered and dark work areas invite accidents. Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes.
Page 4
Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing, and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts. Avoid accidental starting. Be sure the circuit supplying electrical power is off before plugging in.
Use only accessories that are recommended by the manufacturer for your model. Accessories that may be suitable for one tool may become hazardous when used on another tool. Tool service must be performed only by qualified repair personnel. Service or maintenance performed by unqualified personnel could result in a risk of injury. When servicing a tool, use only identical replacement parts.
Page 6
Your tool must be plugged into an appropriate outlet, properly installed and grounded in accordance with all codes and ordinances. The plug and outlet should look like that in the following illustration. (See Figure A.) 3-PRONG PLUG 115 VOLT, GROUNDED, ELECTRICAL OUTLET FIGURE A SYMBOLOGY...
Maintain labels and nameplates on the Sump Pump. These carry important information. If unreadable or missing, contact Harbor Freight Tools for a replace- ment. Use the right product for the right job. There are certain applications for which this product was designed. Do not use small equipment, tools, or attach- ments to do the work of larger industrial equipment, tools, or attachments.
Page 8
Water transfers in cycles. Do not attempt to manipulate the automatic Switch (3) to keep the Sump Pump running continuously. It is meant to shut off intermittently. Doing so will damage the Pump. Make sure the discharge pipe (not included) is secured to a solid surface to ensure the stability of the Sump Pump.
Page 9
ASSEMBLY AND OPERATING INSTRUCTIONS NOTE: For additional information regarding the parts listed in the following pages, refer to the Assembly Diagram on page 14. If necessary, have a certified electrician install (within six feet of where the Sump Pump will be located) a 115 volt, grounded, electrical outlet that is dedicated only to the Pump.
Do not attempt to reduce the discharge size below 1-1/4” as this will affect Pump flow and performance. A Schedule 40 PVC 1-1/4” diameter Pipe is recom- mended. (See Figure D.) Connect the 1-1/4” diameter Discharge Pipe to the Impeller Case (22) of the Sump Pump.
Page 11
B. Water level in pit may be too low (Switch has not yet activated). Add more water to pit. C. Power Cord may not be making contact in electrical outlet. Check connec- tion. D. Float may be obstructed. Make sure the Float is free and not rubbing against the pit wall or other obstruction.
INSPECTION, MAINTENANCE, AND CLEANING WARNING! Make sure the Sump Pump is unplugged from its electrical outlet before performing any inspection, maintenance, or cleaning procedures. Before each use, inspect the general condition of the Sump Pump. Check for clogs throughout the system, misalignment or binding of moving parts, damaged electrical wiring, damaged or loose discharge pipes, and any other condition that may affect its safe operation.
Part # Description Power Cord Screw Switch Motor Rear Cover Star Washer Screw Capacitor Motor Enclosure Cable Clamp Float Rod Float Stator Bearing Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. SKU 92274 For technical questions, please call 1-800-444-3353.
ASSEMBLY DIAGRAM NOTE: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. SKU 92274 For technical questions, please call 1-800-444-3353. PAGE 14...
