TerraTec PHASE 24 FW Description

2 4 B i t / 1 9 2 k H z A u d i o S y s t e m
High end audio meets eye-catching design: The external FireWire™ system PHASE 24 FW!
The TerraTec PHASE 24 FW combines fine design and superior
specs. Regardless of whether you're using the PHASE 24 FW on
the move with your notebook or at home with your PC or Mac -
this versatile audio system cuts a fine figure in any situation.
Simply connect the high grade aluminium case to the FireWire™
port of your computer for fast, uncomplicated data exchange.
The required cables and adapters are included, of course. The
two analog mono inputs and outputs have been realized as
professional, balanced ¼" jacks - the studio standard simplifies
the connection of additional equipment. DJs, for example, can
create mixes on their laptops using applications such as the
included Native Instruments Traktor, add an external beatbox,
DESCRIPTION
insert effects between the PHASE 24 FW and the computer,
and control it all via a MIDI keyboard. The integrated digital
hardware mixer ensures that all this happens nearly without any
latencies at all. An additional stereo out can be used as a line out
or adjustable headphone output.
You always have complete control over brilliant, full sound -
thanks to 24 Bit/192 kHz signal processing and a signal-to-
noise ratio of 111 dB. The PHASE 24 FW unites proven hightech
with innovative ideas and exclusive design into a harmonious
whole. In the club or in the studio.
2 balanced analog inputs,
¼" (6.3 mm) jack
2 balanced analog outputs,
¼" (6.3 mm) jack
1 analog stereo output, ¼" (6.3 mm)
jack, usable as line out or adjustable
stereo output
24 Bit/192 kHz analog signal
processing
24 Bit/96 kHz kHz digital signal
processing
109 dB signal-to-noise ratio
(A-weighted) of the analog inputs
111 dB signal-to-noise ratio
(A-weighted) of the analog outputs
Digital hardware mixer
MIDI interface
