WIRELESS 868 MHz WEATHER STATION
Instruction Manual
INTRODUCTION:
Congratulations on purchasing this fancy Weather Station with wireless 868MHz
transmission of outdoor temperature and display of indoor temperature and humidity. It is
further acting as a DCF-77 radio controlled clock with calendar display and alarm clock
function. In addition, sunrise/ sunset/ sun duration time as well as the moon phase are
shown. With the totally 15 different weather forecast icons featured by "Weather girl", users
can easily observe the forecast weather condition and will no longer worry the sudden
weather change. This innovative product is ideal for use in the home or office.
« Instant Transmission+» is the up and coming state-of-the-art new wireless
transmission technology, exclusively designed and developed by LA CROSSE
TECHNOLOGY.
"IT +" offers you an immediate update of all your outdoor data measured from
the transmitters: follow your climatic variations in real-time!
49
