12 volt Jump-start
and power supply
set up and operating instructions
visit our website at: http://www.harborfreight.com
read this material before using this product.
Failure to do so can result in serious injury.
save this manual.
Copyright
2009 by Harbor Freight Tools
©
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
38391
. All rights reserved. No portion of this manual or any artwork
®
note: after purchase
and before initial use
of the Jump-start,
fully charge the Jump-
start battery until the
dc charging led
turns off.
after each jump start,
fully recharge the
battery until the dc
charging led turns
off.
Fully charge Jump-
start battery every 30
days to ensure long
battery life.

Advertising

   Also See for Chicago Electric CHICAGO ELECTRIC 38391

   Related Manuals for Chicago Electric CHICAGO ELECTRIC 38391

No related manuals

   Summary of Contents for Chicago Electric CHICAGO ELECTRIC 38391

  • Page 1

    Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improvements, actual product may differ slightly from the product described herein. Tools required for assembly and service may not be included.

  • Page 2: Specifications

    speciFications Start Amps Peak Amps Battery 12 V, Lead-Acid, Rechargeable Charging Current = 0.18A Booster Cables #4 Gauge, 17” Length Includes: 12 Volt Cigarette Lighter Charger, AC Adapter Receptacle, Built-in Light, Booster Cable Storage, Charge/Battery Indicators note: Charging performance of this tool (if charged by line voltage) may vary depending on variations in local line voltage.

  • Page 3

    10. stay alert. Watch what you are doing, use common sense. Do not operate any tool when you are tired. 11. check for damaged parts. Before using any tool, any part that appears damaged should be carefully checked to determine that it will operate properly and perform its intended function.

  • Page 4: Controls And Components, Charging

    controls and components Jump Start ON/OFF Work Test Clamp Light Meter Voltage Charging Receptacle Switch DC Charging Light Light Switch Figure 1 charging note: After purchase and before initial use, fully charge the Jump-Start battery until the DC charging LED turns off.

  • Page 5: Power Source

    note: The LED light will go on (when Switch is in the OFF position) to indicate a reverse polarity condition. 12 vdc charging note: This system is equipped with a 12 VDC Cigarette Lighter Adapter so you can charge the Jump-Start from a vehicle or boat battery.

  • Page 6

    If you use the Jump-Start with a power inverter (not included) as a 120 V~ power source, Table 3 will give you approximate times to expect with a fully charged unit. table 3 120 V~ Power Source Usage Times using a power inverter (not included) estimated appliance power...

  • Page 7: Battery Replacement

    Do not short terminals. Do not incinerate. Risk of electric shock; use only in dry location. Only use with battery packs distributed by Harbor Freight Tools; others may burst, causing personal injury and/or property damage. For additional information on battery recycling call 1-800-822-8837.

  • Page 8: Parts List And Assembly Drawing

    parts list and assembly drawing please read the Following careFully THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER NOR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.

  • Page 9

    90 day warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.

This manual also for:

38391
