Table of Contents

System Overview.................................................... 1
PINs (Personal ID Codes) .................................... 2
Code 2 ...................................................................... 2
Normal User ............................................................. 2
Maintenance Code.................................................... 2
Installer Code ........................................................... 3
Basic Touchpad Operation ................................... 4
Touchpad Buttons..................................................... 5
System Status Lights ................................................. 7
Access Control Operation ..................................... 9
Opening an Access Controlled Door........................ 9
7
Using the Anti-Passback Feature ....................... 9
7
7
Viewing Door Status......................................... 11
Single-Area Operation ......................................... 12
7
7
7
7
Activating Auto Arm ......................................... 14
7
Cancelling Auto Arm ........................................ 14
7
Bypassing Zones ............................................... 15
7
Unbypassing Zones........................................... 16
7
Activating/Deactivating Code 2........................ 17
7
Multi-Area Operation ............................................18
Personnel................................................................ 18
7
Arming/Disarming All Areas ............................ 19
7
Arming/Disarming a Specific Area................... 20
7
7
7
Activating Auto Arm ......................................... 22
7
Cancelling Auto Arm ........................................ 23
7
Bypassing Zones ............................................... 23
7
Unbypassing Zones........................................... 24
7
Activating/Deactivating Code 2........................ 25
7
Other Important Features.....................................27
7
7
Pressing the Emergency keys........................27
7
Setting System Time and Date............................30
Set Time .................................................................. 30
Set Date .................................................................. 30
Viewing System Status .......................................31
Pressing the STAT Button....................................... 31
i
