Page 1 ‫ﻣﺮﺑﻮﻃﻪ‬ ‫ﺭﺍﻫﻨﻤﺎﯼ‬ ‫ﺩﻓﺘﺮﭼﻪ‬ ‫ﺑﻪ‬ ،‫ﮐﺮﺩﻥ‬ ‫ﻣﺘﺼﻞ‬ ‫ﻭ‬ ‫ﻧﺼﺐ‬ ‫ﺑﺮﺍﯼ‬ Указания по установке и выполнению соединений приводятся в отдельной инструкции. INSTRUCTIONS ‫ﺍﻟﺘﻌﻠﻴﻤﺎﺕ‬ ‫ﺩﻟﻴﻞ‬ ИНСТРУКЦИИ ПО ЭКСПЛУАТАЦИИ ‫ﻫﺎ‬ ‫ﺩﺳﺘﻮﺭﺍﻟﻌﻤﻞ‬ GET0800-001A K EN, RU, TH, AR, PE © 2012 JVC KENWOOD Corporation 0212DTSSANJEIN...
Page 2 Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. IMPORTANT FOR LASER PRODUCTS 1. CLASS 1 LASER PRODUCT 2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit;...
Page 3: Table Of Contents
How to attach the control panel Contents Preparation ............4 Canceling the display demonstration Setting the clock Basic operations ........... 4 Radio ................ 6 How to detach the control panel CD/USB ..............8 Avoid touching the connectors. iPod/iPhone ............. 9 Quick Search ............
Page 4: Preparation
Preparation Preparation Canceling the display Setting the clock demonstration SET UP (Hold) The display demonstration is always turned on DEMO Clock unless you cancel it. 2 Select <Clock>. SET UP (Hold) DEMO Clock Clock DEMO Clock Color DEMO 3 Select <Set Clock>. (Initial setting) Clock Clock Display...
Page 5: Control Panel
Basic operations Control panel Remote controller Display window Flips down the panel Remote sensor Control dial Aim the remote controller directly at the sensor. DO NOT expose to bright sunlight. When you press or hold the following button(s)... Remote Control panel General function controller Turns on.
Page 6: Radio
Radio Radio Searching for a station Select <FM> or <AM>. Auto search. (Press) Manual search. (Hold) ST DYNAMIC 1:00AM “M” appears, then press the button repeatedly. 88.3 MHz “ST” lights up when receiving an FM stereo broadcast with sufficient signal strength. Auto presetting (FM only) Storing stations in memory SSM (Strong-station Sequential Memory)
Page 7: Setting The Radio Timer
Radio Setting the Radio Timer Naming the stations You can tune in to a preset station at a specific You can assign names for up to 30 station time regardless of the current source. frequencies (FM and AM) using a maximum of 8 characters for each name.
Page 8: Cd/Usb
CD/USB CD/USB Playing a CD/USB device Label side USB cable from the rear of the unit The source changes to “CD” and playback starts. The source changes to “USB” and playback starts. This unit can play MP3/WMA files stored in CD-R, CD-RW, and MP3/WMA/WAV files in USB mass storage device (such as a USB memory and Digital Audio Player).
Page 9: Ipod/Iphone
“Album” is not applicable for some iPod/ iPhone. Applicable under <Headunit Mode> only. iPod/iPhone application You can operate JVC original application with this unit in <Application Mode>. For more details, visit JVC website: <http://www3.jvckenwood.com/ english/car/index.html> (English website only). ENGLISH |...
Page 10: Quick Search
Quick Search Quick Search If you have many folders/tracks/contacts, you can search through them quickly according to the first character (A to Z, 0 to 9 and OTHERS). 1 Enter list menu or “Hands-Free” menu. CD (MP3/WMA)/ iPod/iPhone Bluetooth phonebook USB (MP3/WMA/WAV) Select the desired list.
Page 11: Bluetooth Connection
USB cable from the rear of the unit KS-UBT1 2 Search and select “JVC Unit” on the Bluetooth device. For some Bluetooth devices, you may need to enter the Personal Identification Number (PIN) code immediately after searching. ENGLISH |...
Page 12: Connecting/Disconnecting Registered Device Manually
Bluetooth connection 3 Perform (A) or (B) depending on what appears on the display. For some Bluetooth devices, pairing sequence may vary from the steps described below Pairing? Pairing? Pairing? Pairing? Yes: Press VOL Yes: Press VOL Device: [Device name] Device: [Device name] No: Press BACK No: Press BACK...
Page 13: Bluetooth Mobile Phone
Connecting to JVC original Deleting a registered device application (Hold) JVC original application is designed to view JVC car receiver status and perform simple control operations on Android smart phones. 2 Select <Delete OK>. For JVC original application operations, visit JVC <Bluetooth>...
Page 14 Bluetooth mobile phone Adjustments during a call Text message notification Phone volume (00 — 50) When a text message is received, the unit rings [Volume 15]: Volume and “[Device Name]” “Received Message” adjustments made during a call appears. will not affect the other <Message Notice>...
Page 15: Using Voice Recognition
Bluetooth mobile phone Using voice recognition Deleting a contact (name/ phone number) You can use the voice recognition features of the connected phone through this unit. Only when <Phonebook Select> is set to <In “Not Support” appears if the connected phone Unit>.
Page 16: Using The Settings Menu
Bluetooth mobile phone Using the Settings menu 3 Repeat this step to perform the necessary 1 Enter the “Hands-Free” menu. settings. 2 Select <Settings>. To return to the previous menu, press To exit from the menu, press MENU. The following settings are applicable to the paired device. If another device is paired, perform the settings again.
Page 17: Bluetooth Audio Player
Bluetooth audio player Bluetooth audio player Playing a Bluetooth audio player Select <BT-1> or <BT-2> depending on the location of the USB Bluetooth adapter KS-UBT1. Operate the Bluetooth audio player to start playback. Operations and display indications may differ according to their availability on the connected device. Basic operations Selecting the playback modes Starts or resumes playback.
Page 18: Illumination Color Adjustments
Illumination color adjustments Button zone All zone: Includes both Button zone and Display zone Display zone. All zone Selecting the preset color Storing your own adjustments You can select a preset color for <Button Zone>, You can store your own day and night colors for <Display Zone>, and <All Zone>...
Page 19: Brightness Adjustments
Brightness adjustments Brightness adjustments You can select your preferred brightness for <Button Zone>, <Display Zone> separately. (Hold) <Dimmer> Button Zone Level 00 to 31 <Brightness> Display Zone Level 00 to 31 <Day Brightness>/ <Night Brightness> 4 Press MENU to exit. Sound adjustments This unit memorizes sound settings adjusted for each individual source.
Page 20: Menu Operations
Menu operations Menu operations 3 Repeat step 2 if necessary. (Hold) To return to the previous menu, press To exit from the menu, press DISP or MENU. If no operation is done for about 60 seconds, the operation will be canceled. Menu item Selectable setting (Initial: [XX]) DEMO...
Page 21 Menu operations Menu item Selectable setting (Initial: [XX]) Fad/Bal *4*5 R6 — F6 [0]: Press to adjust the front and rear speaker output balance. L6 — R6 [0]: Press to adjust the left and right speaker output balance. Loud On: Boosts low and high frequencies to produce a well-balanced sound at a (Loudness) low volume level.
Page 22 Information Connected Phone/Connected Audio/Connected Application *11: Displays connected phone/audio/application device name. My BT Name: Displays the unit name (JVC Unit). My Address: Shows address of USB Bluetooth Adapter. AM Source *12 [Show]/Hide: Enables or disables “AM” in source selection.
Page 23: Remote Controller
Remote controller Remote controller Warning: Preparing Do not install any battery other than CR2025 or When you use the remote controller for the first its equivalent. time, pull out the insulation sheet. Do not leave the remote controller in places (such as dashboards) exposed to direct sunlight for a long time.
Page 24 Additional information About audio files About USB device Playable files Unplayable files Cautions “ ” File/folder names Others | ENGLISH...
Page 25 Additional information About iPod/iPhone About Bluetooth < > Trademark and license notice < > < > “ ” < > ENGLISH |...
Page 26: Troubleshooting
Troubleshooting Troubleshooting Symptom Remedy/Cause General “ ” “ ” < > FM/AM CD/USB/iPod/iPhone “ ” “ ” “ ” “ ” “ ” “ ” < > | ENGLISH...
Page 27 Troubleshooting Symptom Remedy/Cause Bluetooth “ ” “ ” < > < > “ ” < > < > DISP “ ” “ ” “ ” “ ” “ ” “ ” “ ” “ ” “ ” “ ” “ ”...
Page 28: Specifications
Specifications Specifications AUDIO AMPLIFIER SECTION TUNER SECTION CD PLAYER SECTION USB SECTION BLUETOOTH SECTION | ENGLISH...
Page 29 Specifications GENERAL Having TROUBLE with operation? Please reset your unit. Refer to page of How to reset your unit. ENGLISH |...
Page 30: Руcckий
ВАЖНО ДЛЯ ЛАЗЕРНОЙ АППАРАТУРЫ ПРЕДУПРЕЖДЕНИЕ: ПРЕДУПРЕЖДЕНИЕ: Предупреждение: Предостережение: Предостережение, касающееся настройки громкости: Температура внутри автомобиля: Конденсация: | РУCCKИЙ...
Page 31 Подключение панели управления Cодержание Подготовка ............4 Отмена демонстрации функций дисплея Настройка часов Основные операции ........4 Отсоединение панели управления Радио ............... 6 Избегайте контакта с разъемами. CD/USB ..............8 iPod/iPhone ............9 Быстрый поиск ..........10 Внешние компоненты ........10 Соединение...
Page 32 Подготовка Подготовка Отмена демонстрации Настройка часов функций дисплея SET UP (Удерживать) DEMO Clock SET UP 2 Выберите <Clock>. (Удерживать) DEMO Clock Clock DEMO Clock Color DEMO 3 Выберите <Set Clock>. (Начальная настройка) Clock Clock Display Set Clock 3 Выберите <Off>. 24/12H DEMO 4 Установите...
Page 33 Панель управления Пульт дистанционного Открывает управления Окно дисплея панель Телеметрический датчик Диск управления Направьте пульт дистанционного управления на датчик. НЕ подвергайте его воздействию прямых солнечных лучей. “ ” РУCCKИЙ |...
Page 34 Bыберите <FM> или <AM>. Автоматический поиск. (нажмите) Ручной поиск. (Удерживать) ST DYNAMIC 1:00AM “ ” 88.3 MHz “ ” (Удерживать) (Удерживать) < > “ ” < > Выбор запрограммированного номера. < > “ ” “ ” | РУCCKИЙ...
Page 35 (Удерживать) Bыберите <FM> или <AM>. < > < > < > < > Войдите в меню “Введение имени”. < > (Удерживать) (Удерживать) Введите желаемое название. Переместите Выберите запрограммированную Выберите радиостанцию. < > < > < > < > < > < > Установите...
Page 36 Сторона с ярлыком Кабель USB, идущий от задней панели устройства или “ ” “ ” (Удерживать) < > < > Выберите папку. (Для MP3/WMA/WAV) Выберите дорожку. * Для MP3/WMA/WAV | РУCCKИЙ...
Page 37 Выберите желаемый список. Кабель USB, идущий от задней панели устройства Выберите необходимую дорожку. или Кабель USB 2.0 (не входит в комплект поставки)* “ ” < > (Удерживать) < > < > < > (Удерживать) < > < > < > “...
Page 38 Войдите в меню списка или меню “Hands-Free”. < > Выберите желаемый символ (от A до Z, Выберите желаемую папку/дорожку/ от 0 до 9 и OTHERS). контакт. “ ” Подключите к кабелю AUX, который выходит из задней панели устройства. Выберите <AUX IN>. Портативный...
Page 39 “ ” KS-UBT1 Микрофон Подключите USB-адаптер Bluetooth (KS-UBT1) к одному из входных USB- Кабель USB, разъемов. идущий от задней панели устройства KS-UBT1 или Найдите и выберите “JVC Unit” на устройстве Bluetooth. РУCCKИЙ |...
Page 40 Выполните (A) или (B), в зависимости от того, что отображается на дисплее. Pairing? Pairing? Pairing? Pairing? Yes: Press VOL Yes: Press VOL Device: [Имя устройства] Device: [Имя устройства] No: Press BACK No: Press BACK Passkey: XXXXXX “ ” (1) Когда устройство Bluetooth предложит...
Page 41 (Удерживать) Выберите <Delete OK>. < > < > < > (Удерживать) “ ” Нажмите , чтобы выйти. Выберите <Connect>. < > < > < > Выберите желаемый смартфон. “ ” “ ” Нажмите , чтобы выйти. “ ” “ ” (Удерживать) или...
Page 42 “ ” “ ” < > < > “ ” “ ” “ ” “ ” Войдите в меню “Hands-Free”. Выберите способ звонка. Выберите контакт и позвоните ему (имя/номера телефона). Выберите имя/номер телефона Вызов “ ” “ ” “ ” <...
Page 43 С помощью этого изделия вы можете Только когда для <Phonebook Select> использовать функции распознавания голоса установлено <In Unit>. ( стр. 16) подключенного телефона. Войдите в меню “Hands-Free”. Если подключенный телефон не поддерживает эту функцию, появляется надпись “Not Support”. Войдите в режим распознавания голоса. Выберите...
Page 44 Повторите данное действие для Войдите в меню “Hands-Free”. осуществления необходимых настроек. Выберите <Settings>. < > “ ” “ ” * Выбор возможен, только когда подключенный телефон поддерживает профиль PBAP. | РУCCKИЙ...
Page 45 Выберите <BT-1> или <BT-2> в зависимости от расположения адаптера USB Bluetooth KS-UBT1. (Удерживать) < > < > РУCCKИЙ |...
Page 46 Зона кнопок Зона дисплея Общая зона < > < > < > < > < > (Удерживать) (Удерживать) Выберите <Color Setup>. Выберите <Color>. < > * Цвет изменяется с различной скоростью. < > < > < > Нажмите , чтобы выйти. “...
Page 47 < > < > (Удерживать) < > < > < > < > Нажмите , чтобы выйти. (Удерживать) < > < > < > < > Нажмите , чтобы отрегулировать частоту. Нажмите , чтобы отрегулировать угловой коэффициент Q. Настройте уровень. (Удерживать) Выберите...
Page 48 (Удерживать)
Page 51 Изоляционный материал CR2025 “ ” “ ” РУCCKИЙ |...
Page 52 “ ” “ ” “ ” “ ” | РУCCKИЙ...
Page 53 < > < > < > “ ” < > РУCCKИЙ |...
Page 54 “ ” “ ” < > “ ” “ ” “ ” “ ” “ ” “ ” < > | РУCCKИЙ...
Page 55 “ ” < > < > “ ” “ ” < > < > “ ” “ ” “ ” “ ” “ ” “ ” “ ” “ ” “ ” “ ” “ ” “ ” РУCCKИЙ |...
Page 56 | РУCCKИЙ...
Page 57 РУCCKИЙ |...
Page 60 Clock DEMO Clock Color Clock Clock Display Set Clock 24/12H DEMO Set Clock 1 : 00AM...
Page 61 แผงควบคุ ม รี โ มทคอนโทรล...
Page 62 ST DYNAMIC 1:00AM 88.3 MHz...
Page 67 KS-UBT1...
Page 68 Pairing? Pairing? Pairing? Pairing? Yes: Press VOL Yes: Press VOL Device: Device: No: Press BACK No: Press BACK Passkey: XXXXXX...
Page 79 CR2025...
Page 87 ..........................iPhone iPod ............
Page 88 < . Clock > < . Set Clock > < . > < . 24H/12H > < . 12Hours > < 24Hours > “ ”...
Page 89 ‫ﻟﻮﺣﺔ ﺍﻟﺘﺤﻜﻢ‬ ‫ﻭﺣﺪﺓ ﺍﻟﺘﺤﻜﻢ ﻋﻦ ﺑﻌﺪ‬ “ ”...
Page 90 < . > < > ST DYNAMIC 1:00AM “ ” 88.3 MHz “ ” < > < > “ ” < > “ ” “ ”...
Page 91 < . > < > < > < > “ ” < > < > < > < > < > < > < > < > < > “ ” < > < >...
Page 92 “ ” “ ” < > < >...
Page 93 “ ” < > < > < > < > < > < > < > “ ” < > < > “ ” < > “ ” “ ” “ ” < > < >...
Page 94 “ ” < > OTHERS “ ” < . AUX IN >...
Page 95 “ ” KS-UBT1 KS-UBT1 KS-UBT1 “ JVC Unit ”...
Page 96 Pairing? Pairing? Pairing? Pairing? Yes: Press VOL Yes: Press VOL Device: [‫]ﺍﺳﻢ ﺍﻟﺠﻬﺎﺯ‬ Device: [‫]ﺍﺳﻢ ﺍﻟﺠﻬﺎﺯ‬ No: Press BACK No: Press BACK Passkey: XXXXXX “ ” “ ” “ ” “ Pairing ” “ ” “ ” ” “ “ ”...
Page 97 < . Delete OK > < > < > < > “ ” < . Connect > < > < > < > “ ” “ ” “ ” “ ” “ ” < > < >...
Page 98 ” “ ” “ < > < > “ ” “ ” “ ” “ ” “ ” “ ” “ ” < > “ ” < >...
Page 99 < > < > “ ” “ ” < > < > < > < > “ ” “ ” ] “ Waiting Voice ” “ ” < . Delete All > < Delete >...
Page 100 “ ” < . Settings > < > “ ” “ ” PBAP...
Page 101 < BT-2 > < BT-1 > KS-UBT1 < > < >...
Page 102 < > < > < > < > < > < . Color Setup > < . Color > > < < > < > < > “ ” “ ” < >...
Page 103 < > < > < > < > < > < > < > < > < > < > Treble Middle Bass Sub. W < > < . > < Subwoofer On/Off > < >...
Page 104 < > < > “ ” < . Dimmer Auto > < . Dimmer Set >...
Page 105 “ ” “ ” “ ” “ ” “ ” “ ” < . > < Subwoofer On/Off >...
Page 106 “ ” “ ” “ ” “ . USB-2 USB-1 ” “ . iPod-2 iPod-1 ” “ Please Connect BT Adapter ” < Connect > “ . AUX Source AM Source ” “ . BT-2 BT-1 ” KS-UBT1...
Page 107 CR2025 “ ” “ ”...
Page 108 “ ”...
Page 109 < > < > < > “ ” < >...
Page 110 “ ” “ ” < > “ ” “ ” “ ” “ ” “ ” “ ” < >...
Page 111 < > < > “ ” “ ” “ ” < > < > “ ” “ ” “ ” “ ” “ ” “ ” “ ” “ ” “ ” “ ” “ ” “ ”...
Page 115 ..........................iPhone iPod ..........Bluetooth ..........Bluetooth ........ Bluetooth...
Page 116 < Clock > < Set Clock > < > < 24H/12H > < 12Hours > < 24Hours > “ ”...
Page 117 ‫ﭘﺎﻧﻞ ﮐﻨﺘﺮﻝ‬ ‫ﺩﺳﺘﮕﺎه ﻛﻨﺘﺮﻝ ﺍﺯ ﺭﺍه ﺩﻭﺭ‬ “ ”...
Page 118 < > < > ST DYNAMIC 1:00AM “ ” 88.3 MHz “ ” < > < > < > “ ” “ ” “ ”...
Page 119 < > < > < > “ ” < > < > < > < > < > < > < > < > < > < > “ ” < > < >...
Page 120 “ ” “ ” < > < > “ ”...
Page 121 “ ” “ ” < > < > < > < > < > < > “ ” < > “ ” < > < > < > “ ” “ ” “ ” < > < >...
Page 122 “ ” < > OTHERS “ ” < AUX IN >...
Page 123 ” “ KS-UBT1 KS-UBT1 KS-UBT1 “ JVC Unit ”...
Page 124 Pairing? Pairing? Pairing? Pairing? Yes: Press VOL Yes: Press VOL Device: [‫]ﻧﺎﻡ ﺩﺳﺘﮕﺎه‬ Device: [‫]ﻧﺎﻡ ﺩﺳﺘﮕﺎه‬ No: Press BACK No: Press BACK Passkey: XXXXXX “ ” Bluetooth “ 0000 ” Bluetooth Bluetooth “ ” “ Pairing ” Bluetooth “ ” Bluetooth “...
Page 125 < Delete OK > < > < > < > “ ” < Connect > < > < > < > “ ” “ ” “ ” “ ” “ ” < > < >...
Page 126 ” “ ” “ < > < > “ ” “ ” “ ” “ ” “ ” “ ” “ ” “ ” “ ” < > < >...
Page 127 < > < > “ ” “ ” < > < > < > < > “ ” “ ” ] “ Waiting Voice ” “ ” < Delete All > < Delete >...
Page 128 “ ” < Settings > < > “ ” “ ” PBAP...
Page 129 KS-UBT1 < BT-2 > < BT-1 > < > < >...
Page 130 < > < > < > < > < > < Color Setup > < Color > < > < > “ ” < > “ ” < > < >...
Page 131 < > < > < > < > < > < > < > < > < > < > Q-slope Bass Sub. W Treble Middle < > < Subwoofer On/Off > < > < >...
Page 132 < > < > “ ” < Dimmer Auto > < Dimmer Set >...
Page 133 “ ” “ ” “ ” “ ” “ ” < > < Subwoofer On/Off >...
Page 134 “ ” “ ” “ ” “ USB-2 USB-1 ” “ iPod-2 iPod-1 ” “ Please Connect BT Adapter ” USB Bluetooth < Connect > Bluetooth Bluetooth “ AUX Source AM Source ” BT-1 ” KS-UBT1 “ BT-2...
Page 135 CR2025 “ ” “ ”...
Page 136 “ ”...
Page 137 < > < > < > “ ” < >...
Page 138 “ ” “ ” < > “ ” “ ” “ ” “ ” “ ” “ ” < >...
Page 139 < > < > “ ” “ ” “ ” < > < > “ ” “ ” “ ” “ ” “ ” “ ” “ ” “ ” “ ” “ ” “ ” “ ”...
