Contents Features....................2 For your Attention................3 Package Contents................4 Panel....................5 Remote Control................6-7 Remote Control Function..............8-9 Connections................10-11 System Setup................12-17 Basic Playback................18-19 Troubleshooting................20 Specifications..................21...
Features Thanks for your purchase of our product. Please read through this manual before making connections and operating this product. Retain this manual for future reference. DVD player is a domestic video player of new generation which produces high quality pictures and Hi-Fi audio effect. Its performance is much better than that of any previous home video equipment.
For Your Attention IMPORTANT NOTES Please read through this manual before making connections and operating this product. Retain this manual for future reference. Don't open the cabinet of this unit. No user-serviceable parts inside. Refer servicing to qualified personnel only. Switch off the unit when you don't use it.
Package Contents Package Contents User manual Remote control A/V cable Playable Disc and Media Types: Disc types Symbol Contents Audio + Video Audio Video-CD Audio + Video Audio CD-DA Picture CD JPEG Photo CD DVD REGION CODES: DVD discs and players are covered by a worldwide agreement which limits playback of DVD discs to specific regions as determined by the software manufacturer.
Remote control Remote Control Operation Insert two AAA/1.5V batteries into the remote control. Point the remote control at the remote sensor on the front panel. The remote control works within a distance of about 7 metres from the sensor and within an angle of about 30 degrees from the left and right side.
Page 8
Remote control 16. OPEN/CLOSE( ) 1. STANDBY/ON 2. DIGIT KEYS 17. REPEAT 3. FAST REWIND( 18. A-B REPEAT /FAST FORWARD( 19. VOLUME+/- 4. PLAY( 20. GOTO Ñ ¡ Ê ± 5. STOP( 21. PREVIOUS( ¿ ì Í Ë ¿ ì ½ ø Ç...
Remote control Function STANDBY/ON Press to switch on the unit. Press it again to put the unit in standby mode. Press repeatedly to select a TV type, NTSC, PAL or MULTI. OPEN/CLOSE Press to open /close the disc tray. The digit keys can be used to input numbers or make selection of a track or a chapter, etc.
Page 10
Remote control Function SLOW Press repeatedly for slow-motion playback in different speeds. The available speeds are 1/2, 1/4, 1/8, 1/16 of the normal speed. Press [ ] to resume the normal playback. (Note: Applies to DVD, VCD discs, etc.) REPEAT Press repeatedly to switch the repeat modes.
Connections Connections Connections Connections Connections Connections Connections Connections Connections Connections VIDEO SYSTEM CONNECTION VIDEO SYSTEM CONNECTION VIDEO SYSTEM CONNECTION VIDEO SYSTEM CONNECTION VIDEO SYSTEM CONNECTION VIDEO SYSTEM CONNECTION VIDEO SYSTEM CONNECTION VIDEO SYSTEM CONNECTION VIDEO SYSTEM CONNECTION VIDEO SYSTEM CONNECTION The following video outputs are available for this unit.
Page 12
Connections Connections Connections Connections Connections Connections Connections Connections Connections Connections AUDIO SYSTEM CONNECTION AUDIO SYSTEM CONNECTION AUDIO SYSTEM CONNECTION AUDIO SYSTEM CONNECTION AUDIO SYSTEM CONNECTION AUDIO SYSTEM CONNECTION AUDIO SYSTEM CONNECTION AUDIO SYSTEM CONNECTION AUDIO SYSTEM CONNECTION AUDIO SYSTEM CONNECTION There are two types of audio output systems.
System Setup Menu Operation 1. Press [SETUP] on the remote control to show the setup menu. 2. Press [ ]/[ ] to select an item. The submenu of the selected item will be displayed below instantly. 3. Press [ ]/[ ] to select an item you desire to set in the submenu, then press [ENTER] / [ ]to enter.
System Setup 1.6 LAST MEMORY ON: During a playback or in the paused/stopped status each time you open the disc tray or turn off the player, the unit will memorize the last playback time. Next time when you insert the same disc and close the disc tray to load the disc, the unit will play from the memorized point.
System Setup 2.3 DOLBY DIGITAL SETUP 2.3.1 DUAL MONO STEREO: The player outputs the left-channel audio and right-channel audio via the FL and FR speaker respectively. L-MONO: The player outputs the left-channel audio only via both the FL and FR speaker. R- MONO: The player outputs the right-channel audio only via both the FL and FR speaker.
System Setup 2.6 3D PROCESSING 3D processing provides a virtual surround sound experience using just two speakers. 2.6.1 PRO LOGIC II Pro Logic II: This unit allows you to configure Dolby Pro Logic II to expand 2-channel source audio into full 5.1-channel surround sound. NOTE: Pro Logic II functionality is effective only when DOWNMIX is set to 5.1CH and DIGITAL OUTPUT is set to SPDIF RAW.
System Setup 2.7 HDCD(High Definition Compatible digital) HDCD (High Definition Compatible digital) is a patented encode/decode process for delivering the full richness and details of the sound from HDCD-encoded CDs. 2.7.1 FILTER You can select the digital filter at 2x, 1x or off. 2.8 KARAOKE SETUP 2.8.1 MIC SETUP 2.8.1.1 MIC...
Page 18
System Setup NTSC: If the connected TV is NTSC system , select this mode. The video signal of a PAL disc will be output in NTSC format. NOTE: If a wrong selection is made, the viewing image will be very poor. In such case, you are supposed to change the option in this item to fix the error.
Basic Playback MP3 DISC PLAYBACK Insert an MP3 disc into the player, then a content menu will display on the screen. MENU OPERATION: Use the direction key [ ]/[ ] to select a folder or a file, then press [ENTER] to enter the selected folder or play the selected file.
Basic Playback PICTURE CD PLAYBACK Place a picture CD in the disc tray, then the unit will load the disc automatically(the maximum size of the picture should be less than 8900*8900 pixels). Press [ ] to enter the thumbnail mode to preview the pictures. In the thumbnail mode, use the direction keys to select a picture, then press [ENTER] to start the playback from the selected picture.
Troubleshooting Before resorting to maintenance service, please kindly check by yourself with the following chart. Symptom Cause(s) Remedy No Power Please check that the AC power cord The AC power cord is not connected to the is connected securely. power supply or is not connected to a power supply securely.
Specifications AC~100-240V,50-60Hz Power supply Less than 20W Power consumption PAL /NTSC TV system DVD: 650nm Laser wave length 780nm 180 W Laser power output DVD: 4Hz~22kHz 48kHz PCM 4Hz~ 44kHz 9 6kHz PCM Audio frequency range 4Hz~20kHz 80dB S/N ratio Audio dynamic range 90dB Operating conditions...
