- Page 1 For further details contact Music Hall LLC: 108 Station Road Great Neck, NY 11023 T: 516.487.3663 F: 516.773.3891 W: http://www.musichallaudio.com...
- Page 2 50.2 integrated amplifier integrated amplifier user manual user manual vo lu m e in p u t n it o r re c. m o p h o n e s ip o d p lif ie r p lif ie r g ra te d am g ra te d am 5 0 .2 in te...
-
Page 3: Safety Guidelines
3. Object or liquid entry Do not allow foreign objects or liquids into the unit. If this happens, immediately disconnect the power cord from the wall and take the unit to an authorized music hall service center for inspection. 4. Ventilation You must allow 2 inches (5 cm.) of unobstructed clearance around the unit. -
Page 4: Power Sources
integrated amplifier integrated amplifier 5. Heat Keep the unit away from naked flames, radiators, heat registers, stoves, or any other heat- producing appliances (including amplifiers). 6. Climate The unit has been designed for use in moderate climates. Do not attempt to use below 41 degrees Fahrenheit (5 degrees Celsius) or above 95 degrees Fahrenheit (35 degrees Celsius). -
Page 5: Getting Started
Indicates high-voltage power inside the unit, which will cause electric shock. Getting Started Thank you for purchasing the music hall a50.2. The a50.2 is a classic two-channel integrated amplifier designed for the music lover. We chose a select group of technologically advanced components to create this powerful 90 watt/channel integrated amplifier. -
Page 6: A Few Precautions
Ensure that there is adequate ventilation around all sides of the unit. Avoid placing the a50.2 where it may be subject to excessive heat, such as near a heat register. Do not place anything on top of it. For best performance, avoid placing the a50.2 where it may be subject to vibration, such as near a speaker. -
Page 7: Speaker Out
Connect your source components to the appropriate inputs on back of the a50.2. Pay careful attention to match the right (red) and left (black) outputs from your source components to the right (red) and left (black) inputs on the a50.2. Connect to the ipod input on the front using a 3.5mm stereo mini-plug. - Page 8 50.2 integrated amplifier 50.2 integrated amplifier power - on/off Push this button on the front of the a50.2 to turn the unit . When the a50.2 is the display will show the input that is currently selected and the volume level. Pushing it again will switch the a50.2...
-
Page 9: Using The Remote Control
TUNER INPUT use. The supplied remote control is a standard system remote and therefore not all buttons will function with the a50.2. The remote controls the a50.2, cd25.2, REP / REP / SCAN and t25.2. For information on using the remote control with the cd25.2 or... - Page 10 integrated amplifier integrated amplifier Technical Specification Amplifier Maximal power output (no distortion): ............... 90W/8 Minimal impedance: ....................2 S/N: ........................ 101dB Frequency Response: ..............10Hz - 60KHz 0.5dB Distortion (THD+N): ................<0.002 (1KHz) Input Sensitivity: ................230mV CD-IN/47K Crosstalk Attenuation: ................... 73dB/1KHz Phones Output Level: .................
- Page 11 Guarantee This entitles you to have the music hall a50.2 repaired or replaced, at our discretion, free of charge for one year after purchase, at any authorized music hall dealer, provided the unit was purchased from an authorized dealer. Your original sales receipt is used as proof of purchase date.
