Samsung SCC-520N User Manual

Digital Color Dome Camera
SCC-520N/520P
User's guide
Overview
CCTV COLOR DOME CAMERA SCC-520N/520P is the monitoring
camera incorporated with the recent CCD that provides the best
monitoring function in connection with the CCTV system equipment.
Number of CCD pixels
• SCC-520N : 270,000 pixels
• SCC-520P : 320,000 pixels
Power supply
• SCC-520N :
DC 12V
• SCC-520P :
Automatic function and special function
• ATW
• ELC(Electronic shutter iris)
Component Name
Fixed focus lens
PCB board
Main body
Dome cover
Power cable
Video cable
Function of Each Component
Fixed focus lens
• Fixed focus lens installed on the camera.
Please take cautions that any dust or foreign matter gathers
on the front glass surface of the lens.
Main body
• A body that supports the camera.
PCB board
• This part is quite important since it performs the camera
function.
Please handle with care.
Power cable
• The terminal that is connected to the power (adaptor) cable.
Connect to DC 12V.
Video signal output cable
• The cable that sends the video signal.
Dome cover
• The transparent plastic cover that protects the camera.
Be careful not to make a scratch on it.
ELECTRONICS
Printed In Korea
AB68-00140A
