Polaroid TTM-2420 User Manual

24" pure flat tube stereo tv

Advertisement

Quick Links

Important Safety Precautions

CAUTION
Risk of electric shock, do not open.
Do not attempt to service this product yourself as opening or
removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service personnel;
WARNING
1. To reduce the risk of fire or electric
shock, do not expose this product to
rain or moisture.
The apparatus shall not be exposed
to dripping or splashing and that no
objects filled with liquids, such as
vases, shall be placed on the appa-
ratus;
4. The ventilation should not be impeded
by covering the ventilation opening
with items, such as newspapers,
table-cloths, curtains, etc.
NOTE
1. For your protection, please read this
instruction completely, and keep this
manual for future reference;
3. The apparatus is not suitable for chil-
dren under 3-year to operate.
High Voltage, Do not open.
2. To avoid the fire, no naked flame
source, such as lighted candles,
should be placed on the apparatus;
3. At least 10 cm space should be left
around the apparatus for sufficient
ventilation;
10cm
5. In case of smoke, strange noise or
strange smell from the unit, switch it
off, unplug it from the wall outlet and
contact your dealer or service cen-
ter.
2. Unplug the apparatus from the AC
outlet when it will not be used for a
long period of time. And when there
is a lightning, unplug the unit from the
AC outlet immediately. Never touch
the antenna wire during lightning.
i

Advertisement

Table of Contents
loading

Summary of Contents for Polaroid TTM-2420

  • Page 1: Important Safety Precautions

    Important Safety Precautions CAUTION High Voltage, Do not open. Risk of electric shock, do not open. Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel; WARNING 1.
  • Page 2 Important Safety Precautions 4. Do not push objects of any kind 5. Do not place this apparatus near water, into this apparatus through cabinet for example, near a bath tub, wash bowl, slots as they could touch current kitchen sink, or laundry tub, in a wet carrying parts or short-circuit parts basement, a swimming pool, and the resulting in fire, electric shock or...
  • Page 3: Table Of Contents

    Polaroid. Add a little color to your life. Since 1937, America has turned to Polaroid for their photography needs. Today, families look to Polaroid for consumer electronics that define the digital age: plasma and LCD TVs, portable and standard DVD players, digital cameras.
  • Page 4: Overview

    IR RECEIVER WINDOW POWER SWITCH POWER INDICATOR Note: Buttons for SA-U series TV may have different position for different models, but the same button has same function. Figure mentioned above is for model TTM-2420.
  • Page 5 VIDEO INPUT AUDIO INPUT HEADPHONE OUTPUT JACK Note: Side AV and headphone jacks may have different position for different models,but the same jack has same function. Figure mentioned above is for model TTM-2420.
  • Page 6: External Connection

    External connection Antenna connection The antenna input impedance used in this model is 75ohm, just connect 75ohm coaxial cable of VHF/UHF antenna to the antenna jack on the back of TV directely. If you use 300 flat feeder, you need connect it with one 300 /75ohm converter first, then connect the converter into the antenna jack.
  • Page 7 Connect to video equipment (VCD, DVD) and headphone jack Connect back AV jacks as the following figure shown: S-terminal has the same AUDIO IN jack as AV1, but you can not input AV signal from these two terminals at the same time. YUV has the same AUDIO IN jack as AV2, but you can not input AV signal from these two terminals at the same time.
  • Page 8: Remote Control

    Remote Control Remote Control POWER ON/STANDBY MUTE MUTE ON/ OFF DIGITAL, LETTER INPUT BUTTONS DISPLAY PRE.CH SLEEP BROWES CLEAR TV/AV PROG. PROGRAM UP/ MAIN MENU MENU SELECT VOLUME UP/MENU VALUE UP MENU VOLUME DOWN/MENU VALUE DOWN PROGRAM DOWN/MENU SELECT PROG. SOUND STEREO GAME...
  • Page 9 Remote Control Remote control DISPLAY Displays channel information. PRE.CH Returns you to the previous channel.If the user is in the menu system,Go Back will take the user to the previous menu screen. BROWSE “Browse”feature.Pressing the button twice will begin channel scan,again will stop at current channel. SLEEP Set the sleep timer.
  • Page 10: Basic Operation

    Basic Operation Overview Connect to the Mains Insert the mains wire plug of the unit into AC 120V mains outlet. Power on/off When you press the POWER switch button to standby or turn on TV. Note: The power indicator will turn into red when TV is under standby state. The power indicator will die when TV is under turn on state.
  • Page 11 Basic Operation Overview Sound modes Press S.STD button on the remote control to select sound modes (MEMORY—- STANDARD—NEWS—MUSIC), MEMORY status is the sound mode you have ad- justed. Calendar Press CALENDAR button to display the screen as the figure shown: The calendar of these series models provide you searching the solar calendar and current week from January 1, 1900 to December 31, 2049.
  • Page 12: Menu Basic Operation

    Menu Basic Operation Menu Basic Operation 1. To enter the menu, press MENU button in front of the TV (or on the remote control), press MENU button in front of TV (or on the remote control) again to select the icon.
  • Page 13: Using The Sound Menu

    Using the PICTURE menu Using the PICTURE Menu SHARPNESS Adjust left/right to soften/sharpen the picture detail. Adjust range: (00~63). TINT Adjust the balance between the red and green levels. Adjust range: (-31~+31). COLOR TEMP Automatic color adjustments. Provide three states: (NORMAL, WARM, COLD).
  • Page 14: Using The Preset Menu

    Using the SOUND menu Using the SOUND Menu BASS Adjust left/right to decease/increase low pitched sound. Adjust range: (00~63). BALANCE Adjust left/right to emphasize left/right speaker balances. Adjust range: (-31~+31). SURROUND Adjust different kinds of the surround sound effect. Provide two states(OFF, ON).
  • Page 15: Using The Function Menu

    Using the PRESET Menu Using the PRESET menu SOURCE Let you select AIR or CABLE. Select AIR to receive radio broadcast signal. Select CABLE to receive CATV signal. provide two states:(AIR,CABLE) Available audio modes, provide four states: BTSC (AUTO, MONO, STEREO, SAP). Optional item.
  • Page 16 Using the FUNCTION Menu Eight closed captioned modes including four text modes. Provide nine states: (OFF,C1,C2,C3,C4,T1.T2,T3,T4). V-CHIP Press VOL button in front of TV (or VOL button on the remote control) to see the figure below. Figure CONFIRM PASSWORD: Press four digital buttons on the remote control. V-CHIP menu can not be displayed without inputting the right password.
  • Page 17 V-CHIP Adjust V-CHIP funtion on or off,Provide two states: (ON, OFF). MPAA Press VOL or VOL buttons on the remote control to Select the MPAA ratings. When you select a movie rating, the system will auto- matically block all movies with higher ratings. No Rating Provided Directed at Older Children TVPG SETTING...
  • Page 18: Picture Defects And Countermeasures (Air Reception)

    Using the FUNCTION Menu Eight closed captioned modes including four text modes. Provide nine states: (OFF,C1,C2,C3,C4,T1.T2,T3,T4). V-CHIP Press VOL button in front of TV (or VOL button on the remote control) to see the figure below. Figure CONFIRM PASSWORD: Press four digital buttons on the remote control. V-CHIP menu can not be displayed without inputting the right password.
  • Page 19: Troubleshooting

    Troubleshooting If you have any problem, check the countermeasures for each symptom listed below. The following symptoms may have been caused by inappropriate adjustments rather than actual malfunction of the unit. If the trouble persists, contact the service center.
  • Page 20 PRINTED IN Printed on Recycled Paper RECYCLED PAPER 604-L20H33-02...
  • Page 21 24" Pure Flat Tube Stereo TV TTM-2420 20051212...
