Pioneer CD-R5 Owner's Manual

Remote control for DVD-VIDEO
Télécommande pour DVD-VIDEO
Owner's Manual
Mode d'emploi
CD-R5
PIONEER CORPORATION
4-1, MEGURO 1-CHOME, MEGURO-KU, TOKYO 153-8654, JAPAN
PIONEER ELECTRONICS (USA) INC.
P.O. Box 1540, Long Beach, California 90801-1540, U.S.A.
TEL: (800) 421-1404
PIONEER EUROPE N.V.
Haven 1087, Keetberglaan 1, B-9120 Melsele, Belgium
TEL: (0) 3/570.05.11
PIONEER ELECTRONICS ASIACENTRE PTE. LTD.
253 Alexandra Road, #04-01, Singapore 159936
TEL: 65-6472-7555
PIONEER ELECTRONICS AUSTRALIA PTY. LTD.
178-184 Boundary Road, Braeside, Victoria 3195, Australia
TEL: (03) 9586-6300
PIONEER ELECTRONICS OF CANADA, INC.
300 Allstate Parkway, Markham, Ontario L3R OP2, Canada
TEL: 1-877-283-5901
PIONEER ELECTRONICS DE MEXICO, S.A. de C.V.
Blvd.Manuel Arila Camacho 138 10 piso
Col.Lomas de Chapultepec, Mexico, D.F. 11000
TEL: 55-9178-4270
Published by Pioneer Corporation.
Copyright © 2004 by Pioneer Corporation.
All rights reserved.
Publication de Pioneer Corporation.
Copyright © 2004 Pioneer Corporation.
Tous droits de reproduction et de traduction
réservés.
Printed in Japan
Imprimé au Japon
<KSNZX> <05C00000> <CZR5026-A> E
Before you start
Setting the remote control code
Information to User
type
Alteration or modifications carried out with-
When the remote control operation mode switch
out appropriate authorization may invalidate
is set to DVD, changing the remote control code
the user's right to operate the equipment.
type enables you to operate the Pioneer DVD
player with this remote control. There are three
This device complies with part 15 of the FCC
remote codes, code type A, code type B and
Rules. Operation is subject to the following
code type AVH.
two conditions:
(1) This device may not cause harmful inter- To operate a multi-DVD player
ference, and (2) this device must accept any
When operating a multi-DVD player (e.g.
interference received, including interference
XDV-P9II), select code A.
that may cause undesired operation.
To operate a DVD navigation unit
When operating a DVD navigation unit,
select code B.
Using the remote control
To operate an AV-Receiver
operation mode switch
When operating an AV-Receiver (e.g. AVH-
There are three remote control operation modes
P5700DVD), select code AVH.
on this remote control.
1 Set the remote control code selection
AVH mode operation
switch on the left side of the remote control to
the appropriate position with a pen tip or other
When operating an AV-Receiver (e.g. AVH-
pointed instrument.
P5700DVD) with this remote control, remote
control operation mode switch is normally
• If you select AVH mode, there is no need to
switched to AVH.
take the following procedure.
DVD mode operation • If you select A/B mode, take the following
When operating a Pioneer DVD player with this procedure and change the code type to the
remote control, operation mode switch is nor-
appropriate type.
mally switched to DVD. If you switch the remote
2 Press and on the remote control simul-
control operation mode switch to DVD, the
taneously to change the code type.
joystick and – operations are changed for
DVD player. Initially, the code type is set to A. Each time you
press and simultaneously on the remote
TV mode operation
control the code type switches between A and
When operating a Pioneer TV tuner (e.g. GEX-
B.
P5700TV(P) or GEX-P5750TV(P)) with this remote
control, operation mode switch is normally
switched to TV. If you switch the remote control
operation mode switch to TV, the joystick opera-
tion is changed for TV tuner.
Before you start
Installing the battery
CAUTION
Slide the tray out on the back of the remote con-
• Use only one CR2025 (3V) lithium battery.
trol and insert the battery with the plus (+) and
• Remove the battery if the remote controller is
minus (–) poles pointing in the proper direction.
not used for a month or longer.
• When using for the first time, pull out the film
• Do not recharge, disassemble, heat or dispose
protruding from the tray.
of the battery in fire.
• Do not handle the battery with metallic tools.
• Do not store the battery with metallic materi-
als.
• In the event of battery leakage, wipe the
remote control completely clean and install a
new battery.
Battery holder
• When disposing of used batteries, please
comply with governmental regulations or envi-
ronmental public institution's rules that apply
(+) pole
in your country/area.
• Always check carefully that you are loading
battery with its (+) and (–) poles facing in the
proper directions.
• Do not leave this unit free inside the car. When
the car stops or turns a curve, the unit might
drop on the floor. If the unit is rolled and put
WARNING
under the brake pedal, it might prevent the
• Keep the battery out of the reach of children.
driver from braking well, causing a serious
Should the battery be swallowed, immediately
trouble.
consult a doctor.
• Do not disassemble or modify this unit. To do
so may cause a fault.
• The volume of the car stereo should be so
adjusted that you can hear a loud sound
occurring outside your car. If any happening
sound outside your car is deafened by music
from the car stereo when you are driving, this
condition can be a factor of being involved in a
traffic accident.
Before you start
Using the remote control
Point the remote control in the direction of the
front panel to operate.
• The remote control may not function properly
in direct sunlight.
Precaution
• Do not store the remote control in high tem-
peratures or direct sunlight.
• Do not let the remote control fall onto the floor,
where it may become jammed under the brake
or accelerator pedals.
Specifications
Power source ...................... 3 V DC
(Lithium Battery: CR2025)
Dimensions (W × H × D): .... 52 × 123 × 11 mm
Weight ................................. 50 g (including battery)
Infered Remote Control
<Wavelength> .................. 945 nm
<Output> .......................... typ; 10 mw/sr per infrared
LED
Note
• Specifications and the design are subject to
possible modification without notice due to
improvements.
