Pioneer ELITE PRO-620HD Operation Instruction Manual

Elite hdtv projection monitor
Hide thumbs Also See for ELITE PRO-620HD:
Table of Contents

Advertisement

Quick Links

See also: Service Manual
HDTV PROJECTION MONITOR
PRO-720HD
PRO-620HD
PRO-520HD
Operating Instructions

Advertisement

Table of Contents
loading

Related Manuals for Pioneer ELITE PRO-620HD

Summary of Contents for Pioneer ELITE PRO-620HD

  • Page 1 HDTV PROJECTION MONITOR PRO-720HD PRO-620HD PRO-520HD Operating Instructions...
  • Page 2 Progressive An advanced and exclusive I/P (Interlace/Progressive) format Connection to a DVD player with a component output terminal converter developed by Pioneer, called “PureCinema”, delivers makes possible high picture-quality display, superior to that a high-resolution progressive picture. It reproduces film of S-VIDEO terminal connection.
  • Page 3 Thank you for purchasing this PIONEER HDTV Projection Monitor. Please read the precautionary instructions enclosed with these operating instructions please do so before proceeding. After learning how to operate the Projection Monitor, be sure to keep this manual handy for future reference.
  • Page 4 The following symbols are found in this WARNING manual and on the labels on the product. This symbol refers to a hazard or unsafe They alert the operators and service practice which can result in severe personal personnel of this equipment to potentially injury or death.
  • Page 5 Do not subject your Monitor to 11-1. Do not place this Monitor on an impact of any kind. Be particularly unstable, uneven or an inclined careful not to damage the screen location. The Monitor may surface. overturn, causing serious injury (to a person), and serious damage Unplug the Monitor from the wall to the appliance.
  • Page 6 An outdoor antenna system For added protection during a should not be located in the lightning storm, or when it is left vicinity of overhead power lines/ unattended and unused for long electric lights or power circuits, or periods of time, unplug the where it can fall onto such power Monitor from the wall outlet and lines or circuits.

  • Page 7: Table Of Contents

    CONTENTS INTRODUCTION HOW TO USE THESE OPERATING INSTRUCTIONS ..... 8 INSTALLING THE MONITOR ............9 BASIC OPERATIONS BEFORE USE ................12 CONNECTING THE ANTENNA ........... 14 CONNECTING VIDEO/AUDIO EQUIPMENT ........ 16 FRONT PANEL FUNCTIONS ............20 REMOTE CONTROL UNIT FUNCTIONS ........22 TO WATCH TV ................

  • Page 8: How To Use These Operating Instructions

    HOW TO USE THESE OPERATING INSTRUCTIONS The following page is an example of the way that basic operating instructions are shown in this manual. The explanation method varies from page to page. AUTO CHANNEL PRESET Explanation of the function on this page.

  • Page 9: Installing The Monitor

    • Handle the screen with care to avoid scratches or damages. • While the Projection Monitor is operating, it is cooled by • Ask your dealer or a Pioneer authorized service center to airflow through ventilation holes in the rear and bottom.
  • Page 10 INSTALLING THE MONITOR HOW TO ATTACH THE PROVIDED PROTECTIVE SCREEN WE RECOMMEND ATTACHING THE PROTECTIVE SCREEN BEFORE USING THE MONITOR. To improve the image reproduction characteristics of the HOW TO ATTACH THE PROTECTIVE SCREEN monitor and to protect the screen from damage or dust, attach 1.
  • Page 11 INSTALLING THE MONITOR 3. While holding the screen in place, attach the upper panel 5. Attach the remaining frame covers to the upper and lower frame to the screen and fasten five or three screws starting panel frames: first, insert the edge of the frame cover into with the center screw.

  • Page 12: Before Use

    BEFORE USE Before you watch the TV, perform the following procedure. Connect the cables of the VHF antenna and UHF antenna to the ANTENNA A terminal. (See pages 14 and 15) Mixer ANTENNA /CABLE Connect the CATV converter to the ANTENNA B terminal. (See pages 14 and 15) CATV converter...
  • Page 13 BEFORE USE Inserting batteries into the remote control unit CAUTION Incorrect use of batteries may lead to leakage or rupture. Always be sure to follow these instructions. Never mix new and used batteries. Batteries of the same size may have different voltages ®...

  • Page 14: Connecting The Antenna

    CONNECTING THE ANTENNA • A good color picture depends on a good TV signal. So does Connect the TV signal source to your Monitor properly. good multichannel (stereo program and SAP) sound. Ask Use a 75-ohm coaxial cable with an F-type connector and your dealer for advice on how to install your external antenna connect the cable as shown in the illustration.
  • Page 15 CONNECTING THE ANTENNA Connecting the CATV converter with VCR ANTENNA /CABLE Cable TV Splitter CATV converter ANTENNA Connecting VHF/UHF antenna and CATV converter VHF antenna UHF antenna ANTENNA /CABLE U/V mixer Cable TV CATV converter...

  • Page 16: Connecting Video/Audio Equipment

    CONNECTING VIDEO/AUDIO EQUIPMENT DVD/LD player ◊B√¿≥??ÙÛ ◊B√¿≥??ÙÛ Video movie, etc. SAT tuner Digital tuner • Refer to the instructions of your VCR or DVD/LD player for • Only the INPUT 1 and INPUT 2 jacks can input the component the detailed connections. video signal.
  • Page 17 CONNECTING VIDEO/AUDIO EQUIPMENT SIGNAL DVD/LD player OUTPUT AUDIO VIDEO S-VIDEO SIGNAL SIGNAL The video output can be connected to BNC or to RCA types. ANTENNA /CABLE INPUTS INPUT 1 INPUT 2 INPUT 3 SIGNAL OUTPUTS INPUT S-VIDEO MONITOR CENTER VIDEO AUDIO S-VIDEO/VIDEO (MONO)
  • Page 18 CONNECTING VIDEO/AUDIO EQUIPMENT Front panel S-VIDEO VIDEO L-AUDIO-R (MONO) VIDEO S-VIDEO OUTPUT INPUT 4 Video movie/VCR INPUT jacks COMPONENT VIDEO INPUT jack There are 4 sets of inputs for VCR and DVD/LD players. Use Inputs three signals – Y, P ) and P ) –...
  • Page 19 CONNECTING VIDEO/AUDIO EQUIPMENT ANTENNA /CABLE INPUTS INPUT 1 INPUT 2 INPUT 3 OUTPUTS INPUT S-VIDEO MONITOR CENTER VIDEO AUDIO S-VIDEO/VIDEO (MONO) INPUT 3 SELECT AUDIO AUDIO FIXED/VAR COMPONENT INPUTS VIDEO OUTPUT INPUT 1 VIDEO S-VIDEO/VIDEO INPUT 3 SELECT CONTROL INPUT INPUT 3 Do not connect to INPUT 1 BNC and INPUT 1 RCA simultaneously.

  • Page 20: Front Panel Functions

    FRONT PANEL FUNCTIONS 1 POWER STANDBY/ON indicators A flip-down door conceals the INPUT 4 jacks. Push gently and release, to open the door. To close the door, lift it back up into red: STANDBY place. green: ON NOTE: 2 ROOM LIGHT SENSOR (RLS) If you accidentally pull the door, it may not shut properly.
  • Page 21 SPEAKER: NORMAL treatment, immediately unplug the power cord and call your AUDIO OUT: FIXED nearest PIONEER-authorized service center. SYSTEM MODE: • When this button is pressed while adjusting the MULTI- NOTES: • On rare occasions, an electrical discharge may occur inside the POINT convergence, the MULTI-POINT convergence returns to the initial mode.

  • Page 22: Remote Control Unit Functions

    REMOTE CONTROL UNIT FUNCTIONS Set the mode switch to TV. TV Power button (STANDBY/ON) Mode switch Turns the power of the monitor on and off. 2 INPUT Selector buttons (TV, INPUT 1 to INPUT 4) Press the button to select the source you wish to watch. TV CBL The screen will display your selection.
  • Page 23 REMOTE CONTROL UNIT FUNCTIONS 0 SPLIT/SEARCH screen buttons SPLIT: Press to turn the SPLIT screen function on and off. SEARCH: Press to select the SEARCH screen mode. SELECT: Selects the screen for switching the channel or input source.* FREEZE: When this button is pressed with the regular screen, the screen will change to the SPLIT screen and the picture at the time the button was pressed will become the sub-picture,...

  • Page 24: To Watch Tv

    TO WATCH TV Best Horizontal and Vertical Viewing Angle • The optimum viewing angle is 140˚ in horizontal and 45˚ in vertical. • Watch from at least 10 feet (3m) away from the screen (optimum viewing distance is 10 to 45˚...
  • Page 25 TO WATCH TV VHF L VHF H SUPER HYPER 7-13 14-69 A-5(95) A(14) J(23) Q(30) W+1(37) W+11(47) W+21(57) W+31(67) W+41(77) W+51(87) W+61(102) W+71(112) W+81(122) A-4(96) B(15) K(24) R(31) W+2(38) W+12(48) W+22(58) W+32(68) W+42(78) W+52(88) W+62(103) W+72(113) W+82(123) A-3(97) C(16) L(25) S(32) W+3(39) W+13(49) W+23(59)

  • Page 26: Checking The Menu

    CHECKING THE MENU Press MENU on the remote control unit. EDIT/ TV/SAT/DVD DTV/DVD TOP The MAIN MENU will be displayed on the screen. LEARN MENU MENU SOURCE Select the desired menu item using 5 or ∞ button of the remote DTV/SAT GUIDE POWER...
  • Page 27 CHECKING THE MENU SCREEN setting menu (See page 42) PICTURE SOUND SCREEN SCREEN C N EMA W I D E SET UP V . P O S I T I O N : – 1 0 SET/ SET/ ENTER ENTER ∞...

  • Page 28: Auto Channel Preset

    AUTO CHANNEL PRESET The broadcast frequencies that can be received depend on your area. Memorize the broadcast stations that can be received in your area in the presets. Select TV. TV CBL /SAT /DTV POWER Press MENU and select SET UP by using INPUT the 5 or ∞...
  • Page 29 AUTO CHANNEL PRESET Select TV/CABLE MODE , then select the broadcast system to be received from AIR, CATV STD, CATV HRC or CATV IRC. • Ask your dealer or cable service station for the mode of your local CATV system. TV CBL /SAT /DTV...

  • Page 30: Convergence Adjustment

    CONVERGENCE ADJUSTMENT Before convergence adjustment* , please choose a stabilized input signal* order to display a stable cross pattern. *1 Convergence adjustment ..Color deviation adjustment *2 Stabilized input signal ..Examples, DVD player, digital tuner, etc. Due to the differing magnetic fields in different locations, you may experience color deviation, that is inaccurate colors.
  • Page 31 CONVERGENCE ADJUSTMENT Move the red line onto the green line. Move the vertical line. O N V E R G E N C E SET/ TV CBL ENTER /SAT /DTV POWER ∞ INPUT USE: MENU SPLIT SEARCH SELECT Move the horizontal line. SCREEN SUB CH MODE...

  • Page 32: Program Block (V. Chip) Function

    PROGRAM BLOCK (V. CHIP) FUNCTION Since laws have been passed in the United States requiring a way of blocking undesirable programming, the V-chip has become a required component in television sets. The V-chip is a computer chip which decodes signals added to broadcast signals transmitted by television broadcasters.
  • Page 33 PROGRAM BLOCK (V. CHIP) FUNCTION <CANADIAN RATING SYSTEM> CANADIAN ENGLISH LANGUAGE RATING SYSTEM RATING Children Children 8 years and older General programming, suitable for all audiences Age-Base Parental Guidance Viewers 14 years and older Adult Programming Programming interned for children under age 8 Careful attention is paid to themes, which could threaten children's sense of security and well-being.
  • Page 34 PROGRAM BLOCK (V. CHIP) FUNCTION SETTING THE PROGRAM BLOCKING LEVEL Press MENU and select SET UP by using the 5 or ∞ button and then pressing SET/ TV CBL /SAT /DTV ENTER. (Refer to page 26.) POWER INPUT Select PROGRAM BLOCK in the same SPLIT SEARCH SELECT...

  • Page 35: Mpaa Rating

    PROGRAM BLOCK (V. CHIP) FUNCTION Set BLOCK to ON. SET UP P R O G R AM B L O C K B L O C K : O N O F F R A T I N G S Y S T EM SET/ SET/ ENTER...
  • Page 36 PROGRAM BLOCK (V. CHIP) FUNCTION Select and confirm the rank of the TV PARENTAL GUIDELINES. SET UP P A R E N T A L G U I D E L I N E S T V – Y – –...
  • Page 37 PROGRAM BLOCK (V. CHIP) FUNCTION Select and then confirm the rank of the FRENCH RATING. SET UP C A N A I D A N E N C H V I E V I E TV CBL SET/ SET/ /SAT 1 3 + V I E ENTER...
  • Page 38 PROGRAM BLOCK (V. CHIP) FUNCTION HOW TO REMOVE BLOCKING REMOVING BLOCKING IN FROM A PROGRAM IN PROGRESS MULTI-SCREEN MODE • If you choose a program that has a rating higher than your Just as in normal single-screen mode, programs are program blocking rating, the picture and sound will cut off blocked in SEARCH screen mode (see pages 43 and 44), and an enter password screen will appear.

  • Page 39: Changing Password

    CHANGING PASSWORD A password must be entered to turn program blocking on and off. The default password is '1234', but it is strongly recommended that you change the password. Press MENU and select SET UP by using the 5 or ∞ button and then pressing SET/ TV CBL /SAT /DTV...
  • Page 40 CHANGING PASSWORD Enter new password. • Press numeric buttons ‘ 0’ through ‘ 9’ to enter a four-digit password and press the SET/ENTER button. SET UP C H A N G E P A S SWO R D TV CBL /SAT /DTV P R E S S N UME R I...

  • Page 41: Changing Screen Size

    CHANGING SCREEN SIZE SETTING SCREEN MODE Different source material have specific screen modes they should use. Some films are mode in Vista some in cinemascope etc. check video/DVD packaging for info. Regular TV program are 4:3, so 4:3 is the standard mode.
  • Page 42 CHANGING SCREEN SIZE TO ADJUST THE SCREEN POSITION When the screen size is CINEMA WIDE or ZOOM, you can adjust the screen position by pushing the 5 or ∞ button. Press MENU and select SCREEN by using the 5 or ∞ button and then pressing SET/ TV CBL /SAT /DTV...

  • Page 43: Multi-Screen Function

    MULTI-SCREEN FUNCTION VIEWING TWO SCREENS (SPLIT screen) The screen can be split vertically, making it possible to view different images on the left and right. • The screen on which is displayed is the main picture, and the other screen is the sub-picture. Sound will be output for the main picture. •...
  • Page 44 MULTI-SCREEN FUNCTION SEARCHING FOR A PROGRAM ON A DIFFERENT CHANNEL (SEARCH screen) The screen on the right side can be made into nine or three different screens, making it possible to search for programs or enjoy multiple images. TV CBL /SAT Press the SEARCH button.

  • Page 45: Closed Caption Decode Function

    CLOSED CAPTION DECODE FUNCTION Closed caption broadcasting (character Press MENU and select CC by using the information) in the video signal allows the displaying of characters on the screen. This unit 5 or ∞ button and then pressing SET/ has a closed caption decoder which allows, these titles to be displayed when receiving these ENTER.

  • Page 46: Changing Channel Set Up

    CHANGING CHANNEL SET UP TO ADD OR DELETE PRESET CHANNELS Broadcast stations preset by auto channel preset which are unnecessary can be deleted. Broadcast stations you want to watch that were not preset by auto channel preset can be preset. You can add a name to a channel that has been added.
  • Page 47 CHANGING CHANNEL SET UP Select CHANNEL , then select a channel. SET UP C H A N N E L A D D / D E L A N T E N A : A C H A N N E L : 1 2 5 SET/ S E T T I N : D...
  • Page 48 CHANGING CHANNEL SET UP Select LABEL and input the letters for the name you want to call this channel. • When adding a channel, a label of 4 characters can be input for the added channel. TV CBL SET UP /SAT C H A N N E L A D D / D E L...
  • Page 49 CHANGING CHANNEL SET UP FAVORITE CHANNEL SET UP Assigning your favorite channels to the four buttons (blue, green, red and yellow) on the remote control unit makes it easy to call them up. Four channels can be assigned to each button, making it possible to set a total of 16 channels.
  • Page 50 CHANGING CHANNEL SET UP Select number. SET UP F A V O R I H A N N E L Y E L L OW A N T SET/ SET/ ENTER ENTER TV CBL /SAT /DTV ∞ POWER E X I T USE: END: MENU...

  • Page 51: Picture Adjustments

    PICTURE ADJUSTMENTS This device has three types of picture quality settings in memory. You can choose one from them or set the picture quality you desire and store it in memory. RECALL THE DESIRED SETTINGS TV CBL /SAT Press MENU and select PICTURE by /DTV POWER using the 5 or ∞...
  • Page 52 PICTURE ADJUSTMENTS STORING THE SET PICTURE QUALITY IN MEMORY USER mode can be set for each input source: TV and INPUT 1 to INPUT 4. TV CBL /SAT Select the input source and show the /DTV POWER image on the screen. INPUT SPLIT SEARCH...
  • Page 53 PICTURE ADJUSTMENTS TO ADJUST THE PICTURE QUALITY Adjust the picture quality when you want improve the quality of the picture you are watching. You can adjust the CONTRAST, BLACK LVL (brightness), COLOR, TINT and SHARPNESS. CONTRAST ..Adjusting the contrast to match the brightness of the surroundings so it is easier to watch.
  • Page 54 PICTURE ADJUSTMENTS OTHER PICTURE QUALITY ADJUSTMENTS The following six fine adjustments are available. 1 3D Y/C LEVEL ..Perform this adjustment when noises appear at the color borders of the image. 2 3D NR LEVEL ..Reduces the noise level of the luminance and chrominance signals when there is S-VIDEO input.
  • Page 55 PICTURE ADJUSTMENTS Select 3D Y/C LEVEL . PICTURE 3 D Y / C E V E L 3 D N R L E V E L : C O L O R T EMP : S T D SET/ F L E S H T O N E : SET/ ENTER ENTER...
  • Page 56 PICTURE ADJUSTMENTS 3 To adjust COLOR TEMP This function enables the image to be set to five different tones. Select COLOR TEMP . PICTURE 3 D Y / C E V E L 3 TV CBL 3 D N R L E V E L : /SAT /DTV C O L O R T EMP :...
  • Page 57 PICTURE ADJUSTMENTS 5 To adjust PURECINEMA This function automatically detects movie film recorded at 24 frames per second, and converts it into a high quality 30 frames per second delivering the picture at the same rate as it was recorded. NOTE: This function cannot be used when 1080i or 480p component signals or RGB signal input.
  • Page 58 PICTURE ADJUSTMENTS 7 To adjust Scan Velocity Modulation (SVM) Screen contour definition can be selected as desired. NOTE: This function cannot be used when SCREEN MODE is 4:3 NORMAL or PICTURE MODE is GAME. TV CBL /SAT /DTV Select SVM . POWER INPUT PICTURE...

  • Page 59: Sound Adjustments

    SOUND ADJUSTMENTS WATCHING STEREO AND BILINGUAL PROGRAMS The multichannel TV sound (MTS) decoder enables stereo program and Second Audio Program (SAP) to be received. (SAP is often used for a second language). This MTS decoder can only be used if a broadcast of stereo program or SAP is received.
  • Page 60 SOUND ADJUSTMENTS TO ADJUST THE SOUND QUALITY BASS, TREBLE and BALANCE can be adjusted. Press MENU and select SOUND . (Refer to page 26.) TV CBL /SAT /DTV POWER INPUT Select the adjustment item. SPLIT SEARCH SELECT SCREEN SUB CH SOUND MODE FREEZE...
  • Page 61 SOUND ADJUSTMENTS TO SELECT THE DESIRED SURROUND MODE This function creates the sound with a sense of presence. In a concert hall or in a theater, you hear a mixture of sound coming directly to you (direct sound) and sound that reaches you with a slight delay after being reflected from the walls (indirect sound).
  • Page 62 SOUND ADJUSTMENTS TO ADJUST SUPER BASS Use this function to enjoy powerful bass sounds. Press MENU and select SOUND . (Refer to page 26.) TV CBL /SAT /DTV POWER INPUT Select SUPER BASS . SPLIT SEARCH SELECT SCREEN SUB CH SOUND MODE FREEZE...

  • Page 63: Rls Function

    RLS FUNCTION The monitor has a sensor that automatically adjusts the black level, contrast and color of the screen in accordance with the light in the room. This is called the RLS (Room Light Sensor). You can adjust the RLS to react to a greater or lesser extent to the light in the room.

  • Page 64: Multi-Point Convergence Adjustment

    MULTI-POINT CONVERGENCE ADJUSTMENT Before convergence adjustment* , please choose a stabilized input signal* order to display a stable cross pattern. *1 Convergence adjustment ..Color deviation adjustment *2 Stabilized input signal ..Examples, DVD player, digital tuner, etc. Convergence adjustment may be fined-tuned here. Press MENU and select SET UP by using TV CBL /SAT...
  • Page 65 MULTI-POINT CONVERGENCE ADJUSTMENT Adjust the blue line. SET/ SET/ ENTER ENTER TV CBL /SAT /DTV ∞ MU L T I - P O I N T POWER : N E X T P O I N T INPUT USE: END: MENU SPLIT •...

  • Page 66: Connection With Receiver (1)

    CONNECTION WITH RECEIVER (1) The audio signal output from this unit can be reproduced on • Before making or changing connections, set the power the receiver when this monitor is connected to the receiver. switch to off and unplug the power cord from the AC outlet. When this monitor is connected to the CENTER OUT terminal •...
  • Page 67 CONNECTION WITH RECEIVER (1) SPEAKER and AUDIO OUT settings Press MENU and select SET UP by using the 5 or ∞ button and then pressing SET/ ENTER. (Refer to page 26.) TV CBL /SAT /DTV POWER INPUT Select SYSTEM IN/OUT in the same way. SPLIT SEARCH SELECT...
  • Page 68 CONNECTION WITH RECEIVER (1) Select AUDIO OUT . • If the speaker mode was set to CENTER IN in step 4, the AUDIO OUT mode will automatically change to FIXED, and VAR cannot be selected. SET UP TV CBL S Y S T EM I N / /SAT /DTV S P E A K E R :...

  • Page 69: Connection With Receiver (2)

    CONNECTION WITH RECEIVER (2) This unit can be used as the monitor for the receiver when this • Before making or changing connections, set the power unit is connected to the receiver. When this unit is connected switch to off and unplug the power cord from the AC outlet. to the CENTER OUT terminal of the receiver, the speaker of •...
  • Page 70 CONNECTION WITH RECEIVER (2) SYSTEM MODE setting Press MENU and select SET UP . (Refer to page 26.) TV CBL /SAT /DTV POWER Select SYSTEM IN/OUT . INPUT SET UP SPLIT SEARCH SELECT C H A N N E L S E SCREEN SUB CH C O N V E R G E N C...

  • Page 71: Connecting The System Remote Control

    CONTROL CONTROL NOTES: • When the Pioneer unit with Î mark is connected to the CONTROL IN terminal of the projection monitor, the remote sensor of the projection monitor does not accept signals from the remote control unit. In this case, point the remote control at the this unit in the chain (the equipment with no CONTROL IN connection).

  • Page 72: Remote Code Set Up

    • If the table on page 71 does not include your desired manufacturer or the remote control code does not work, you can make the memory learn its code by the learning mode (see page 74). • The initial code is “00” (PIONEER).
  • Page 73 REMOTE CODE SET UP Manufacturer's preset remote control codes CBL/SAT/DTV DVD/LD PIONEER 1 (CABLE) PIONEER PIONEER (DVD) PIONEER 2 (CABLE) FISHER PANASONIC (DVD) JERROLD 1 (CABLE) FISHER SAMSUNG (DVD) JERROLD 2 (CABLE) FISHER SONY (DVD) JERROLD 3 (CABLE) GOLD STAR...
  • Page 74 REMOTE CODE SET UP TO LEARN REMOTE CONTROL CODES To operate other manufacturers' remote control codes not preset using the remote control unit, have the remote control unit learn these signals. Example) To learn the VCR power to turn on. Before operation: TV CBL /SAT...
  • Page 75 REMOTE CODE SET UP • Buttons which can be learnt are as follows. Face the remote control unit of the other CABLE ..SOURCE POWER, CH (+), CH ( – ) , CH RETURN, CH ENTER, 1 to 9, 0 manufacturer's and the remote control SAT ...
  • Page 76 GUIDE SET/ ENTER DTV/(SAT) ∞ INFO When a Pioneer receiver is connected to the Monitor, the VCR REC FAVORITE CH ¡ receiver can be operated using buttons 4 to 6. RECEIVER When another company’ s receiver is connected to the Monitor, INPUT have the signals for 4 to 6 learned (see page 74).

  • Page 77: Cable Control Buttons

    REMOTE CODE SET UP CABLE CONTROL BUTTONS Mode switch CABLE and SAT cannot be selected at the same time. When the mode switch is set to CBL/SAT/DTV the cable converter connected to the Monitor can be operated using the TV CBL /SAT buttons 1 to 5.

  • Page 78: Sat Control Buttons

    REMOTE CODE SET UP SAT CONTROL BUTTONS Mode switch CABLE and SAT cannot be selected at the same time. When SAT is preset by REMOTE CODE SET UP , the remote TV CBL control unit buttons will function as shown below. /SAT /DTV •...
  • Page 79 REMOTE CODE SET UP DTV CONTROL BUTTONS The following buttons will not work if a digital tuner has not Mode switch been connected. 1 SCREEN MODE button Press to select the SCREEN MODE. TV CBL /SAT /DTV ON/OFF 2 Direct channel selection buttons INPUT Press the button (or buttons) that corresponds to the channel that you wish to watch.

  • Page 80: Vcr Control Buttons

    REMOTE CODE SET UP VCR CONTROL BUTTONS Mode switch If the VCR is preset by REMOTE CODE SET UP, the remote control unit button will function as follows when the mode switch of the remote control unit is set to VCR. TV CBL When the input selector button having the same number as /SAT...
  • Page 81 REMOTE CODE SET UP DVD/LD CONTROL BUTTONS Mode switch DVD and LD cannot be selected at the same time. If the DVD/LD is preset by REMOTE CODE SET UP , the remote control unit button will function as follows when the mode TV CBL /SAT /DTV...

  • Page 82: Menu Index

    MENU INDEX Main menu (See page 26) PICTURE adjustment menu (See page 51) PICTURE PICTURE SOUND MO D E : S T D SCREEN C O N T R A S T B L A C K L V L SET UP C O L O R T I N T...
  • Page 83 MENU INDEX CHANNEL SET UP menu (See page 28) AUTO CHANNEL PRESET menu (See page 28) SET UP SET UP C H A N N E L S E A U T O C H A N N A U T O C H A N N A N T E N N A : A C H A N N E L T V / C A B L E...

  • Page 84: Troubleshooting

    Sometimes the trouble may lie in another component. Investigate the other component and electrical appliances being used. If the trouble cannot be rectified even after exercising the checks listed below, ask your nearest PIONEER authorized service center or your dealer to carry out repair work.
  • Page 85 TROUBLESHOOTING The following symptoms may be mistakenly regarded as malfunctioning. In many cases, they are not the faults of the Monitor. SYMPTOM CAUSE There are 2 or 3 layers of images (ghost Influence of waves from the broadcast stations reflected by nearby mountains and images) high-rise buildings.

  • Page 86: Specifications

    SPECIFICATIONS Display and amplifier section Electrical section, miscellaneous Reception system ..American TV standard NTSC system Power requirements ........120 V AC, 60 Hz Screen size ..........64" (PRO-720HD) Power consumption 58" (PRO-620HD) At time of shipment ......325 W, 600 VA (CSA) 53"...
  • Page 88 Haven 1087, Keetberglaan 1, B-9120 Melsele, Belgium TEL: 32-3-570-0511 PIONEER ELECTRONICS AUSTRALIA PTY. LTD. 178-184 Boundary Road, Braeside, Victoria 3195, Australia, TEL: 61-39-586-6300 PIONEER ELECTRONICS DE MEXICO S.A. DE C.V. San Lorenzo 1009 3er Piso Desp. 302 Col. Del Valle Mexico D.F. C.P. 03100 TEL: 52-5-688-52-90 <TNSSF/01G00000>...
