800 LB. Load CaPaCITY
PICkuP TRuCk RaCk
InsTRuCTIons and PRECauTIons
Read this material before using this product.
Failure to do so can result in serious injury.
saVE ThIs ManuaL.
©
Copyright
2008 by Harbor Freight Tools
contained herein may be reproduced in any shape or form without the express written consent of Harbor
Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improve-
ments, actual product may differ slightly from the product described herein. Tools required for assembly
and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
Manual Revised 10h
Model
Visit our website at: http://www.harborfreight.com
®
. All rights reserved. No portion of this manual or any artwork
98511
