WELCOME Dear Panasonic Customer, Welcome to the Panasonic family of customers. We hope that you have many years of enjoyment from your new colour television. This is a very advanced television; however, the Quick Start Guide will tell you how to have the TV operating quickly. You can then read the instructions completely and retain them for future reference. -
Page 3: Warnings And Precautions
D This type of picture tube damage, is not an operating defect, and as such is not covered by the Panasonic warranty. D CABINET AND PICTURE TUBE CARE Remove the mains plug from the wall socket. The cabinet and picture tube can be cleaned... -
Page 4: Accessories
ACCESSORIES Check that you have the accessories and items shown Remote Control Transmitter EUR511268 Operating Instruction book Batteries for the Remote Control Transmitter. Pan uropean guarantee (2 x R6 (UM3) size) Remote control batteries Make sure that the batteries are fitted the correct way round. -
Page 5: Quick Start Guide
QUICK START GUIDE Plug in aerial and connect ancillary equipment. SATELLITE RECEIVER VCR / DVD/R First, ensure that the VCR / DVD/R is in Standby mode. Plug in TV and switch on. - Page 6 QUICK START GUIDE Select your country. Press the red button. Auto setup will begin, your stations will be located and stored. Use the Programme Edit menu to delete unwanted stations (see page 18). Press the TV/AV button to exit. TV/AV If you are installing a new Q---Link compatible VCR / DVD/R, you can now switch it ON.
- Page 7 QUICK START GUIDE Slight tilting of the picture may be noticeable or coloured patches may sometimes appear at the corners of the screen (colour purity). The Geomagnetic Correction feature can be used to eliminate them, if necessary: First, ensure the ATP and Q---Link download procedures are complete. The screen should not be showing any On---Screen Display menus.
-
Page 8: Basic Controls
BASIC CONTROLS : FRONT PANEL AND REMOTE CONTROL MAINS Power On/Off switch Red light indicates Standby mode. RCA Audio/Video sockets STR (Normalisation store) (page 30) Used to store tuning and other function S---VHS socket (see page 30) settings Headphone socket (see page 30) F (Function select) TV/AV switch (see page 30) Displays the On Screen Display functions, use... -
Page 9: Using The On Screen Displays
USING THE ON SCREEN DISPLAYS This TV has a comprehensive system of On Screen Display menus to access adjustments and options Some selections, for example, Contrast, Brightness, Colour and Sharpness will allow you to increase or decrease their level. Some selections, for example, Off timer, allow a choice to be made. Some selections, for example Tuning menu, will lead to a further menu. -
Page 10: Aspect Controls
ASPECT CONTROLS ASPECT Press the ASPECT button to move through the four aspect options: Auto, 4:3 16:9 and S---Zoom. 16:9 Auto Selecting AUTO mode this will Auto automatically cause the TV to display any incoming picture at its correct format, i.e. 16:9 or 4:3. -
Page 11: Still Control
ASPECT CONTROLS S---Zoom S---Zoom allows increased magnification and the ability to move the picture horizontally and vertically. S-Zoom The on screen selector keys that appear for some aspect function will clear after a few seconds. If you subsequently wish to select an operation then press the Aspect key once more for the keys to reappear. -
Page 12: Multi Window
MULTI WINDOW Press the MULTI WINDOW button (whilst the on screen selector keys are on MULTI screen) to move between watching the current programme, the picture and WINDOW picture and the picture in picture. The on screen selector keys (corresponding to the four coloured buttons on the remote control) that appear for the features clear after a few seconds. -
Page 13: Picture Menu
PICTURE MENU This menu allows you to make adjustments to the picture quality PICTURE Picture menu Open the Picture menu Viewing mode Dynamic Contrast Move to your choice Brightness Colour Sharpness Colour balance Normal Increase or decrease levels or P-NR set options TV/AV Press the TV/AV button to exit the... - Page 14 PICTURE MENU Contrast Brightness Colour The Contrast, Brightness, Colour, Tint (in NTSC only) and Sharpness levels can Tint (NTSC only) be adjusted to suit your own preferences and the viewing conditions. Sharpness Colour balance The Colour balance setting allows you to set the overall colour tone of the picture. P- -NR P--NR will automatically reduce unwanted picture interference.
-
Page 15: Sound Menu
SOUND MENU The Sound menu will allow you to set your personal preferences for all aspects of sound quality SOUND Open the Sound menu Sound menu Volume Move to your choice Bass Treble Balance Increase or decrease levels or set Headphone volume options Stereo... -
Page 16: Setup Menu
SETUP MENU The Setup menu provides access to various advanced features and also to the Tuning menu SET UP Setup menu Open the Setup menu AV2 out Teletext List Move to your choice Off timer Flicker reduction On Increase or decrease levels, set Q-Link options or access further menus Text language... -
Page 17: Tuning Menu
TUNING MENU The Tuning menu provides access to manual, automatic and fine tuning menus SET UP Open the Setup menu Setup menu Move to Tuning menu AV2 out Teletext List Off timer Access Tuning menu Flicker reduction On Q-Link Text language West Move to your choice Tuning menu... -
Page 18: Tuning Menu - - Programme Edit
TUNING MENU - - PROGRAMME EDIT The Programme edit menu allows you to edit the programme position settings SET UP Open the Setup menu Move to Tuning menu Tuning menu Programme edit Access Access Tuning menu Auto setup Manual tuning Fine tuning Move to Programme edit menu Colour system... - Page 19 TUNING MENU - - PROGRAMME EDIT To add a programme position Make sure the cursor is in the Prog. column Programme edit Prog. Chan. Name Lock Sys Press the Green button CH41 XYZ CH44 ZXY Press the Green button again to confirm This blank programme can then be Cancel...
- Page 20 TUNING MENU - - PROGRAMME EDIT To rename a programme position Programme edit Move to the Name column Prog. Chan. Name Lock CH41 Choose the new character CH44 Move to the next character position ABCDEFGHIJKLMNOPQRST UVWXYZ+-. 123456789 Continue until renaming is done Press STR to store To lock a programme position to prevent access...
- Page 21 TUNING MENU - - PROGRAMME EDIT To copy programme information to a compatible VCR / DVD/R connected to AV2 Move to the Prog. column DOWNLOAD IN PROGRESS PLEASE WAIT Programme : 48 Press the Blue button on the remote Remote control unavailable control Programme data will now be sent to the VCR / DVD/R.
-
Page 22: Tuning Menu - - Auto Setup
TUNING MENU - - AUTO SETUP (ATP) The Auto setup menu will allow you to automatically retune the TV to your local stations. It is useful if you move to a different region SET UP Open the Setup menu WARNING All current tuning Move to Tuning menu data will be erased... -
Page 23: Tuning Menu - - Manual Tuning
TUNING MENU - - MANUAL TUNING Manual tuning of the Programme positions is available either from the On Screen Display menu or from the front panel controls Manual tuning menu SET UP Open the Setup menu Move to Tuning menu CH41 Access Tuning menu Manual tuning... -
Page 24: Q- -Link
Q- -LINK Q- -Link allows the television to communicate with your VCR / DVD/R SET UP Setup menu Open the Setup menu AV2 out Teletext List Move to Q--Link Off timer Flicker reduction On Q-Link Confirm Q--Link is set to “On” Text language West Tuning menu... -
Page 25: Osd Language
VCR / DVD/R. Auto Power functions With Panasonic Q--Link VCR / DVD/Rs these additional features are available: D If you insert a tape in your VCR / DVD/R and press the Play button, the television will automatically switch on and select the AV2 input so you can view the tape. -
Page 26: Vcr/Dvd/R Operation
VCR / DVD/R OPERATION The Remote Control is capable of operating some functions of selected Panasonic VCRs and DVD/R (Digital Versatile Disc) equipment. Some VCR and DVD/R equipment have different functions, so to ensure compatibility please refer to the equipment’s instruction book or consult your dealer for details. -
Page 27: Teletext Operation
TELETEXT OPERATION D Teletext features may vary depending on the Broadcasting Companies and is only available if the channel selected is transmitting Teletext. D Pressing the Picture button whilst in Teletext operation will display the contrast function with a cyan bar, press A " to alter the setting as required. D Pressing the Setup button whilst in Teletext operation will display special function options at the bottom of the screen. - Page 28 TELETEXT OPERATION It is not possible to change the programme position when in News flash, Update or Sub Coded Page Access operation. Reveal SET UP Press the SET UP button to display special functions, followed by the Red button to reveal hidden words e.g. quiz page answers. Press again to hide. Red / Green / Yellow / Blue buttons In TOP/FLOF mode these correspond to the differently coloured subjects.
- Page 29 TELETEXT OPERATION It is not possible to change the programme position when in News flash, Update or Sub Coded Page Access operation. Accessing sub pages When Teletext information exceeds one page, it may take some time for the automatic changing of the sub pages to reach the sub page you require. As each sub page is found its number is displayed at the top of the page so that you may select it;...
-
Page 30: Audio / Video Connections
AUDIO / VIDEO CONNECTIONS AV Select and Setup Once your equipment is connected, use the following procedure to view the input: TV/AV Press the TV/AV menu button Press the relevant on screen selector key to select the AV source you wish to view (for example, press the green button to select AV2 if you have connected a video recorder to the AV2 SCART socket). -
Page 31: Scart, S--Video Socket And Component In (Y, Pb, Pr) Information
AUDIO / VIDEO CONNECTIONS SCART, S- -Video Socket and Component in (Y, Pb, Pr) Information Scart socket AV2 Scart socket (S---Video--- AV4 only) (S---Video, Q---Link) Socket Earth Socket Earth CVBS in (video) CVBS in (video CVBS out (video) CVBS out (video) RGB status earth Earth CVBS earth... -
Page 32: Rear Sockets
AUDIO / VIDEO CONNECTIONS Rear sockets Additional equipment can be connected at the rear of the TV via three 21 pin Scart sockets, AV1 / AV2(S) / AV4(S). HI--FI SYSTEM 2 x RCA Audio Cables Output from L- - R AUDIO OUT Sockets Input/Output from Input/Output from... -
Page 33: Troubleshooting
TROUBLESHOOTING Symptoms Checks Checks Sound Picture Aerial location, direction or connection Noisy Sound Snowy Picture Aerial location, direction or connection Multiple Images Normal Sound Electrical appliances Cars / Motorcycles Fluorescent lights Switch on P---NR in Picture menu to reduce picture noise Interference Noisy Sound Volume level... -
Page 34: For Your Guidance
Before requesting service, please refer to the troubleshooting guide on previous page to determine the symptoms. To obtain service please contact your local Panasonic dealer quoting the model number and serial number (both are located at the rear of the TV). - Page 36 2005CS...
