- Page 1 INSTRUCTION MANUAL Hammer Drill HP1630 HP1631 008892 DOUBLE INSULATION WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
-
Page 2: Specifications
ENGLISH SPECIFICATIONS Model HP1630 HP1631 Concrete 16 mm 16 mm Capacities Steel 13 mm 13 mm Wood 30 mm 30 mm No load speed (min 0 - 3,000 0 - 3,000 Blows per minute 0 - 45,000 0 - 45,000... -
Page 3: Specific Safety Rules
a cord suitable for outdoor use reduces the risk of preventive safety measures reduce the risk of electric shock. starting the power tool accidentally. If operating a power tool in a damp location is 20. Store idle power tools out of the reach of unavoidable, use a ground fault circuit children and do not allow persons unfamiliar with the power tool or these instructions to... -
Page 4: Functional Description
only when hand-held. Reversing switch action Do not touch the bit or the workpiece 1. Reversing immediately after operation; they may be switch lever extremely hot and could burn your skin. Some material contains chemicals which may be toxic. Take caution to prevent dust inhalation and skin contact. -
Page 5: Installing Side Grip
• gauge is installed. 008897 Installing or removing drill bit For Model HP1630 The depth gauge is convenient for drilling holes of uniform depth. Loosen the side grip and insert the depth 1. Chuck key gauge into the hole in the side grip. Adjust the depth gauge to the desired depth and tighten the side grip. -
Page 6: Maintenance
If you need any assistance for more details regarding symbol to use "rotation only" action. these accessories, ask your local Makita Service Center. Drilling in wood Tungsten-carbide tipped hammer bit •... - Page 8 Makita Corporation 884816-9...
