Air-Conditioners
PLH18, 24, 30, 36, 42AK
PL12, 18, 24, 30, 36, 42AK
PCH24, 30, 36, 42GK
PC24, 30, 36, 42GK
PKH18, 24, 30, 36FK3
PK12, 18, 24, 30, 36FK3
PKH18, 24, 30, 36FL
PK18, 24, 30, 36FL3
FOR USER
OPERATION MANUAL
For safe and correct use, please read this operation manual thoroughly before operating the air-conditioner unit.

Advertisement

Table of Contents

   Also See for Mitsubishi Electric Mr.Slim PLH18

   Summary of Contents for Mitsubishi Electric Mr.Slim PLH18

  • Page 1 Air-Conditioners PLH18, 24, 30, 36, 42AK PL12, 18, 24, 30, 36, 42AK PCH24, 30, 36, 42GK PC24, 30, 36, 42GK PKH18, 24, 30, 36FK3 PK12, 18, 24, 30, 36FK3 PKH18, 24, 30, 36FL PK18, 24, 30, 36FL3 FOR USER OPERATION MANUAL...
  • Page 2: Table Of Contents

    Contents 1. Safety Precautions 1. Safety Precautions ..................2 s Before installing the unit, make sure you read all the “Safety precautions”. 2. Operation ....................3 s The “Safety precautions” provide very important points regarding safety. 2.1. Switching the unit on/off .............. 3 Make sure you follow them.
  • Page 3: Operation

    2. Operation Operating range Indoor air intake temperature Outdoor air intake temperature Maximum 95 °F DB, 71 °F WB 115 °F DB Cooling CHECK TEST COOL Minimum 67 °F DB, 57 °F WB 0 °F DB* ˚F MODEL ˚C SELECT STOP AMPM ON/OFF –...
  • Page 4: Adjusting Airflow Direction

    2. Operation 2.5. Adjusting airflow direction The vertical air vane helps select the vertical direction of the airflow. 1 Press AIR DISCHARGE button to select the vertical airflow direction. • Each time you press the button, the option changes are displayed on the remote controller, as shown below.
  • Page 5: Care And Cleaning

    3. Care and cleaning I PLH/PL Series Caution: • Always turn off the power, first on the remote controller and then the main switch, before cleaning or servicing the unit. • When installing or removing the filter or the intake grille, do not stand on an unsteady surface.
  • Page 6: Care And Cleaning

    3. Care and cleaning 4. Troubleshooting 3.2. Care and cleaning Clean the filter When the A “FILTER” indicator blinks on the remote controller to alert you to the necessity of cleaning of the filter. ∗ As a guideline for typical office environment, the long-life filter must be cleaned ON/OFF –...
  • Page 7: Specifications

    5. Specifications Models Item PLH18AK PLH24AK PLH30AK PLH36AK PLH42AK Cooling *1 BTU/h 18,000 24,000 30,000 35,400 42,000 Capacity Heating *1,*3 BTU/h 19,000 [24,500/25,500] 26,000 [31,500/32,500] 33,000 [39,500/41,200] 38,000 [45,900/47,600] 44,300 [52,200/53,900] Heating *2,*3 BTU/h 11,000 [16,500/17,500] 16,500 [22,000/23,000] 18,500 [25,000/26,700] 23,000 [30,900/32,600] 26,800 [34,700/36,400] Cooling...
  • Page 8 5. Specifications Models Item PL12AK PL18AK PL24AK PL30AK PL36AK PL42AK Cooling capacity *1 BTU/h 12,500 18,400 24,000 31,000 36,500 42,500 Power consumption *1 kW 1.26 1.85 2.65 3.17 3.64 4.08 SEER 10.1 10.2 10.0 10.6 10.5 10.8 INDOOR UNIT MODELS PL12AK PL18AK PL24AK...
  • Page 9 5. Specifications Models Item PCH24GK PCH30GK PCH36GK PCH42GK Cooling *1 BTU/h 24,000 30,000 35,400 42,000 Capacity Heating *1,*3 BTU/h 27,000 [34,000/35,500] 33,000 [40,500/42,500] 38,000 [45,500/47,500] 45,000 [52,500/54,500] Heating *2,*3 BTU/h 14,800 [21,800/23,300] 20,000 [27,500/29,500] 21,000 [28,500/30,500] 23,800 [31,300/33,200] Cooling *1 kW 2.51 3.23 3.60...
  • Page 10 5. Specifications Models Item PC24GK PC30GK PC36GK PC42GK Cooling capacity *1 BTU/h 25,000 31,000 36,500 42,500 Power consumption *1 kW 2.61 3.18 3.62 4.10 SEER 10.4 10.0 10.3 10.8 INDOOR UNIT MODELS PC24GK PC30GK PC36GK PC42GK External finish Munsell 0.7Y 8.59 / 0.97 Power supply V, Phase, Hz 115, 1, 60...
  • Page 11 5. Specifications Models Item PKH18FK3/PKH18FL PKH24FK3/PKH24FL PKH30FK3/PKH30FL PKH36FK3/PKH36FL Cooling *1 BTU/h 18,000 24,000 30,000 34,200 Capacity Heating *1,*3 BTU/h 18,600 [24,100/25,100] 25,000 [30,500/31,500] 33,000 [39,100/40,500] 38,000 [44,100/45,500] Heating *2,*3 BTU/h 10,700 [16,200/17,200] 14,700 [20,200/21,200] 19,000 [25,100/26,500] 19,600 [25,700/27,100] Cooling *1 kW 1.79 2.36 3.12...
  • Page 12 5. Specifications Models Item PK12FK3 PK18FK3/PK18FL3 PK24FK3/PK24FL3 PK30FK3/PK30FL3 PK36FK3/PK36FL3 Cooling capacity *1 BTU/h 12,500 18,500 24,000 30,000 34,200 Power consumption *1 kW 1.21 1.75 2.34 3.06 3.47 SEER 11.5 11.3 10.6 10.7 10.2 INDOOR UNIT MODELS PK12FK3 PK18FK3/PK18FL3 PK24FK3/PK24FL3 PK30FK3/PK30FL3 PK36FK3/PK36FL3 External finish Munsell 3.4Y 7.7/0.8...
