MANUFACTURING
NUMBERS:
9700464
9700466
9700469
9700474
9700476
9700479
System Tested and Certified by NSF
International against NSF/ANSI
Standard 42 and 53 for the reduction of:
Standard No. 42: Aesthetic Effects
Nominal Particulate Reduction Class I
Standard No. 53: Health Effects
Cyst Reduction
Turbidity Reduction.
P/N 1010873 Rev. C 05/05
WATER FILTRATION
UFL-420/440 Series
Owner
SYSTEM
s Manual
'
Advertisement
Table of Contents
Related Manuals for Antunes Filtration Technologies UFL-420 9700464
Summary of Contents for Antunes Filtration Technologies UFL-420 9700464
- Page 1 MANUFACTURING NUMBERS: 9700464 9700466 9700469 9700474 9700476 9700479 WATER FILTRATION SYSTEM System Tested and Certified by NSF International against NSF/ANSI Standard 42 and 53 for the reduction of: UFL-420/440 Series Standard No. 42: Aesthetic Effects Nominal Particulate Reduction Class I Standard No.
-
Page 2: Table Of Contents
OWNER INFORMATION Warranty Information General Please read the full text of the Limited Warranty in this Antunes Filtration Technologies, Division of A.J. manual. Antunes & Co., has partnered with companies from around the globe to produce the UFL-Series water fil- If the unit arrives damaged, contact the carrier imme- tration systems. -
Page 3: Important Safety Information
UFL-420/440 WATER FILTRATION SYSTEM OWNER INFORMATION (continued) Service/Technical Assistance Purchased From: If you experience any problems with the installation Date of Purchase: or operation of your unit, contact Antunes Filtration Model No.: Technologies at 1-630-784-1000, or toll free in the United States at 1-800-253-2991. - Page 4 UFL-420/440 WATER FILTRATION SYSTEM IMPORTANT SAFETY INFORMATION (continued) The following warnings and cautions appear throughout • If the supply cord is damaged, it must be this manual and should be carefully observed. replaced by the manufacturer or its service agent or a similarly qualified person.
-
Page 5: Electrical Cord & Plug Configurations
UFL-420/440 WATER FILTRATION SYSTEM SPECIFICATIONS Dimensions Electrical Ratings Model & Voltage Watts Amps Hertz Mfg. No. UFL-420 50/60 9700464 UFL-420 50/60 9700466 UFL-420 50/60 9700469 UFL-440 50/60 9700474 UFL-440 50/60 9700476 UFL-440 50/60 9700479 Electrical Cord & Plug Configurations 120 VAC 230 VAC (P/N 0700665) (P/N 0700666) - Page 6 UFL-420/440 WATER FILTRATION SYSTEM SPECIFICATIONS (continued) Components Permeate Drain Mounting Bracket Power Transformer LED Display Program Button Filter Housing Flow Controller Inlet Figure 2. Components P/N 1010873 Rev. C 05/05...
-
Page 7: Performance Data Sheet
UFL-420/440 WATER FILTRATION SYSTEM PERFORMANCE DATA SHEET Filter Cartridge Capacities System Tested and Certified by NSF Maximum Operating Pressure 100 psig (690 kPa) International against NSF/ANSI Maximum Operating Temp. 104°F (40°C) Standard 42 and 53 for the reduction of: Maximum Trans Membrane Pressure 45 PSI (3.1 Bar) pH Range 3-10 Standard No. -
Page 8: Installation
UFL-420/440 WATER FILTRATION SYSTEM INSTALLATION If soldered plumbing is used, do not apply heat to, or Unpacking near, the filtration system. The use of union (O-ring 1. Remove the system and all packing materials seal) connections is highly recommended for ease of from the shipping carton. -
Page 9: Locating And Mounting The System
UFL-420/440 WATER FILTRATION SYSTEM INSTALLATION (continued) Locating and Mounting the System Consider these points before mounting the system: INSET • Note the location of the water supply, drain, and an appropriate electrical outlet when choosing a Sanitation mounting location. Into Flow Controller Plug (not Filter... - Page 10 UFL-420/440 WATER FILTRATION SYSTEM INSTALLATION (continued) properly for the plumbing line. This valve will allow for 1. Plug the power cord into the appropriate electrical easier servicing and future cartridge change out. outlet. The unit will power on and the LED display will display the following for about two seconds DRAIN LINE PLUMBING each:...
- Page 11 UFL-420/440 WATER FILTRATION SYSTEM INSTALLATION (continued) SANITIZING THE SYSTEM AND LINES 6. When the water flow out of the inlet fitting stops, close the inlet drain valve and pour the liquid The plumbing must be sanitized to eliminate possible bleach into the inlet connection fitting. Be careful contamination that may have occurred during the instal- not to spill bleach onto clothing or skin.
-
Page 12: Filtration Process
UFL-420/440 WATER FILTRATION SYSTEM OPERATION Filtration Process Starting the System Water filtration in the UFL Series is accomplished using Power up the unit. two modes: The LED read-out displays the following for about two • Flush Interval ( on the LED display) seconds each: •... -
Page 13: Programming Timer During Startup
UFL-420/440 WATER FILTRATION SYSTEM OPERATION (continued) Programming Timer During Startup NOTE: Once the unit is powered up, the LED display cycles through the default or current settings: Flush Duration (Fd) and its setting will be followed by Flush Interval (Fi) and its settings. At any time during this sequence, which lasts approxi- mately 30 seconds the unit can be programmed. -
Page 14: Manual Flushing
UFL-420/440 WATER FILTRATION SYSTEM OPERATION (continued) Programming Timer While Unit is in Flush Interval (Fi) Mode TO SET Fi - FLUSH INTERVAL MODE NOTE: After power-up and cycling - Fi time setting displays a flashing decimal point. PROGRAM 1. Press and hold the Program button for four seconds. -
Page 15: Checking The Timer Program
UFL-420/440 WATER FILTRATION SYSTEM MAINTENANCE The filtration system is designed to require very little 6. Unplug the system. maintenance. To ensure that the water is of the highest 7. Make sure there is enough room below the quality, occasionally some service is required. housing to remove the cartridge. -
Page 16: Troubleshooting
UFL-420/440 WATER FILTRATION SYSTEM TROUBLESHOOTING Problem Possible Cause Corrective Action Unit does not have power. The power cord is not correctly Plug power cord in correctly. plugged in. The Control Display is blank. The power cord is not correctly Plug power cord in correctly. plugged in. -
Page 17: Wiring Diagram
UFL-420/440 WATER FILTRATION SYSTEM WIRING DIAGRAM POWER CORD W/24V XFORMER NOTE: ALL WIRES TO BE 16 GA. AWM-105°C UNLESS OTHERWISE SPECIFIED. 14 GA. AWM-105°C 22 GA. AWM-105°C TERMINAL BLOCK CONTROL BOARD SOLENOID VALVE P/N 1010873 Rev. C 05/05... - Page 18 UFL-420/440 WATER FILTRATION SYSTEM REPLACEMENT PARTS UFL-420/440 (continued) Replacement Parts can be purchased from an authorized dealer. Contact Antunes Filtration Technologies at 1-630-754-1000 or toll free in the United States at 1-800-253-2991 NOTE: Item 12 is GREEN and rated at 5 GPM for UFL-420 units. For UFL-440 units, it is BLACK and rated at 10 GPM.
-
Page 19: Replacement Parts Ufl-420/440
UFL-420/440 WATER FILTRATION SYSTEM REPLACEMENT PARTS UFL-420/440 Replacement Parts can be purchased from an authorized dealer. Contact Antunes Filtration Technologies at 1-630-754-1000 or toll free in the United States at 1-800-253-2991 Item Part Description Qty. Item Part Description Qty. 0400334 Strain Relief - Small 2190146 Union Assembly 1”... -
Page 20: Limited Warranty
2. Antunes Filtration Technologies reserves the right to make changes in design or add any improvements on any product. The right is always reserved to modify equipment because of factors beyond our control and government regulations. Changes to update equipment do not constitute a warranty charge.
