- Page 1 IN400 AV SWITCHING AMPLIFIER INSTALLATION AND OPERATION MANUAL...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION PRÉCAUTIONS DURANT UTILISATION Read these instructions. LISEZ ces instructions. Keep these instructions. Tenez ces instructions. Heed all warnings. Notez tous les avertissements. Follow all instructions. Suivez toutes les avertissements. Do not use this apparatus near water. N’utilisez pas ce produit près de l’eau (la piscine, la plage, le lac, etc.). Clean only with dry cloth. -
Page 3: Introduction And Contents
REAR PANEL The IN400 is a compact AV switching amplifi er with a host of extra features SETUP available to the AV integrator. With 8 AV inputs as well as mix in, stereo line... -
Page 4: Front Panel
IR SENSOR This is the sensor used for IR control. A hand held remote control is supplied with the IN400. Line of sight is required for the remote control to work. COMMS LED This LED indicates when data is sent or revceived via IR or RS485. -
Page 5: Rear Panel
AMP OUT feature can be used in paging environments or emergency systems. Short it to The IN400 has a built in audio stereo power amplifi er. The input signal is the RS485 ground pin to activate it. parallelled from the AUDIO OUTPUT. The power amp is rated at 2 x 80W into 4 ohm, 2 x 50W into 8ohm. - Page 6 None XXX - 3 byte data so may be inserted anywhere in the data network. If the IN400 is being used at the end of a chain, <CR> - carriage return a 120ohm (characteristic impedance of UTP) terminating resistor should be connected between All bytes are ASCII the + and - connections.
-
Page 7: Installation
AWG10 AWG13 AWG14 AWG16 AWG17 AWG18 AWG20 AWG22 AWG24 AWG26 or CAT6 UTP cabling. RS485 data networks should be wired in a ‘daisy chain’ confi guration with a maximum of 32 devices in the chain. The IN400 is not Speaker terminated so may be inserted anywhere in the data network. -
Page 8: Block Diagram
BLOCK DIAGRAM PAGE 8 IN400 INSTALLATION AND OPERATION MANUAL... - Page 9 DIMENSIONS IN400 INSTALLATION AND OPERATION MANUAL PAGE 9...
-
Page 10: Specifications
482 x 44 x 325mm 19 ” x 1.75” x 12.8” NET WEIGHT 7.0kg 15.4lb SHIPPING WEIGHT 9.0kg 19.8lb SHIPPING DIMENSIONS (WXHXD) 520 x 90 x 420 mm 19.0” x 3.5” x 16.5” PAGE 10 IN400 INSTALLATION AND OPERATION MANUAL... - Page 11 NOTES IN400 INSTALLATION AND OPERATION MANUAL PAGE 11...
-
