Summary of Contents for LG GR-P247PGMH
- Page 1 OWNER’S MANUAL REFRIGERATOR Please read this owner's manual thoroughly before operating and keep it handy for reference at all times. GR-P247PGMH GR-P247PGMY GR-P247PDLT GR-P247PGMK www.lg.com P/No. : MFL67442701...
- Page 2 Table of contents Introduction Installation Operation Suggestion on food storage Care and maintenance This product is exclusive use at 230V/50Hz. You should purchase transformer of more than 2.0KVA when you want to use it at the 110V area.
-
Page 3: Basic Safety Precautions
Entry The model and serial numbers are found on the inner case or Right side of refrigerator compartment of this unit. These numbers are unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase. -
Page 4: When Connecting The Power
WARNING To reduce the risk of fire, electric shock, or injury to persons when using your product, basic safety precautions should be followed, including the following. Read all instructions before using this appliance. 1. When connecting the power The dedicated outlet should be used. •... - Page 5 Do not pull out the cord or touch the power plug with wet hands. It may cause electric shock or injury. Remove water or dust from the power plug and insert it with the ends of the pins securely connected. Dust, water or unstable connection may fire or electric shock.
-
Page 6: When Using The Refrigerator
2. When using the refrigerator Do not place the heavy object or the dangerous object (container with liquid) on the refrigerator. It may be dropped to cause injury, fire or electric shock when opening or closing the door. Do not install the refrigerator in the wet place or the place which water or rain splashes. - Page 7 Do not use the combustible spray near the refrigerator. It may cause fire. Install in places away from the fire such as the place where flammable gas is leaked. It may cause fire. Do not place flower vase, cup, cosmetics, medicine or any container with water on the refrigerator.
- Page 8 Do not spray water at the outside or the inside of the refrigerator or do not clean it with benzene or thinner. Deterioration of insulation of electric parts may cause electric shock or fire. When any strange smell or smoke is detected from the refrigerator, disconnect the power plug immediately and contact to the service center.
- Page 9 Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. Do not damage the refrigerant circuit. Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.
- Page 10 Do not touch food or containers at the freezer with wet hands. It may cause frostbite. Do not put ice in thin crystal cup or ceramic ware. It may break cup or ceramic ware to cause injury. When the electricity is off, remove ice from the ice bucket (only for the model with the dispenser).
-
Page 11: Identification Of Parts
Because opening or closing the door or the home bar of the refrigerator may cause injury to the person around it, be careful, please. Opening or closing the door may cause feet or hands to be caught in the chink in door or the child to be get hurt by the corner. -
Page 12: Disposal Of The Old Appliance
Where to Install Select a good 1. Place your appliance where it is easy to use. location 2. Avoid placing the unit near heat sources, direct sunlight or moisture. 3. To ensure proper air circulation around the fridge -freezer, please maintain sufficient space on both the sides as well as top and maintain at least 2 inches (5 cm) from the rear wall. -
Page 13: Door Removal
Door removal Lower cover Electric Shock Hazard WARNING Disconnect electrical supply to refrigerator before installing. Failure to do so could result in death or serious injury. Feed water tube If your access door is too narrow for the refrigerator to pass through, remove the refrigerator door and pass the refrigerator laterally. Remove lower Remove the lower cover by lifting upward and then pull up the feed water tube cover and... -
Page 14: Door Replacement
Pass the Pass the refrigerator laterally through the access refrigerator door as shown in the right figure. Door replacement Mount them in the reverse sequence of removal after they pass through the access door. Feed water pipe installation Before Automatic ice maker operation needs water pressure of 147~834 kPa installation (1.5~8.5 kgf/cm ) (That is, an instant paper cup (180 cc) will be fully filled... -
Page 15: Height Adjustment
Height adjustment When the floor is - When the height of the door may not be not leveled leveled when the floor is not leveled. When the freezer door is lower – Use the (-) driver or spanner to turn the groove or nut of the height adjustment screw on the left to the counterclockwise direction to level the door. -
Page 16: Adjusting The Temperatures And Functions
Starting When your refrigerator is first installed, allow it to stabilize at normal operating temperatures for 2-3 hours prior to filling it with fresh or frozen foods. If operation is interrupted, wait 5 minutes before restarting. Adjusting the temperatures and functions Your model may not include every option. - Page 17 You can adjust temperature of and freezer room and refrigerator room. The actual inner temperature varies depending on the food status, as the indicated setting temperature is a target temperature, not actual temperature within refrigerator. Refrigeration function is weak in the initial time. Please adjust temperature as above after using refrigerator for minimum 2~3 days.
- Page 18 The water collector has no self-drainage function, so it should be cleaned regularly. Remove the cover by pulling the front of the water collector cover and dry it with a cloth. The automatic icemaker can automatically make 6 cubes at a time, 40~50 pieces per day.
- Page 19 - Do not disassemble the ice maker unless it is WARNING necessary. - Hold the ice storage bin using both hands so that it does not fall. - Do not touch the ice dispenser with your hand or tool. - Because the ice maker can operate by opening the freezer door, please take precaution.
- Page 20 This button stops operation of different button. Locking or Release is repeated whenever the is pressed more than 3 seconds. If you use the button, none of LOCK UNLOCK the other buttons will work until you unlock them. There is a replacement indicator light for the water filter cartridge on the dispenser.
- Page 21 How ice/cold Water is cooled while stored in the water tank in freezer door, and then sent to water is supplied the dispenser. Ice is made in the automatic ice maker and sent to the dispenser divided into crushed or cubed form ice. NOTE It is normal that the water is not very cold at first.
-
Page 22: Refreshment Center (Applicable To Some Models Only)
Refreshment center (Applicable to some models only) How to use the 1. Press the top central part of the Home Bar until you hear the Press until you Home Bar "Click" sound. hear the "Click" - You can save electricity because you do not have to open sound the refrigerator door. -
Page 23: Nano Charcoal Deodorizer
Shelf You can store side dish or refrigerated food on the shelf with sufficient space in between the containers. 1. Hold the front part of the shelf and pull it out until it gets blocked by the hooking part. 2. When you cannot pull out the shelf any more, lift it up slightly. -
Page 24: Fresh Compartment
Fresh compartment You can store fruits or vegetables. 1. Hold the front handle of the fresh compartment and pull it out until it gets blocked by the hooking part. 2. When you cannot pull out the fresh compartment any more, lift it up slightly to pull it out completely to the front side (outer side). -
Page 25: Vacuum Fresh Compartment
Vacuum fresh compartment You can store vegetables or fruits freshly for a long period of time. - In the middle vacuum fresh compartment, you can store the vegetable or fruit for a longer period of time with the improved seal and vacuum effect. 1. -
Page 26: Freezer/Fridge Basket
Freezer/Fridge basket You can store small packaged frozen food (Freezer basket), small packaged refrigerated food or beverages (Fridge basket) such as milk, beer etc. But, do not store ice cream or food to store for a long period of time (Freezer basket) etc. -
Page 27: How To Exchange The Water Purifier Filter
(or about 1 liter) to remove any air or residual charcoal. (Charcoal is not hazardous to the human body.) Is LED lamp turned on? - As LED lamp is difficult for customer to exchange directly, please contact to LG Electronics service center unless the lamp light up. -
Page 28: Location Of Foods
Location of foods (Refer to identification of parts) Store various frozen foods such as meat, fish, ice cream, frozen snacks, etc.. Store small packed frozen food. Temperature is likely to increase as door opens. So, do not store long-term food such ice cream, etc.. -
Page 29: Storing Foods
Storing foods Store fresh food in the refrigerator compartment. How food is frozen and thawed is an important factor in maintaining its freshness and flavor. Do not store food which goes bad easily at low temperatures, such as bananas, and melons. -
Page 30: General Information
General information During average length vacations, you will probably find it best to leave the refrigerator in operation. Place freezable items in freezer for longer life. When you plan not to operate, remove all food, disconnect the power cord, clean the interior thoroughly, and leave each door OPEN to prevent odor formation. -
Page 31: Troubleshooting
Trouble shooting Before calling for service, review this list. It may save you both time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Runing of refrigerator Refrigerator control is off. Set refrigerator control. -
Page 32: Temperatures Are Too Warm
Thermostat is keeping the refrigerator This is normal. The refrigerator goes on at a constant temperature. and off to keep the temperature constant. Temperatures are too cold Set the freezer control to a warmer Freezer control is set too cold setting until the freezer temperature is satisfactory. - Page 33 Sound and noise Today’s refrigerators have increased It is normal for sound levels to be higher. storage capacity and maintain more even temperatures. Refrigerator operates at higher pressures This is normal. The sound will level off as during the start of the ON cycle. the refrigerator continues to run.
- Page 34 Odors in refrigerator Clean interior with sponge, warm water Interior needs to be cleaned. and baking soda. Cover food completely. Food with strong odor is in the refrigerator. Some containers and wrapping materials Use a different container or brand of produce odors.
- Page 35 Ice has melted and frozen around auger Remove ice storage bin, and thaw and due to infrequent use, temperature the contents. Clean bin, wipe dry and fluctuations and/or power outrages. replace in proper position. When new ice is made, dispenser should operate.
-
Page 36: It Is Normal
It is Normal... The following occurrences are normal. This is the sound of various parts expanding/contracting When you hear "Tak" or "Took" sound or various control devices operating depending on the temperature change within the refrigerator. When you hear This is the count of compressor or fan operating when "Deureureuk~", "Dulkuk"... -
Page 37: Product Information
Product information GR-P247PGMH GR-P247PGMY Model GR-P247PDLT GR-P247PGMK Producer Category Capacity (l) Weight (kg) Free standing / Built-in Defrost system Sound Power (dB) Energy Class Energy Consumption (kWh/year) Temperature rise time (hr) Freezing Capacity (kg/24hr) Refrigerant Star Rating Climate Class Climate Class : SN - T (This appliance is intended to be used at an ambient...
