- Page 1 INSTRUCTIONS FOR USE AND INSTALLATION Electric Hob HEH 604...
-
Page 2: Table Of Contents
CONTENTS Unpacking of the appliance ..............2 Recommendations ................2 • INSTALLATION Safety instructions ................3 Fitting the hob ................... 3/4 Electrical connection ................. 5/7 • USING THE APPLIANCE Presentation of the hob ................ 8 Technical data ..................8 The different hot plates ................. 9 Using the hot plate ................ -
Page 3: Installation
In the event that this advice is ignored and the installation is carried out by an unqualified person, HOOVER declines all responsibility for any technical failure of the product whether or not it results in damage to goods or injury to individuals. - Page 4 Building-in according to TYPE Y (Norm EN 335-2-6) Opening 10x10 cm 560 mm The body of the hob is fitted with 4 location holes to take the fixing brackets that secure the intended to fix the hob in the unit. Place the 4 fixing bars in such a way that the hob surface is placed perfectly in the support unit.
-
Page 5: Electrical Connection
• HOOVER cannot be held responsible for any accidents resulting from the use of an appliance which is not connected to earth, or with a faulty earth connection continuity. - Page 6 2 - Operations to be carried out to make a new connection: . Choose the supply cord in accordance with the recommendations in the table on next page. . The hob must be in situation as shown : Earth Terminal .
- Page 7 INSTALLATION: "ELECTRICAL CONNECTION" ² ² ² ² 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5 PH PH PH PH PH 1rst Phase 1rst Phase 1rst Phase 1rst Phase Shunt 2nd Phase Shunt...
-
Page 8: Using The Appliance Presentation Of The Hob
Building-in dimensions (cm) - (see chapter "Installation") Width : 56 Depth : 48 Total electrical power: 6 kW In order to improve the quality of the products, HOOVER may carry out modifica- tions linked to technical improvements. Appliance meeting with the standard CEE 89/336, and 73/23. -
Page 9: The Different Hot Plates
THE HOT PLATE THE STANDARD ELECTRICAL HOT PLATE This is a cast-iron hot plate, controlled by a 7 positions commutator. Each position corresponds to a permanent and progressive tempe- rature according to the marks 1, 2, 3, 4, 5 and 6. RAPID SELF-PROTECTING ELECTRIC HOT PLATE (with a red dot in the centre) This a cast-iron hot plate, controlled by a 7 positions commutator. -
Page 10: Cooking With The Hot Plate
For information, we note below the different powers reached according to the type of the plate and the control knob setting. Cooking with the electric hot plate To gest the best results from your appliance it is important to observe the following: •... -
Page 11: General Maintenance
MAINTENANCE Before all cleaning or dismantling operation, it is imperative to: . disconnect the hob to the mains supply. . let all parts of the hob cool down. Never use: . harsh abrasives, scouring pads or sharp object to clean the hob. •...
