NEC MultiSync X462HB Detailed Specifications page 2

An ideal solution for digital
signage in high ambient light
environments.
The 46" NEC X462HB shines a new light of performance on outdoor digital signage, drive-thru menu
boards and video walls that are placed in heavily-lit environments. With its high-bright (1200 cd/
m2), professional-grade panel and remarkable contrast ratio (3500:1), the 46" NEC X462HB displays
images at amazing brightness levels no matter the lighting condition. Ideal for environments heavy
with ambient light, this model boasts a quarter-lambda polarizing film that allows for outdoor
viewing with polarized sunglasses in both landscape and portrait display orientations. The result is
an image with greater visibility that outperforms displays with standard brightness and polarization,
which can appear dim or washed out when placed in areas with high ambient light.
Product Highlights
•
Ultra high bright panel designed for high ambient light
situations
•
Full connectivity, including option slot
•
A panel specifically designed for heavy duty applications
•
Advanced thermal panel design
•
Quarter-lambda polarizing film for optimal viewing
Typical environment with high ambient light
Suitable Applications
•
Retail (shopping centres
and retail stores)
•
Transportation (train
stations, bus terminals)
•
Fast food restaurants
(menu boards)
•
Pubs and clubs
•
Semi outdoor solutions
(within suitable casing/
protection)
Plus many, many more...
2
Outstanding Performance
The X462HB's full high-definition screen performance
is enhanced by 30+ advanced features of the Digital
Signage Technology Suite, including advanced ther-
mal protection and improved operating temperature,
which helps maintain the display's performance in
even the most demanding environments.
Quarter-lambda polarizing film
allows viewing of content
regardless of display orientation or the use of polarized
sunglasses.
Thermal protection
starts with an extra thermal layer
on the display panel to diffuse heat followed by fan-based
technology specially designed to work in both landscape and
portrait modes and be controlled locally or remotely. Internal
temperature sensors control self-protective circuits, while
special self-diagnostics communicate the status of the thermal
characteristics.
Sealed panel design
provides protection in less than
optimal environments, while protecting against particles like
dust, grease, or steam from getting behind the glass and
damaging the unit.
Enhanced video wall capabilities
allow you to expand
your messaging options. Technologies include:
•
TileMatrix™ allows you to create video walls (up to 100
displays in a 10x10 matrix)
•
TileComp™ works in tandem with TileMatrix to compensate
for the bezel width and create a more seamless video wall
•
Copy function allows the user to apply the settings from
one display to all others in the RS-232 daisy chain, reducing
setup time and saving money.
•
Individual and Group ID functions allow users to control
settings for a defined individual display or group of displays
within a video wall
•
Display Wall Calibrator Kit (optional) provides a quick,
accurate and easy-to-use means of matching all displays in
color and brightness to create uniformity across the video
wall
CableComp+™
uses a digitised signal delay circuit to
automatically compensate for each red, green and blue
cable's length and video signal delay, ensuring sharp image
reproduction despite long cables and low output level.
Advanced screen saver functions
include an array of
features designed to reduce the risk of image persistence and
extend display life.
Delivering Genuine Benefits
Eco-Friendly Features
•
An ambient light sensor, which ensures consistent
brightness no matter the lighting conditions, with efficient
product design and high quality components ensuring
power consumption is significantly minimized.
•
A carbon footprint metre, which helps track and calculate
the conservation of green gas emissions.
•
Improved operating temperature allows for improved
installation flexibility
•
Industrial-strength, premium-grade panel with additional
thermal protection, internal temperature sensors with self
diagnostics and fan-based technology
Extended Functionality
A built-in expansion slot future-proofs your display investment,
allowing for seamless integration of NEC and third-party
components, including an HD-SDI card, single-board computer
and DVI daisy chain capability, avoiding additional cables and
mounting brackets.
NEC MultiSync X462HB
Centralised, Convenient, Cost Efficient Maintenance
and Control
With free LAN control software – the industry's most extensive
control, diagnostic and communication provide the highest
level of remote display management. These include:
•
RS-232 enables multi-display control and daisy chain,
allowing for individual and group-addressable control, and
simple, effective setup and monitoring of the display
•
Ethernet connectivity adds the same RS-232 control plus
automatic email notification for diagnostic purposes
•
NaViSet™ software offers an intuitive graphical interface,
allowing for easy adjustment of display settings via mouse
and keyboard. NaViSet Administrator provides all the
advanced control to remotely located IT professionals.
•
DDC/CI standard allows for PC control of the display based
on the VESA command set
Easy Connection
Enhanced input options include quick input change,
customised detection and naming. DisplayPort and HDMI,
along with a LAN interface for control of the screen are unique
in this combination in a public display and secure future
proofing.
Real-time clock/round-the-clock scheduling
Allows for advanced scheduling of monitor powering up/down.
3
