Owner´s manual
USB-MIDI-Masterkeyboard with 25 keys
Features:
-Class Compliant for Windows XP,
Windows Vista 32/64 & Mac OS X (10.2.6 & higher)
-25 high-quality dynamic keys
-Programable 2-way-joystick with integrated knob
-4 different velocity curves
-Programable slider
-10 user memory places to store own settings
-Footswitch-input for a sustain-pedal
-MIDI-Out
-USB powered or optional with AC adaptor
eMail:
info@miditech.de
Internet:
www.miditech.de
1
Advertisement
Table of Contents
Related Manuals for Miditech Midistart music 25
Summary of Contents for Miditech Midistart music 25
- Page 1 Windows Vista 32/64 & Mac OS X (10.2.6 & higher) -25 high-quality dynamic keys -Programable 2-way-joystick with integrated knob -4 different velocity curves -Programable slider -10 user memory places to store own settings -Footswitch-input for a sustain-pedal -MIDI-Out -USB powered or optional with AC adaptor eMail: info@miditech.de Internet: www.miditech.de...
- Page 2 This manual is written to help you become familiar with the features of the Midistart music 25. Please read the manual carefully to discover all the features of your Midistart music 25. After reading the manual, you will have a clear understanding of how to transmit different MIDI messages to other instruments and equipment.
-
Page 3: Power On/Off
By default the DATA buttons are used for Octave function. If you hold the SHIFT button at the same time, they will be assigned with Transpose. The default keyrange of the Midistart music 25 is from C2-C4. With DATA +/- you can change it 3 octaves up or down. - Page 4 By default the DATA buttons are used for Octave function. If you hold the SHIFT button at the same time, they will be assigned with Transpose. The default keyrange of the Midistart music 25 is from C2-C4. With DATA +/- you can change it 3 octaves up or down.
- Page 5 Value range：0-145 The center position of the joystick will send data 0, and the lowest position will send data 127. How to choose a soundprogram in 3 steps: The next 3 steps will work together, if you want to choose a bank and a sound number in a sound module. You can use step 3 alone to change the sound number in the actual soundbank.
-
Page 6: Velocity Curve
4.System settings Velocity Curve There are 4 different velocity curves can be selected ranged. Press <SHIFT><Velocity curve> and immediatly the curve will be changed. Velocity Curve 1 (Normal) Velocity Curve 2 (Soft) Velocity Curve 3 (Hard) Velocity Curve 4 (Expand) Pedal Polarity You can set the polarity of the switch type pedal. - Page 7 Store operation: Press <SHIFT>, <Regist> and <Set value> at the same time, it means, press a number key and regist key at the same time, it is not necessary to press <ENTER>. Recall Operation: Press <SHIFT><Regist><Set value> simply press a number key and do not need <Enter> a Standard Midi Controller (CC) numbers Controller Funktion...
- Page 8 Data Entry +1 Expression Data Entry -1 Effect Control 1 NRPN LSB Effect Control 2 NRPN MSB 46/47 Not defined RPN LSB General Purpose #1 RPN MSB General Purpose #2 102-119 Not defined All Sound Off EG Attack Time Reset All Controllers EG Decay Time Local Control on/off EG Release Time...
-
Page 9: Specifications
Specifications: Keyboard:25 keys (C2 - C4), (velocity sensitive) Functions:Basic functions: USB MIDI, Octave shift, Transpose, Joystick, Pedals, MIDI OUT, Slider, Function buttons:MIDI Data: Bank select, Program change, GM System On, GS System on, All Notes Off, etc; Parameters: Transose, Octave, MIDI out channels, Velocity curve, Pitch bend, Moulation, Brightness, etc. Panel Controls and Indicators: Function buttons with light ×...
