Summary of Contents for Miditech K32S
- Page 1 K32s Owner's Manual USB masterkeyboard with General MIDI sound engine Manual V.1.0 – 29.09.2019 eMail: info@miditech.de Internet: www.miditech.de...
-
Page 2: Table Of Contents
Catalog (1) Preface ..........................3 (2) What’s in the Box? ......................3 ......................3 (3) Panel overview ....................... 4 (4) Functions overview 4.1 PAD1: ..........................4 4.2 Touch Pitch Bend wheel: ................... 5 4.3 PAD2: ..........................5 4.4 Octave buttons(DOWN& UP): ................... 5 4.5 Shift: .......................... -
Page 3: Preface
0~9 . Left pannel have pedal input jack , USB socket and phone out . K32s comes with MIDI sound source to support external amplifier or headphone output. You can play internal GM sound when USB cable connected or you can play internal GM sound without USB cable connecting just use 3 of “Rechargeable”... -
Page 4: Functions Overview
3.2 Left pannel overview Function of the serial number (1) PAD1 (2) Touch Pitch Bend (3) PAD2 (4) Octave buttons(DOWN& UP) (5) Shift button (6) Clipper potentiometer (Slider) (7) Unlimited rotation data regulator(Encoder) (8) Electricity LED (9) Power switch with volume regulator (10) Composite function :Transpose -7~0~+7 (11) Composite function :Velocity curve (12) Composite function :Reverb ON/OFF... -
Page 5: Touch Pitch Bend Wheel
Switch to Sustain : “Shift” button and “PAD1” are pressing until “Shift” LED flash blue. 4.2 Touch Pitch Bend wheel: Transmits MIDI Pitch Bend information to raise or lower the pitch of a note temporarily. 4.3 PAD2: This button has two modes : 1. -
Page 6: Clipper Potentiometer (Slider)
“Shift”, “OCTAVE DOWN” and “OCTAVE UP” LED flash RED. 4.6 Clipper potentiometer (Slider): The potentiometer can adjust the specific MIDI controller message. K32s send CC #15Hex. And send TVF cutoff freq modify for internal GM sound. 4.7 Unlimited rotation data regulator (Encoder): Unlimited rotation data regulator to send specific MIDI controller message, K32s send CC #16Hex . -
Page 7: Composite Function :Velocity Curve
4.15 Sustain pedal Jack: Connect to the pedal jack. 4.16 Mini USB Jack: Connect to the mini USB wire . K32s is power for USB and charging when “Rechargeable” Ni-MH batteries installed. 4.17 3.5mm Headphone Jack: Connect to the headphone . External speaker mute of K32s when connect to the... -
Page 8: System And Specifications
(5) System and Specifications: 5.1 Minimum System Requirements: If you are using your K32S with a computer, the following minimum system requirements need: Windows Mac OS Macintosh G3*800/G4*733MHzor higher Pentium 3 800MHz or higher CPU requirement may be higher laptops CPU requirement may be higher for laptops OS X 10.3.9 with 256MB RAM... -
Page 9: Gm Sound List
(6) GM Sound list:... - Page 10 The device may only be used for this purpose and in accordance with the operating instructions. The detailed operating instructions can be found on our homepage www.miditech.de. Other uses and the use of our products under other operating conditions are expressly not intended and may lead to damage to...
- Page 11 If this symbol is on the packaging, the packaging of the product can be disposed of in the local recycling process. Miditech products should not be disposed of with normal household waste. This applies to all electrical and electronic equipment. Within the scope of your national regulations and guidelines, please take old appliances to the appropriate collection points or return them to your dealer for proper disposal.
