Haier XPB70-111S User Manual

Haier twin-tub washing machine user's manual
Hide thumbs

Advertisement

Quick Links

Twin-tub Washing Machine
This manual is for
XPB70-111S
XPB70-112S
Special number:
Please read this manual
carefully before using.
Retain it for future reference.
0030806263
User's manual

Advertisement

loading

  Also See for Haier XPB70-111S

  Related Manuals for Haier XPB70-111S

  Summary of Contents for Haier XPB70-111S

  • Page 1 Twin-tub Washing Machine This manual is for XPB70-111S XPB70-112S Special number: 0030806263 Please read this manual carefully before using. Retain it for future reference. User's manual...
  • Page 2 Contents Names of the parts Safety precautions Installation and adjustment Preparation before washing The musts in washing Usage of the detergent Washing sequence Disposal after washing Trouble-Shooting *Answers to question Packing list *Specification...
  • Page 3: Names Of The Parts

    Names of the parts Buzzer Water-filling entrance Water inlet selector handle Wash selector Wash timer Control panel Overflow filter Quick water-filling entrance Drain hose hook Water level adjusting lever Lint filter(Installed by user) Pulsator Wash tub Drain hose Wash tub cover Base frame Note Different machine,the form of cortrol panel is different.
  • Page 4: Safety Precautions

    Safety precautions Please insert the power cord into special receptacle with rated vol- tage.Be sure to use single-phase three pins receptacle.The earthing terminal of the receptacle must be earthed reliably.If possible,please adopt electric leakage protector. If the power cord is bad, to avoid risk it is required to replace it by the technicians ofour special shop or the after-sale service department.
  • Page 5 Safety precautions Do not stretch hands into the working machine. It is dangerous even if the rotation is slow. Take special care of the children. Do not put any hot or heavy items ( such as the kettle with hot water ) on the washing machine.
  • Page 6: Installation And Adjustment

    Installation and adjustment Please install and adjust the machine according to the requirement of the manual. It is very important to your security and correct operating the machine. Install the lint filter After opening the package,please take out the lint filter from the document bag,install it to the overflow filter of the wash tub.See to the figure.
  • Page 7: How To Change The Direction Of The Drain Hoses

    How to change the direction of the drain hoses Figure 1 indicates the ex factory installation position of the drain hose. Extend the drain hose from the side of spin tub. Take off the drain hose from the hanging hole of the cabinet.
  • Page 8: Install The Water Inlet Hose; Select The Water Level

    Install the water inlet hose; Select the water level Insert the water inlet hose into the water-filling entrance on the control panel, then push the water-filling jointer into the entrance on the control panel. (To dismantle the water inlet pipe, just push the control handle as indicated in the figure and pull it out) Select water level according to the...
  • Page 9: Preparation Before Washing

    Preparation before washing Pay attention to followings before washing the laundries Check if Clear the the laundries pocket. Take has special out the coins, requirement sand, hairpins on washing etc. a. Check if the laundries are applicable for washing with machine. b.
  • Page 10: The Musts In Washing

    The musts in washing Usage of the detergent How to use the whitener Fill water to decided level. Dilute the whitener with container. Pour it slowly into thewashing tub. Avoid using whitener on laun- dries with color or pattern as they are prone to lose color.
  • Page 11: Washing Sequence

    Washing sequence Wash timer Wash selector (To set to below 2 minute, (Strong current, first set to 5 minute then standard current) turn it back. it can increase the service life of the timer). STRONG SILK WOOL STANDARD COTTON LINEN WASH SELECTOR WASH TIMER Wash...
  • Page 12: Midway Spinning

    Midway spinning 1.Put the laundries into the spin tub evenly and smoothly. 2.Spin (1) Put the gland in properly. Proper (2) Close the inner and outer cover of the spin tub. (3) Spin for 1-2 minutes. 3.Run the foam-removing spinning. (1) Open the outer cover of the spin tub.
  • Page 13: Rinse With Water-Filling

    Rinsing Rinse with water-filling 1.Put the laundries into the wash tub. Select suitable current according to the laundries. 2.Adjust the water level Set the water level with water level adjusting lever according to the laundries quantity. Then fill suitable water continuously. 3.Rinse Adjust the wash timer to 5-7 minutes to do rinsing.
  • Page 14 Spinning 1. Put the laundries into the spin tub evenly and smoothly. 2. Press the gland in the tub properly. Close the inner and outer cover of the spin tub. 3. Spin Select suitable spin time according to the laundries, and do spinning. During spinning, if there's abnormal sound, it is generally owing to slanting placement of the laundries.
  • Page 15: Disposal After Washing

    Disposal after washing After using, please clean the lint and foreign materials of the lint filter and overflow filter in time. Otherwise it may influence your using the machine. Please first pull off the power plug from the receptacle before cleaning. Cleaning the lint filter The lint filter must be used during washing.
  • Page 16: Cleaning The Overflow Filter

    Cleaning the overflow filter 2. Take off the corrugation pipe. Dismantle the upper part of the corrugation pipe overflow filter ( as indicated in Figure 1). 3. Cleaning the overflow filter Clean the lint around the filter and flush with tap water. 4.
  • Page 17: Trouble-Shooting Answer To Question

    Trouble-shooting Answer to question If the laundries fall to the outer side of the spin tub If the laundries fall to the outer side of the spin tub, please take them out immediately. 1.Dismantle As indicated in the figure, push the point marked with "...
  • Page 18: Trouble-Shooting Answers To Question

    Trouble-shooting Answers to question (If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company.
  • Page 19: Packing List

    Packing list Name User's manual Water inlet hose Lint filter Water-filling jointer Gland Twin-tub washing machine Specification Water level/Water quantity (about) Injection pressure(MPa Rated washing / spinning capacity(kg) Quantity One piece One piece One piece One piece One piece One set Maximum/55L Medium/46L Minimum/36L 7.0/5.0 (weight of standard dry cloth)
