Updated on 04/01/2009
GPS
Tracker
USER MANUAL
V5.0
GT30X
Track Systems Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GT30X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Track Systems GT30X

Summary of Contents for Track Systems GT30X

  • Page 1 Track Systems Ltd Tracker USER MANUAL V5.0 GT30X Updated on 04/01/2009...

  • Page 2: Table Of Contents

    Track Systems Ltd Contents 1 Product Overview 2 For Your Safety 3 GT30 Parameters 4 Getting Started 4.1 Hardware and Accessories 4.2 Light and Button Functionality 4.3 First Use 5 SMS Command 5.1 Basic SMS Commands 5.1.1 Return the location of the tracker 5.1.2 Set Interval for automatic timed report...

  • Page 3: Product Overview

    Track Systems Ltd 1 Product Overview GT30 provides an easy way to track your targets and provides peace of mind by showing you with your mobile phone or PC the location of your targets via SMS or GPRS. GT30 has the following features:...

  • Page 4: Getting Started

    Track Systems Ltd GPS Chipset latest GPS SIRF-Star III chipset GPS Sensitivity -158Db GPS Frequency L1, 1575.42 MHz C/A Code 1.023 MHz chip rate Channels 20 channel all-in-view tracking Position Accuracy 10 meters, 2D RMS Velocity Accuracy 0.1 m/s Time Accuracy...

  • Page 5: First Use

    Track Systems Ltd Blue LED - indicating GPS status One button is pressed Flashing ( every 0.1 second) The unit is being Initialized GT30 has a GPS fix Flashing (on for 0.1 second and off for 2.9 seconds) GT30 has no GPS fix...

  • Page 6: Sms Command

    Track Systems Ltd Mini USB Port Connect the tracker with computer by USB cable (with USB to Serial Converter) for configuration or reading stored waypoints data. You need to install the driver - PL-2303 Driver Installer - for using the USB converter.

  • Page 7: Sos/Call B/Call C

    Track Systems Ltd SMS sent: W000000,002,000 SMS received: Set Timer Ok/000 Meaning: GT30 will stop automatic timed report. 5.1.4 SOS/Call B/Call C Description: To authorize a mobile phone number for the SOS, Call B or Call C button. When the button is pressed, a message will be sent and/or simultaneously a call will be made to the authorized number.

  • Page 8: Set Ip Address And Port

    Track Systems Ltd Note: If no APN name and password required, input APN only. Example: W000000,011,CMNET GT30 will reply with an SMS (like ‘Set APN Ok/CMNET’) to confirm this setting. 5.2.3 Set IP Address and Port Command: W<password>,012,IP,PORT Example: W000000,012,202.116.11.12,8000 GT30 will then reply with an SMS (‘Set IP Ok/202.116.11.12,8000’) to confirm this setting.

  • Page 9: Troubleshooting

    Track Systems Ltd Input the latitude and longitude that you receive from the tracker by SMS and click the search button. Google Earth will display the location for you. Example: When you receive: Latitude = 22 32 40.05N Longitude = 114 04 57.74E Type as the following picture shows: (Note: you should input the latitude and longitude as: 22 32 40.05N 114 04 57.74E)
  • Page 10 Track Systems Ltd Battery needs charging Recharge battery for 3 hours Problem: Unit will not reply with SMS Possible Cause: Resolution: Green LED is flashing (on for 1 second and off for 2 Make GT30 connected to GSM network. seconds) GSM Network is slow Wait for SMS.

  • Page 11: Sms Command List

    Track Systems Ltd 8 SMS Command List Remarks: ****** is user’s password and the default password is 000000. Description Command Remarks Get current location W******,000 Get current location of GT30 Change user’s password W******,001,###### ****** is old password ###### is new password...
  • Page 12 Track Systems Ltd Extend Settings W******,008,ABCDEFG### A=0, turn off the function of sending an SMS location report to the authorized phone number when it makes a call to GT30. A=1, turn on the function of sending an SMS location report to the authorized phone number when it makes a call to GT30.
  • Page 13 Track Systems Ltd Presetting by SMS for GPRS tracking (Ensure that your SIM card supports GPRS connection prior to setting) Set ID for GT30 W******,010,ID Tracker ID must not over 14 digits. Set APN W******,011,APN,APN Name, name password Password required, just insert APN only;...
  • Page 14 Track Systems Ltd time difference in minute directly. For example, W000000,032,120 ‘-‘is required for those behind GMT. For example, W000000,032,-120. Set character for SOS alert W******,033,P,Char P is the button number. message P=1, SOS button P=2, Call B P=3, Call C.
