Page 2: Before You Start
XDMA7800 Preparation Please read entire manual before installation. Before You Start • Disconnect negative battery terminal. Consult a qualified technician for instructions. • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration. Getting Started •... -
Page 3: Wiring Diagram
XDMA7800 Wiring Diagram RCA PreamiJ Output BLACK Female USB Input Connections Rear USB Connection SUBWOOFER _ _ _ _ _ _ , BWE 1D-pin Female Mini-DIN HDM90 Connection [sold separately] ~~~~~~~~~~~~==~~t=======~~~====~~~31~Antenna Optional USB Extension Cable Connector [Included] Steering Wheel Interface Input connection SWJ.PS (sold... -
Page 4: Receiver Controls
XDMA7800 Receiver • Controls Control Function Description Changes another mode of operation. Hold down power off/ on. Source/Power Mute/ Mutes the audio output. Activates iTunes Tagging (HDM90 required). Select Activates music searches. Confirms rrienu options. Accesses configuration options within the main menu. - Page 12 XDMA7800 iTunes® Tagging Operation [HDM90) Overview The iTunes Tagging feature of the XDMA7800 requires the optional HDM90 module (sold separately). Once connected, the HDM90 allows the user to "Tag" songs that are playing on HD Radio™ stations and enables them to be purchased later through iTunes.
-
Page 16: Displayed Information
XDMA7800 CD Player Operation · MP3/WMA/ AAC Displayed Information Press DISPLAY to select between displayed information such as 103 tag information and file/folder names. Display layout for MP3/WMA/ AAC CD's Mode Track Number Clock Song Title Artist Name File Type Album Name Track Progress Elapsed Time... -
Page 22: Usb/Sd Card Operation
XDMA7800 USB/SD Card Operation Connect a USB Device To play MP3/WMA/ MC files from most mass storage (sold separately) devices,connect a device to one of the XDMA7800's two USB ports (front or rear). Connect an SD Card To play MP3/WMA/ MC files from an SO Card, insert an (sold separately) SO card into the XDMA7800's SO card slot, located behind the front panel. - Page 25 XDMA7800 USB / SD Card Operation File/Folder Compatibility and Support • CD-ROM (ISO), CD-R, CD-RW • CO-DA (digital audio) • MP3 data (.mp3) Compatible File Types • WMA data (.wma) • AAC data (.m4a) • WAV lossless • DRM protected files •...
-
Page 26: Bluetooth Operation
XDMA7800 Bluetooth® Operation Pairing a Device Preparation Before you can use a Bluetooth device, it must be paired and connected. Make sure that Bluetooth is activated on your device before you begin the pairing process. Pairing a New Device The XDMA7800 broadcasts the pairing signal constantly when no devices are currently connected. -
Page 29: Bluetooth Reset
XDMA7800 Bluetooth® Operation Streaming Audio Operation The XDMA7800 supports A2DP (advanced audio distribution profile) wireless streaming audio from your Bluetooth mobile device directly to your head unit. You can also control your music from the front panel of the head unit using AVRCP [audio video remote control profile].
