  • Page 1: Owners Manual

    TM2000 / TM4000 / TM6000 Owners Manual Failure to return the Warranty Registration document (enclosed) to Control Chief within 30 days of purchase will void any warranty responsibilities on behalf of Control Chief Corporation Control Chief Corporation 200 Williams Street Bradford, PA 16701...
  • Page 2 Control Chief Corporation, a world leader in wireless radio and infrared remote control products has developed and expanded upon this powerful technology. More than three decades of experience in designing, manufacturing and installing state-of-the-art remote communication systems emphasize Control Chief’s mission.
  • Page 3 ® TELECHIEF SERIES TM2000 / TM4000 / TM6000 OWNER’S MANUAL 1.0 Radio Warranty 1.1 Warranty 1.2 Warranty Period 1.3 Warranty Service 1.4 Excluded Parts 1.5 Remarks 2.0 Safety 2.1 Safety Considerations 2.2 Symbols 2.3 Warnings 3.0 Standard Components 3.1 Receiver (RX) 3.2 Transmitter (TX)
  • Page 4 Warranty Period. This equipment is warranted against defects in materials and workmanship for a period of one (1 year from the date of shipment. During the warranty period, Control Chief is responsible for necessary repairs/replacement as long as the product can be proven defective.
  • Page 5 ® TELECHIEF SERIES TM2000 / TM4000 / TM6000 OWNER’S MANUAL 6. Aisles between equipment, stock, etc., should be free of obstructions so the radio control operator can move freely. These aisles should meet local regulations. 7. Radio controlled operators should always position themselves for the best view of the equipment they are controlling.
  • Page 6 3. Only authorized personnel should service this equipment. Unauthorized work on this unit will void the warranty. 4. This manual is for reference only; please call your distributor or Control Chief if further assistance is required. 5. The equipment has been tested for correct operation before delivery from the factory. However, it must not be used in critical or hazardous operation where incorrect operation may cause personal or equipment damage.

  • Page 7: Standard Components

    All replacement part orders require the System Serial Number and the Channel Number for proper frequency matching. Receivers TM2000 AC Receiver, Part Number = 701P0040 TM2000 DC Receiver, Part Number = 701P0040-DC TM4000 AC Receiver, Part Number = 701P0060 TM4000 DC Receiver, Part Number = 701P0060-DC...

  • Page 8: Installation Procedure

    6. To avoid any interference, the receiver must be located away from motors, frequency drives, and power cables (Section 4.3). 7. Coil suppressors are recommended on all contactor coils and relay coils. Control Chief recommends RC type suppressors (Control Chief part number 0700-8002).
  • Page 9 ® TELECHIEF SERIES TM2000 / TM4000 / TM6000 OWNER’S MANUAL 4.2.2 Normally Open / Normally Closed Setup ® The TeleChief Series provides 2 different outputs for the R0/START relay: N.O. and N.C. The N.O. is the default setting. If an N.C. output is necessary, please remove the No. 8 wire (RO/Start) from the connector and insert it into No.
  • Page 10 ® TELECHIEF SERIES TM2000 / TM4000 / TM6000 OWNER’S MANUAL 4.3.1 Radio Schematics AC Models TM2000 TM4000 TM6000 4-button wiring schematic 6-button wiring schematic 8-button wiring schematic DC Models TM2000 TM4000 TM6000 4-button wiring schematic 6-button wiring schematic 8-button wiring schematic...
  • Page 11 ® TELECHIEF SERIES TM2000 / TM4000 / TM6000 OWNER’S MANUAL Remote Setting Remote setting allows you to pair the new transmitter and receiver if either of them becomes damaged. In order for the radios to work the transmitter and receiver must have the same ID codes and frequency. Using remote setting will set both the transmitter and receiver to have the same ID codes.

  • Page 12: Operation

    ® TELECHIEF SERIES TM2000 / TM4000 / TM6000 OWNER’S MANUAL Operation Standard Operation 1. Turn-on the main power switch of the equipment. 2. Install two (2) AA size alkaline batteries in the transmitter. 3. Press the Start/RO pushbutton to turn on the main relay inside the receiver.
  • Page 13 ® TELECHIEF SERIES TM2000 / TM4000 / TM6000 OWNER’S MANUAL 6.3.1 Change of fuse, DC Type Unplug the yellow fuse “F5” (20A) and replace with a new one Ref Fuse Number Size Fuse Type 5 x 20 mm 5 x 20 mm 5 x 20 mm 1.5A...

  • Page 14: Function Settings

    ® TELECHIEF SERIES TM2000 / TM4000 / TM6000 OWNER’S MANUAL Add dot of RTV to clip and press the new crystal down into the socket, bending the pins. Dot of RTV. Attention: The frequency is different when plugging the same crystal into the transmitter or receiver.
  • Page 15 ® TELECHIEF SERIES TM2000 / TM4000 / TM6000 OWNER’S MANUAL Receiver Mounting Diagram Installation Questions? Technical assistance is available from Control Chief. Please call us at 814-362-6811 or email the service department at prodserv@controlchief.com 95-00-0-036 Rev D Control Chief Corporation...
  • Page 16 Control Chief Corporation 200 Williams Street PO Box 141 Bradford, PA 16701 814-362-6811 * 1-800-233-3016 * 814-368-4133 (fax) www.controlchief.com...
