  • Page 1 OWNER’S MANUAL...
  • Page 2 Thanks for your purchasing of the G e n e r i c O N Y X 5 0. This model is designed for safety, built for durability, and perfected for daily street use. The unique of Generic vehicle design, enrich of stylish and peronality, represents your outstanding taste and favor to pursue the state of the art living attitude.
  • Page 3 This manual contains the most of the vehicle information, however, Generic will continually imrprove it’s product design and quality that lead to difference between the manual and vehicle . If you have any questions concerning this manual, please consult your Generic dealer.
  • Page 4 EAU10122 INPORTANT MANUAL INFORMATION Generic Dealer label here ONYX50 OWNER’S MANUAL...

  • Page 5: Table Of Contents

    EAU10122 TABLE OF CONTENTS EAU10210 SAFETY INFORMATION ....1-1 PRE-OPERATION CHECKS ..... 4-1 play ..........6-13 Other safetyriding points....1-3 Pre-operation check list ....4-2 Adjusting the rear brake lever free Location of labels ......1-4 play ..........6-13 OPERATION AND IMPORTANT RIDING Checking the front brake pads and rear DESCRIPTION ........
  • Page 6 EAU10122 TABLE OF CONTENTS EAU10210 Troubleshooting ........ 6-23 Troubleshooting chart ....... 6-24 SCOOTER CLEAN AND STORAGE ... 7-1 Clean..........7-1 Storage ..........7-3 SPECIFICATIONS ....... 8-1 CONSUMER INFORMATION ....9-1 Identification numbers ...... 9-1 Warranty information ......9-2 Service plan ........9-3 Wiring diagram........

  • Page 7: Safety Information

    Motorists, and let them aware of TOR AND CERTIFICATED RE- you safety from potential accidents: your location. PAIR SHOP/GENERIC DEALER TO Know your skills and limits. Always wear an approved helmet. ACQUIRE GOOD MECHANICAL Never lend your scooter to oth- with face shield to protect your eye CONDITIONS OF VEHICLE.
  • Page 8 Modifications when mounting accessories. When loading within this weight limit, Modifications made to this scooter that not approved by Generic, or the keep the following in mind: Never install accessories or carry Cargo and accessory weight removal of original equipment, may...

  • Page 9: Other Safetyriding Points

    EAU10122 SAFETY INFORMATION Other safe-riding points This vehicle is for On-Road Never start the engine or let it run transportation purpose only, for any length of time in a closed Turn the signal before making please do not install any of ex- area.

  • Page 10: Location Of Labels

    EAU10122 SAFETY INFORMATION Location of labels There are two labels that in the scooter and location as noted. 1.WARMING LABEL, FUEL 2.LABEL, ANTI-TAMPERING GENERIC...

  • Page 11: Description

    EAU10122 DESCRPTION Left view 1. Front wheel 2. Front brake caliper (page 6-15) 3. Front turn signal light 4. Helmet holder (page 3-8) 5. Storage compartment (page 3-9) 6. Rear turn signal light 7. Rear wheel 8. Adjusting nut (page 6-15) 9.

  • Page 12: Right View

    EAU10122 DESCRPTION Right view 14.Tail/brake light 15.Carrier (page 3-10) 16.Fuel tank cap 17.2-stroke engine oil tank cap 18.Seat (page 3-8) 19.Headlight 20.Spark plug (page 6-7) 21.Mainstand 22.Muffler...

  • Page 13: Controls And Instruments

    EAU10122 DESCRPTION Controls and instruments 25 26 23.Rear brake lever (page 3-4) 24.Left handlebar switches (page 3-3) 25.Speedometer unit (page 3-2) 26.Fuel gauge (page 3-3) 27.Right handlebar switches (page 3-3) 28.Front brake lever (page 3-4) 29.Throttle grip (page 6-12) 30.Main switch/steering lock (page 3-1) 31.Hook,Helmet (page 3-10) 32.Front storage compartment (page 3-10)

  • Page 14: Instrument And Control Functions

    EAU10122 INSTRUMENT AND CONTROL FUNCTIONS Main switch/steering lock/seat open OFF “ ” To unlock the steering All electrical systems are off. The key Push the key in, and then turn it to “ ” can be removed. while still pushing it. CHECK “...

  • Page 15: Indicator And Warning Lights

    EAU10122 INSTRUMENT AND CONTROL FUNCTIONS Indicator and warning lights 2-stroke engine oil level warning light Dashboard unit “ ” The warning light comes on when the 1 2 3 key is in the “ ” position or when the engine oil level in the 2-stroke engine oil tank is low during operation.

  • Page 16: Fuel Gauge

    EAU10122 INSTRUMENT AND CONTROL FUNCTIONS ” Fuel gauge Handlebar switches High/Low bean switch “ Set this switch to “ ” for the high beam and to “ ” for the low beam. Turn signal switch “ ” To signal a right-hand turn, push this switch to “...

  • Page 17: Front Brake Lever

    EAU10122 INSTRUMENT AND CONTROL FUNCTIONS Start switch “ ” Front brake lever Rear brake lever Push this switch (pull the brkae lever at same time to the start the engine. See page 5-1 for starting instructions prior to starting the engine. The front brake lever is located on the The rear brake lever is located on the right handlebar grip.

  • Page 18: Fuel And 2-Stroke Engine Oil Tank Caps

    EAU10122 To install the fuel tank cap Fuel and 2-stroke engine oil To access the 2-stroke engine oil tank, 1. Push the fuel tank cap into position open the storage compartment. (See tank caps 2. Turn the cap clockwise to the orig- page 3-8.) The fuel tank cap and the 2-stroke en- inal position.
  • Page 19 EAU10122 INSTRUMENT AND CONTROL FUNCTIONS does not exceed 10%. Gasohol contain- Fuel and 2-stroke engine oil CAUTION: ing methanol is not recommended by Immediately wipe off spilled fuel with G e n e r i c because it can cause damage a clean, dry, soft cloth, since fuel may to the fuel system or vehicle perfor- damage the painted surfaces or plas-...

  • Page 20: Catalytic Converter

    EAU10122 INSTRUMENT AND CONTROL FUNCTIONS Catalytic converter 2-stroke engine oil Kickstarter This model is equipped with a catalytic Make sure that there is sufficient 2- converter in the exhaust system. stroke engine oil in the oil tank. Add the recommended 2-stroke engine oil as necessary.

  • Page 21: Seat

    EAU10122 INSTRUMENT AND CONTROL FUNCTIONS Seat Helmet holder 3. Fold the seat up. To open the seat 1. Place the scooter on the cen -terstand. 2. Insert the key into the main switch, and then turn it counterclockwise to “OPEN”. OPEN PUSH 1.

  • Page 22: Storage Luggage Box

    EAU10122 INSTRUMENT AND CONTROL FUNCTIONS To take out the helmet from the hel- Storage Luggage Box Since the storage luggage box met holder will accumulates heat by the heat Open the seat, take out the helmet from of sun and engine, please do not put the helmet holder, and then close the any thing that sentitive to the heat.

  • Page 23: Front Hook,Helmet

    EAU10122 INSTRUMENT AND CONTROL FUNCTIONS Front hook,helmet Front storage box Rear Carrier 1. Front storage box 1. Rear Carrier 1. Front hook,helmet To open the front storge box when it is Front hook.helmet locked,insert the key and turn clockiwse Do not exceed the load limit of 2.5 direction to open it kg for the carrier.
  • Page 24 EAU10122 INSTRUMENT AND CONTROL FUNCTIONS Shelf front comp Sidestand Pedal (for pizza model) (optional accessories) 1. Side stand 1. Shelf front comp 1. Pedal The side stand is located on the left side The pedal is located on the left side and WARNING!! of the Vehicle.

  • Page 25: Pre-Operation Checks

    If any item in the Pre-operation check list is not working properly , have it inspected and repaired before operating the vehicle. If failed to be corrected by yourself, please turn to GENERIC repair shop immediately.

  • Page 26: Pre-Operation Check List

    Make sure that operation is smooth. Check cable free play. Throttle grip 6-11, 6-16 If necessary, have Generic dealer adjust cable free play and lubricate cable and grip housing. Check for damage. Check tire condition and tread depth. Wheels and tires 6-12~6-13 Check air pressure.
  • Page 27 EAU10122 PRE-OPERATION CHECKS Make sure that operation is smooth. Main stand 6-18 Lubricate pivot if necessary. Make sure that all nuts, bolts and screws are properly tightened. Chassis fasteners Tighten if necessary. Instruments, lights, signals Check operation. and switches Correct if necessary.

  • Page 28: Operation And Important Riding Points

    See page 5-4 for engine break-in in- circuit. their functions before riding. To structions prior to operating the ve- consult a Generic dealer shop if hicle for the first time. 3. Close the throttle completely. you not thoroughly understand. Please do not start the engine in...

  • Page 29: Starting Off

    EAU10122 OPERATION AND IMPORTANT RIDING POINTS starting attempt should be as short as 4. Check for oncoming traffic, and Starting off possible to preserve the battery. Do not then slowly turn the throttle grip (on NOTE: crank the engine more than 5 seconds the right) in order to take off.

  • Page 30: Acceleration And Deceleration

    EAU10122 OPERATION AND IMPORTANT RIDING POINTS Acceleration and deceleration Braking 1. Close the throttle completely. Avoid braking hard or suddenly 2. Apply both front and rear brakes , otherwise the scooter may skid simultaneously while gradually in- Railroad crossings, streetcar creasing the pressure.

  • Page 31: Engine Break-In

    If any engine trouble should occur may overturn. result in engine overheating must be during the engine break-in period, avoided. immediately have a Generic dealer check the vehicle. CAUTION: 0 ~ 150 km Avoid prolonged operation above 1/3 Never park in an area where there are throttle.

  • Page 32: Periodic Maintenance And Minor Repair

    Modifications not approved by Maintenance, replacement, or repair Generic may cause loss of perfor- of the emission control devices and mance, excessive emissions, and systems may be performed by any render the vehicle unsafe for use.

  • Page 33: Periodic Maintenance Chart For The Emission Control System

    Replace gasket(s) if necessary. Check the air cut-off valve, reed Air induction system valve, and hose for damage. Replace any damaged parts. * Since these items require special tools, data and technical skills, have a Generic dealer perform the service.

  • Page 34: General Maintenance And Lubrication Chart

    EAU10122 PERIODIC MAINTENANCE AND MINOR REPAIR General maintenance and lubrication chart 1,000 km 4,000 km 7,000 km 10,000 km 13,000 km 16,000 km month months months months months months Clean with solvent. Air filter element Replace if necessary. Check operation, fluid level, and for Front brake fluid leakage.
  • Page 35 Check operation and for oil Shock absorber leakage. assembly Replace if necessary. Check operation. Autolube pump Bleed if necessary. Final transmission Check vehicle for oil leakage. Change. V-belt Apply Generic chain and cable Control and meter lube or engine oil 10W-30 cables thoroughly.
  • Page 36 EAU10122 PERIODIC MAINTENANCE AND MINOR REPAIR 1,000 km 4,000 km 7,000 km 10,000 km 13,000 km 16,000 km month months months months months months Check operation and free play. Adjust the throttle cable free play if Throttle grip housing necessary. and cable Lubricate the throttle grip housing and cable.

  • Page 37: Removing And Installing The Battery

    EAU10122 PERIODIC MAINTENANCE AND MINOR REPAIR Removing and installing the (To install the cover) battery cover and center cover Place the cover in the original position, 2( 2) and then install the screws. Checking the spark plug The spark plug is an important engine component, which is easy to check.
  • Page 38 EAU10122 PERIODIC MAINTENANCE AND MINOR REPAIR 3. Remove the spark plug as shown, 2. Check the spark plug for electrode 2. Clean the surface of the spark plug with the spark plug wrench in- erosion and excessive carbon or gasket and its mating surface, and cluded in the owner’s tool kit.

  • Page 39: Final Transmission Oil

    EAU10122 PERIODIC MAINTENANCE AND MINOR REPAIR Final transmission oil Tightening torque: The final transmission case must be Final transmission oil drain bolt: checked for oil leakage before each ride. 18 Nm If any leakage is found, have a Gener i c 6.

  • Page 40: Cleaning The Air Filter Element

    EAU10122 PERIODIC MAINTENANCE AND MINOR REPAIR Cleaning the air filter element 2( 1) 2( 7) 2( 4) 1. Band 1. Air filter case cover 2. Screw 2. Screw 1. Seat&storage compartment 2. Bolt 2( 2) The air filter element should be cleaned at the intervals specified in the periodic maintenance and lubrication chart.

  • Page 41: Carburetor

    -nk cap(See page 3-5) adjustment. Therefore, carburetor ad- 14. Close the seat. justments should be left to Generic dealer, who has the necessary profes- 7. Apply oil of the recommended type sional knowledge and experience.

  • Page 42: Checking The Throttle Cable Free Play

    Generic dealer for help. Load your cargo firmly on vehicle and put the heaviest cargo to the center of scooter, then distribute the weight evenly from side to side.
  • Page 43 EAU10122 PERIODIC MAINTENANCE AND MINOR REPAIR Tire inspection Front tire: sidewall is cracked, have a Generic Size: dealer replace the tire immediately. 80/80-16 46J Manufacturer/model: Minimum tire tread depth (front and KENDA/K488 rear): Rear tire: Front : 1.6 mm Size: Rear: 2.0mm...

  • Page 44: Cast Wheels

    If there is air even the smallest repair to the in the hydraulic system, have a wheel. A deformed or cracked Generic dealer bleed the system be- wheel must be replaced. 1. Rear brake lever free play fore operating the motorcycle. Air in...

  • Page 45: Checking The Front Brake Pads And Rear Brake Shoes

    EAU10122 PERIODIC MAINTENANCE AND MINOR REPAIR of the wear indicators while applying the Checking the front brake pads brake. If a brake pad has worn to the and rear brake shoes point that a wear indicator almost The front brake pads and the rear brake touches the brake disc, have a G e n e r i c shoes must be checked for wear at the dealer replace the brake pads as a set.

  • Page 46: Checking The Front Brake Fluid Level

    EAU10122 PERIODIC MAINTENANCE AND MINOR REPAIR limit line, have a Generi c dealer replace make sure that the top of the mas- Checking the front brake fluid the brake shoes as a set. ter cylinder is level by turning the level handlebars.

  • Page 47: Changing The Brake Fluid

    PERIODIC MAINTENANCE AND MINOR REPAIR Changing the brake fluid Checking and lubricating the Checking and lubricating the Have a Generic dealer change the cables throttle grip and cable brake fluid at the intervals specified in The operation of all control cables and...

  • Page 48: Adjusting The Autolube Pump

    Front brake lever tenance and lubrication chart. which must be adjusted by a Generic dealer at the intervals specified in the Recommended lubricants: periodic maintenance and lubrication Front brake lever: Silicone grease chart.

  • Page 49: Checking And Lubricating The Main Stand

    If any damage is found or the front fork does not operate smoothly, have The operation of the main stand should a Generic dealer check or repair it. Check the inner tubes for scratches, be checked before each ride, and the damage and excessive oil leakage.

  • Page 50: Checking The Steering

    2. Hold the lower ends of the front fork legs and try to move them forward and backward. If any free play can be felt, have a Generic dealer check or repair the steering.

  • Page 51: Battery

    EAU10122 PERIODIC MAINTENANCE AND MINOR REPAIR CHILDREN. Battery Electrolyte is poisonous and To charge the battery dangerous since it contains sul- Have a Generi c dealer charge the bat- furic acid, which causes severe tery as soon as possible if it seems to burns.

  • Page 52: Replacing The Fuse

    If you do not fimilar to the batt- ery charging, please have a Generic dealer to charge your 3. Turn the key to “ ” and turn on battery. the electrical circuits to check if the devices operate.

  • Page 53: Replacing A Headlight Bulb

    .If a headlight bulb bur If the tail/brake light and licenes light bul remove the screw . -b does not come on,have a Generic deal -ns out,have a Generic dealer replac 2.Remove the burnt-out bulb by push -er check its electrical circuit or replace...

  • Page 54: Replacing A Headlight Bulb(For Pizza M -Odel)

    1. Front turn signal light 1. Headlight If the turn signal light bulb does not co any repair, take it to a Generic dealer, This model is equipped with halogen -m on,have a Generic dealer check its whose skilled technicians have the nec- bulb headlight .If a headlight bulb bur...

  • Page 55: Troubleshooting Chart

    Remove the spark plug and check the electrodes. The engine does not start. Have a Generic dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good.

  • Page 56: Scooter Clean And Storage

    NOTE: Generic do not suggest to use the Salt sprayed on roads in the winter may and pads and seals, due to the acidic cleaners for cleaning , but remain exist into spring.

  • Page 57: Storage

    EAU10122 SCOOTER CARE AND STORAGE Storage CAUTION: WARNING!! Short-term Make sure that there is no oil or Do not use warm water since it in- Always store your scooter in a cool, dry wax on the brakes or tires. If nec- creases the corrosive action of the place and, if necessary, protect it essary, clean the brake discs...
  • Page 58 EAU10122 SCOOTER CARE AND STORAGE spark plug electrodes while turning 3. Fill up the fuel tank and add fuel NOTE: the engine over. stabilizer (if available) to prevent the Make any necessary repairs before fuel tank from rusting and the fuel storing the scooter.

  • Page 59: Specifications

    EAU10122 SPECIFICATIONS Dimensions Engine Carburetor Engine type Manufacturer (QJ) (Weight 120 kg Air cooled 2-stroke Type x quantity Cylinder arrangement PZ19JB-2K x 1 Forward-inclined single cylinder Spark plug (s) Displacement Manufacturer/model 49.0 cm NGK/BR8HSA Compression ratio Spark plug gap 6.9:1(45Km)5.9:1(25Km) 0.6-0.7 mm Starting system Clutch...
  • Page 60 EAU10122 SPECIFICATIONS Tire air pressure Front suspension Rear turn signal light (measured on cold tires) 12 V, 10.0 W x 2 Type License plate light Telescopic fork Front 12 V, 5.0 W x 1 Spring/shock absorber type 280 kPa Meter lighting Coil spring/oil damper Rear 12 V, 2 W x 1...

  • Page 61: Consumer Information

    EAU10122 CONSUMER INFORMATION EAU26342 Identification numbers Key identification number Vehicle identification number Record the key identification number, vehicle identification number and model label information in the spaces provided below for assistance when ordering spare parts from a Generi c dealer or for reference in case the vehicle is sto- len.

  • Page 62: Warranty Information

    WARRANTY INFORMATION Please read the instruction manual carefully prior use to familiarize yourself with the correct operation of your vehicle. Please keep in mind that the instructions concerning care, maintenance, and operation of your vehicle stated must be followed in order ensure your warranty remains valid. In addition to this the following instructions will ensure a satisfactory life span.

  • Page 63: Service Plan

    SERVICE PLAN The warranty can be granted only if the vehicle has been serviced in accordance with this service plan. 1000km or 1.month 4000km or 6. month Stamp / Signature Stamp / Signature 7000KM or 12. month 10000km or 18. month Stamp / Signature Stamp / Signature 13000KM or 24.

  • Page 64: Wiring Diagram

    EAU10122 WIRING DIAGRAM...
  • Page 65 www.genericeurope.com...
