HBS82-880 HBS82-880 Automatic Drum Washing Machine Table of Contents Before using Names of Parts--------------inside front cover Matters Needing Attention--------------------1-3 Installation----------------------------------------4-5 Control Panel---------------------------------------6 Operational Functions------------------------6-7 During using Program Selection--------------------------------8 Preparation-----------------------------------------9 Washing Methods---------------------------10-11 Maintenance Maintenance -------------------------------------12 Trouble Shooting--------------------------------13 Technical Specification---- --------------------14 Wiring Circuit-------------------------------------15... -
Page 2: Names Of Parts
Names of Parts Detergent distributor Door Porthole Power supply cable Earth terminal Back plate screw (3) Drainage hose Caution and Warning symbols For your safety, any instructions in this manual with this “Warning” sign shall be strictly followed. For your safety and to prevent damages to the washing machine, any instructions in this manual with this “Stop”... -
Page 3: Matters Needing Attention
4. For your safety, dry hands before touching for 15A. Refer to a washing machine techni- the washing machine and wear appropriate cian or a Haier designated service point for footwear . power cable replacement. 5. Do not use flammable detergent or dry clean- 6. - Page 4 Matters Needing Attention 9. The washing machine should be place in 8. The washing machine must not be used in a well ventilated area maintaing a space the open or in area of high moisture as water between walls or furniture. droplets may form on electrical components, Air dry the appliance if the washing machine components become wet.
- Page 5 Matters Needing Attention 3. Never place heavy objects ,a heating 4. Do not wash foam rubber or similar sponge materials. applianceor a water container on the top panel of the washing machine. 5. Before washing, do up zippers, buttons ,laces 6.
-
Page 6: Installation
Installation As shown in figure1 remove all the packing materials (including the foam base). Remove the packing screws as shown in figure 2. The packing bolts protect the appliance from shock during transportation The steps below should be followed before using the appliance, 1. - Page 7 Power supply voltage conforms to the required value. The power supply socket and the plug of the washing machine compatible,if they are compatible ,Refer to a washing machine technician or a Haier designated service point for power cable replacement.The washing machine should be connected to an earth before use.
-
Page 8: Control Panel
Control Panel D E F A Washing program Turn the knob clockwise to set the desired wash program . Caution: Turn off the power and turn the program knob clockwise for setting desired wash program. B Washing temperature Turn the knob clockwise to set the desired temperature. Temperatures between 30 C-90 C can be setted , Cold wash is se-... -
Page 9: Operational Functions
Operational Functions D No spin button When this button is pressed, the spin cycle will be spared but water drain is still available. This function is useful for hard ironing fabrics, such as chemical fiber and wool fabrics. E Economic wash button Pressing this button will reduce the consumption of water during bleaching under intense wash. -
Page 10: Program Selection
Program Selection NOTE: “o”means softener liquid detergent canbe added when necessary. “ ”means detergent can be added when necessary. “ ”means no detergent can be added. 22.5 12.5... -
Page 11: Preparation
Preparation 2. Water supply 1. Power supply Turn on the tap ensure that the water is clear. Plug in the power supply Caution: Before staring the washing machine turn on the 220V~/50Hz. water faucrt to ensure that the water faucet and the water inlet hose are connected correctly and do not leak. -
Page 12: Washing Methods
Washing Methods 1. Laundry loading Reference loading Overalls Evenly load the laundry in the washing (cotton 950g) machine and then tightly close the door Blended of the washing machine fabric clothes Note: 1) When first using the washing ma- (800g) chine, let it run unloaded for one program to prevent the laundry from being tainted shirt... - Page 13 Washing Methods 4. Washing temperature Setting Set the washing temperature as required, otherwise, set at position * when heating is not needed. 5. Selecting the function button Select function buttons as required (refer to the directions printed on the operation panel) ,otherwise keep all the button released.
-
Page 14: Maintenance
Maintenance 1. Turn of the water and electricity supply 2. Unplug the machine during cleaning and maintenance. Use a soft cloth dampened with after every wash. Open the door to pre- vent the formation of moisture and odors. soapy liquid to clean the machine case and rub- ber components. -
Page 15: Trouble Shooting
Trouble shooting The following circumstances do not constitute problems. Do not contact the main- tenance service until the problem has been confirmed. Problem Poor connection to power supply Power failure The washing machine fails to operate Door is not properly closed Machine has not been switched on Water is not turned on Water pressure is less than 0.05MPa... -
Page 16: Technical Specification
Technical Specification Model HBS82-880 Item 220V~/50Hz Power supply Maximum working current 0.05 Water pressure (MPa) Washing power Spinning power Washing program 1950 Heating power Size (HXDXW) (mm) 850x550x595 Weight (kg) HBS82-880... -
Page 17: Wiring Circuit
Wiring Circuit I1: Power Switch EVC,EVP,EVL: Water valve I2: Economic wash Switch P1,P2: Pressure Switch I3: No spin Switch THR: Adjustable Thermastat MR: Door Lock D: Drain Pump TM: Timer motor MC,ML: Motor H:Heating Element C: Capacitance I3: No spin Switch I2: Economic wash Switch...
