Ionization smoke alarms are generally more effective at detecting flaming fires which
consumer combustible materials rapidly and spread quickly. Sources of these fires may
include paper burning in a wastebasket or a grease fire in the kitchen.
FEATURES
AC/DC Operated Ionization Type Smoke Alarm
Ionization Sensor for fast flaming
High and stable sensitivity
Quick fix mounting bracket and
simple AC connector for easy installation
Fitting and battery tamper-resist feature
Inter-connectable up to 40 units
Alarm and AC power supply indicator
Extra loud alarm sound over 85 dB
Low-battery warning indicator
Self-test button
Auto-reset when smoke clears
SPECIFICATION
Model Number:
Detection Type:
Power Source:
Standby Current (9V battery):
Alarm Current (9V battery) :
Alarm Sound Level:
Operation Temperature:
Ambient Humidity:
Interconnect Quantities:
Sensitivity to Smoke:
Compact size:
Note: This smoke alarm can only be interconnected with other VST alarms specified.
Smoke Alarm User's Manual
Please read and save this manual
IONIZATION SMOKE ALARM
MODEL: VST-IS598I
Class II Apparatus
VST-IS598I
Ionization Chamber
220-240V AC 50Hz and 9V DC Battery back-up
15uA max
30mA max
85 decibels at 3 meters
4℃to 38℃
10%-90%
up to 40 units
0.61 ~ 1.92 %/FT.OBS.
110mm diameter
V-MUL-008-B(A0)
Advertisement
Table of Contents
Related Manuals for Orientalert VST-IS5981
Summary of Contents for Orientalert VST-IS5981
- Page 1 V-MUL-008-B(A0) Smoke Alarm User’s Manual Please read and save this manual IONIZATION SMOKE ALARM MODEL: VST-IS598I Class II Apparatus Ionization smoke alarms are generally more effective at detecting flaming fires which consumer combustible materials rapidly and spread quickly. Sources of these fires may include paper burning in a wastebasket or a grease fire in the kitchen.
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION 1 . This smoke alarm requires constant 220-240V AC 50Hz mains power supply to operate properly. Backup 9V DC battery will offer additional protection in the event of power failure. This smoke alarm WILL NOT work if AC power is not connected or has failed or been interrupted for any reason. AND if the backup battery is removed, drained or improperly connected, the alarm will not work during a power failure. - Page 3 is over 12 meters (40feet) long, install an alarm at each end. At the top of the first-to-second floor stairway. IMPORTANT! Specific requirements for Smoke Alarm installation vary from state to state. Check with your local Fire Brigade for current requirements in your area. See “Recommended Locations For Smoke Alarm”...
- Page 4 least 10 feet away from these areas. 3. Near air returns or heating and cooling supply vents. Install at least 3 feet away from these areas. The air could blow smoke away from the detector, interrupting its alarm. 4. In rooms where temperatures may fall below 4℃ or rise above 38℃. 5.
- Page 5 #18 AWG or 4000 feet for #14 AWG (20 OHMS loop resistance). This smoke alarm can be interconnected with as many as 40 other DC or AC ORIENTALERT smoke alarms and/or heat alarms. Do not connect to any other type or model smoke alarms except the ones we specify.
-
Page 6: Battery Replacement
DANGER: If the alarm sounds, and smoke alarm is not being tested, the smoke alarm is sensing smoke. THE SOUND OF THE ALARM REQUIRES YOUR IMMEDIATE ATTENTION AND ACTION. MAINTENANCE AND CLEANING In addition to weekly testing, this smoke alarm requires yearly battery replacement and periodic cleaning to remove dust, dirt, and debris. -
Page 7: Troubleshooting
When this alarm is not longer required, it should be returned to supplier or Department of Health for disposal. Do not dispose of it in any other way. Manufacturer: Xiamen Vs-Top Electronics Co., Ltd. 2nd floor, No.107 Xiaguang Road, Xinyang Industrial District, Haicang ,Xiamen, China. Tel: 0086-592-6017700 Fax: 0086-592-6017711 E-mail: info@vs-top.com Website: www.orientalert.com...
Need help?
Do you have a question about the VST-IS5981 and is the answer not in the manual?
Questions and answers
How can where should I get the model no. Vst-s598ih smoke alarm where the electric connection fit on that.
The electric connection for the Orientalert VST-IS5981 smoke alarm is made through household wiring that must be pulled through the center hole of the mounting plate. The alarm is mains powered and must be connected to a constant 220-240V AC 50Hz power supply by a qualified electrician. It also includes a 9V DC battery backup.
