infrasave IEP-1520 Installation & Owner's Manual

Wall fixed electric room heater indoor use only

Advertisement

Model IEP-1520
Wall Fixed Electric Room Heater
INDOOR USE ONLY
INSTALLATION / OWNER'S MANUAL
instructions thoroughly before installing or servicing this equipment.
Improper installation, operation, adjustment, alteration, service or mainte-
nance can result in the risk of fire and electrical shock, and may cause
property damage, injury or death.
SAFETY ALERT:
This heater must be serviced only by a qualified electrician. Failure to com-
ply could result in personal injury, death, fire and/or property damage.
Do not operate this heater unless it is properly installed.
Always disconnect the heater from the power source prior to servicing.
Do not store or use gasoline or other flammable vapours and liquids in
the vicinity of this or any other hot surface appliance.
INDOOR USE ONLY - Do not use this heater outdoors
Do not use or locate this model where it could fall into a bathtub or other
water container.
Do not cover or block any surface of this appliance.
Do not touch this appliance while in operation
- Allow to cool after use.
Read the IMPORTANT INFORMATION section of
this manual before using this appliance.
SAVE THESE INSTRUCTIONS
INSTALLER: PRESENT THIS MANUAL TO THE END USER
Record the following information for future reference if service is required:
IEP-1520
Model #:
Serial #:
InfraSave IEP-1520 Manual
Read all instructions before using this heater.
WARNING
Read and understand all installation and maintenance
. Keep this manual in a secure place.
(located on heater rating label)
3154365
Conforms to ANSI/UL 2021
Certified to CAN/CSA C22.2 No.46
IM110526
RD: JUNE 2011
RL; 1A
BA

Advertisement

Table of Contents
loading

Summary of Contents for infrasave IEP-1520

  • Page 1 . Keep this manual in a secure place. INSTALLER: PRESENT THIS MANUAL TO THE END USER Record the following information for future reference if service is required: IEP-1520 Model #: Serial #: (located on heater rating label) IM110526 RD: JUNE 2011 InfraSave IEP-1520 Manual RL; 1A...
  • Page 2 This publication is the intellectual property of Schwank. This publication, or parts thereof, may not be reproduced in any form, without prior written consent from The Manufacturer. Unau- thorized use or distribution of this publication is strictly prohibited. Schwank Group Schwank and InfraSave brands 5285 Bradco Boulevard Mississauga, Ontario,L4W 2A6 2 Schwank Way Waynesboro, Georgia 30830 Customer &...
  • Page 3: Table Of Contents

    10. Heat Lamp Replacement ...........15 11. Warranty Statement...........18 FIGURE 1: Minimum Required Clearances ....7 FIGURE 2: Mounting Bracket ........8 FIGURE 3: Heater Bracket ..........8 FIGURE 4: Grounded Electrical Connection....9 FIGURE 5: Heater Parts ..........11 IM110526 RD: JUNE 2011 InfraSave IEP-1520 Manual RL; 1A...
  • Page 4: Important Instructions

    Ensure the electrical outlet is readily accessible to be able to disconnect the heater when needed. 13. Do not insert or allow foreign objects to enter the heater or any ventilation continued ... IM110526 RD: JUNE 2011 InfraSave IEP-1520 Manual RL; 1A...
  • Page 5: Save These Instructions

    21. After use, allow the heater to cool down before moving or storing. 22. These instructions belong with the heater for ready reference. Keep this manual in a safe place near the heater. “SAVE THESE INSTRUCTIONS” IM110526 RD: JUNE 2011 InfraSave IEP-1520 Manual RL; 1A...
  • Page 6: Heater Dimensions, Wiring, Specifications

    2. HEATER DIMENSIONS, WIRING, SPECIFICATIONS - IEP 1520 115 - 120 Vac, 60Hz, 13Amps IM110526 RD: JUNE 2011 InfraSave IEP-1520 Manual RL; 1A...
  • Page 7: Project Design Considerations & Guidelines

     Provide heat from at least two sides wherever possible Contact Schwank Design Services for assistance at design@schwankgroup.com. IM110526 RD: JUNE 2011 InfraSave IEP-1520 Manual RL; 1A...
  • Page 8 15 [4.6] 14.4 [4.4] 17.7 [5.4] 32 [9.8] 360 [33.4] 16.7  Refer to design guidelines on previous page.  Refer to Required Minimum Clearances: Table 2 & Figure 2, Page 10 IM110526 RD: JUNE 2011 InfraSave IEP-1520 Manual RL; 1A...
  • Page 9: Installation Instructions

    8. Do not expose the heater to rain or other moisture. 9. Since the appliance radiates heat, no obstruction or object such as furniture should be placed between the heater and the person being heated. continued ... IM110526 RD: JUNE 2011 InfraSave IEP-1520 Manual RL; 1A...
  • Page 10: Minimum Required Clearances

    If at all possible, locate the mounting bracket so that the electrical cord (8 ft [2.4 m]) can be plugged into an electrical outlet (grounded 115 - 120 Vac) without stretching the elec- trical cord taught. See important notice (previous page) regarding the use of continued ... IM110526 RD: JUNE 2011 InfraSave IEP-1520 Manual RL; 1A...
  • Page 11 12. Read and follow all warnings, and the following section on Operation to enjoy safe op- eration of the heater. IM110526 RD: JUNE 2011 InfraSave IEP-1520 Manual RL; 1A...
  • Page 12: Operating Instructions

    - have a qualified electrician install a properly grounded outlet. FIGURE 5: GROUNDED 115 - 120 Vac ELECTRICAL CONNECTION Grounded 115 - 120 Vac Outlet 3 Pronged Plug with Ground Pin IM110526 RD: JUNE 2011 InfraSave IEP-1520 Manual RL; 1A...
  • Page 13: Maintenance Instructions

    Inspect the electrical cord and plug for damage or fraying.  Do not operate the heater with a damaged cord or plug.  Have damaged parts replaced by a qualified electrician IM110526 RD: JUNE 2011 InfraSave IEP-1520 Manual RL; 1A...
  • Page 14: Heater Parts

    9. Power Cord Retainer Plate 10. Terminal Block for electrical connections 11. Power Cord with factory assembled 3 Pronged Plug 12. Lamp Retainer Clips 13. Heat Lamp - 1500 Watts - Part # JE-1500-XX IM110526 RD: JUNE 2011 InfraSave IEP-1520 Manual RL; 1A...
  • Page 15: Heat Lamp Replacement

    Six (6) Phillips screws hold the end cover in place. Remove the screws to secure storage. Step 3 Slide out the face plate at each end of heater to expose both ends of the heat lamp. IM110526 RD: JUNE 2011 InfraSave IEP-1520 Manual RL; 1A...
  • Page 16 Disconnect ground wire (electrical supply cord) from the heater body by removing the anchor screw from the eye of the ground terminal. Step 7 Slide power cord retainer plate from heater body. IM110526 RD: JUNE 2011 InfraSave IEP-1520 Manual RL; 1A...
  • Page 17 Wear gloves. Do not touch lamp with bare fingers! Oils from your skin will damage the lamp. Install the new replacement lamp and reassemble heater in reverse order of steps above. IM110526 RD: JUNE 2011 InfraSave IEP-1520 Manual RL; 1A...
  • Page 18: Warranty Statement

    Limited Warranty will be based upon the date of unit manufacture, plus thirty (30) days. Do not ship a heater back to InfraSave for repair. Contact your local supplier / installer of the heater, or a local qualified electrician for warranty service or repair.
