Fbt DLM26 User Manual page 4

MENU "UTILITY MENU" [Access by pushing the "UTILITY" button]
NAV/Param.1 Encoder
[to navigate between menus]
1 UTILITY MENU:......
<< System Utilities >>
ESC
ENTER
1.1 SYSTEM UTILITY:
<< System Mode >>
1.2 SYSTEM UTILITY:
<< System Setup >>
1.3 SYSTEM UTILITY:
<< Input Routing >>
1.4 SYSTEM UTILITY:
<< Power-On Procedure >>
1.5 SYSTEM UTILITY:
<< Delay Units
1.6 SYSTEM UTILITY:
<< Ramps on changes >>
1.7 SYSTEM UTILITY:
<< Software Version >>
2 UTILITY MENU:......
<< Program Utilities >>
ESC
ENTER
2.1 PROGRAM UTILITY:
<< Recall a Program >>
2.2 PROGRAM UTILITY:
<< Save a Program
2.3 PROGRAM UTILITY:
<< Delete a Program >>
3 UTILITY MENU:......
<< Interface Utilities >>
ESC
ENTER
3.1 INTERFACE UTILITY:
Interface Setup
4 UTILITY MENU:......
<< Security Utilities >>
ESC
ENTER
4.1 SECURITY UTILITY:
Show Parameter
4.2 SECURITY UTILITY:
Lock Unit
4.3 SECURITY UTILITY:
User Password
4.4 SECURITY UTILITY:
Enable Password
ES
C
EN
TE
R
ES
C
EN
TE
R
ES
C
EN
TE
R
ES
C
EN
TE
R
ES
>>
C
EN
TE
R
ES
C
EN
TE
R
ES
C
EN
TE
R
ES
C
EN
TE
R
ES ES
>>
C C
EN EN
TE TE
R R
ES
C
EN
TE
R
ES
C
EN
TE
R
ES
C
EN
TE
R
ES
C
EN
TE
R
ES
C
EN
TE
R
ES
C
EN
TE
R
Param.2 or Param.3 Encoder
[to chose option, then ENTER to load it;
(*) indicates the selected option]
System Mode
Mode: Standard *
Mode: Custom
System Setup [Standard Mode]
Setup: 2x2 WA+ SUB *
Setup: 2x3 WAY XOVER
Setup: 6 WAY XOVER
Input Routing
Source: Analog *
Source: Digital
Power-On Procedure
Fade-In: On *
Fade-In: Off
Delay Units
Unit: Time(ms) *
Unit: Distance (m)
Ramps on changes
Ramps: Off *
Ramps: On
Software Version
Version: V1.01 *
Recall a Program
01: Preset 01
: :
64: Preset 24
Save a Program
01: Preset 01
: :
64: Preset 24
Delete a Program
01: Preset 01
: :
64: Preset 24
Interface Setup
Source: USB
Source: RS485 *
Parameter will
be shown *
not be shown
Lock Unit
Lock: Off *
Lock: On
User Password
[ ]
Enable Password
Password: Enable
Password: Disable *
System Setup [Custom
Setup: 3 DCL *
Setup: 2x2 DCL
Setup: 4+1 DCL
(For the details about the Password Setting/Enable
and Unit Lock, , refer to the "Utility Menus
Section)
Mode]
Use"
