F250 Precision Thermometer Driver
Programmable Serial Interface Card
Series 2

USER MANUAL

Rev. P1.10
July 29, 2004
DeltaV is a trademark of Emerson Process Management, Inc © Emerson Process Management, Inc. 1998, 1999.
All rights reserved.
Printed in the U.S.A.
While this information is presented in good faith and believed to be accurate, MYNAH Technologies does not
guarantee satisfactory results from reliance upon such information. Nothing contained herein is to be construed as
a warranty or guarantee, express or implied, regarding the performance, merchantability, fitness or any other matter
with respect to the products, nor as a recommendation to use any product or process in conflict with any patent.
MYNAH Technologies reserves the right, without notice, to alter or improve the designs or specifications of the
products described herein.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F250 and is the answer not in the manual?

Questions and answers

Related Manuals for Mynah F250

Summary of Contents for Mynah F250

  • Page 1: User Manual

    All rights reserved. Printed in the U.S.A. While this information is presented in good faith and believed to be accurate, MYNAH Technologies does not guarantee satisfactory results from reliance upon such information. Nothing contained herein is to be construed as a warranty or guarantee, express or implied, regarding the performance, merchantability, fitness or any other matter with respect to the products, nor as a recommendation to use any product or process in conflict with any patent.

  • Page 2: Document Format

    Technical Support Describes who to call if you need assistance. Example Describes how to configure a device with input and output datasets. MYNAH Technologies ▪ 504 Trade Center Blvd ▪ Chesterfield, MO 63005 ▪ Telephone (636)681-1555 ▪ Fax (636) 681-1660 www.mynah.com...

  • Page 3: System Specifications

    FRSI DeltaV M3, M5, MD or Series 2 MD Controller, Power Supply and 2 wide controller carrier FRSI 8 wide I/O card carrier MYNAH Technologies ▪ 504 Trade Center Blvd ▪ Chesterfield, MO 63005 ▪ Telephone (636)681-1555 ▪ Fax (636) 681-1660 www.mynah.com...

  • Page 4: Theory Of Operation

    3. The two ports of the PSIC work independently, each connected to a single F250 unit. The following shows PSIC connectivity with F250 Precision Thermometer devices. MYNAH Technologies ▪ 504 Trade Center Blvd ▪ Chesterfield, MO 63005 ▪ Telephone (636)681-1555 ▪ Fax (636) 681-1660 www.mynah.com...
  • Page 5 POWERFUL SOLUTIONS FOR DIGITAL PLANTS MYNAH Technologies ▪ 504 Trade Center Blvd ▪ Chesterfield, MO 63005 ▪ Telephone (636)681-1555 ▪ Fax (636) 681-1660 www.mynah.com...

  • Page 6: Downloading The Firmware

    DeltaV directory on your ProPlus Workstation. The path is: \DeltaV\ctl\ProgSerial\F250 Note that you will have to create the \F250 subdirectory. The following files will be copied: MYNAH Technologies ▪ 504 Trade Center Blvd ▪ Chesterfield, MO 63005 ▪ Telephone (636)681-1555 ▪ Fax (636) 681-1660 www.mynah.com...
  • Page 7 2. Choose Upgrade I/O Modules from the drop down menu and click Next. MYNAH Technologies ▪ 504 Trade Center Blvd ▪ Chesterfield, MO 63005 ▪ Telephone (636)681-1555 ▪ Fax (636) 681-1660 www.mynah.com...
  • Page 8 4. The following dialog will appear, listing all the I/O modules in your selected Controller. The shown list of I/O modules is an example only. Your list will be different. MYNAH Technologies ▪ 504 Trade Center Blvd ▪ Chesterfield, MO 63005 ▪ Telephone (636)681-1555 ▪ Fax (636) 681-1660 www.mynah.com...
  • Page 9 5. Click the Browse button and select the DeltaV path as shown below, and then click Ok. Note that the disk drive could be C or D. MYNAH Technologies ▪ 504 Trade Center Blvd ▪ Chesterfield, MO 63005 ▪ Telephone (636)681-1555 ▪ Fax (636) 681-1660 www.mynah.com...
  • Page 10 7. If you are upgrading an existing Programmable Serial Card, the dialog will be as shown below. From this dialog, select the Programmable Serial Card I/O Module in the list. MYNAH Technologies ▪ 504 Trade Center Blvd ▪ Chesterfield, MO 63005 ▪ Telephone (636)681-1555 ▪ Fax (636) 681-1660 www.mynah.com...
  • Page 11 Once you are in the specified directory, you will need to select the following file: F250.S2F This is shown in the following dialog. MYNAH Technologies ▪ 504 Trade Center Blvd ▪ Chesterfield, MO 63005 ▪ Telephone (636)681-1555 ▪ Fax (636) 681-1660 www.mynah.com...
  • Page 12 10. Click Next and the I/O Module upgrade process will begin. After completion, you will receive the following dialog, indicating success. MYNAH Technologies ▪ 504 Trade Center Blvd ▪ Chesterfield, MO 63005 ▪ Telephone (636)681-1555 ▪ Fax (636) 681-1660 www.mynah.com...
  • Page 13 POWERFUL SOLUTIONS FOR DIGITAL PLANTS 11. This completes the I/O Module upgrade process. MYNAH Technologies ▪ 504 Trade Center Blvd ▪ Chesterfield, MO 63005 ▪ Telephone (636)681-1555 ▪ Fax (636) 681-1660 www.mynah.com...

  • Page 14: Configuration Information

    Floating Point, 1 Reads the Value current PRT Control Network Controller Name C01 - Programmable Serial Card DEV01 DS01 - Current PRT Reading MYNAH Technologies ▪ 504 Trade Center Blvd ▪ Chesterfield, MO 63005 ▪ Telephone (636)681-1555 ▪ Fax (636) 681-1660 www.mynah.com...
  • Page 15 Values Input B, then A- Control Network Controller Name C01 - Programmable Serial Card DEV01 DS01 - Input A, Input B, MYNAH Technologies ▪ 504 Trade Center Blvd ▪ Chesterfield, MO 63005 ▪ Telephone (636)681-1555 ▪ Fax (636) 681-1660 www.mynah.com...

  • Page 16: Device Configuration

    RS-232 will be used for F250 communications, unless there are distance limitations. If the F250 is more than 50 feet from the PSIC, RS-485 should be used. Lastly, select the Baud rate, Parity, Data bits and Stop bits parameters; these must match the F250 settings.

  • Page 17: Special Data

    Special Data 5: Delay in milliseconds to wait for F250 to switch channels. (3) Configuration 3 – A, B, and A-B Differential UNUSED MYNAH Technologies ▪ 504 Trade Center Blvd ▪ Chesterfield, MO 63005 ▪ Telephone (636)681-1555 ▪ Fax (636) 681-1660 www.mynah.com...

  • Page 18: Operational Check

    Programmable Serial Interface Card is functioning then the user will see the Valid Responses counter and the Async and/or Sync Transactions counters incrementing. There will not be any error counting up. MYNAH Technologies ▪ 504 Trade Center Blvd ▪ Chesterfield, MO 63005 ▪ Telephone (636)681-1555 ▪ Fax (636) 681-1660 www.mynah.com...

  • Page 19: Led Indication

    The Yellow LED should be OFF if there are no valid communications on that port. MYNAH Technologies ▪ 504 Trade Center Blvd ▪ Chesterfield, MO 63005 ▪ Telephone (636)681-1555 ▪ Fax (636) 681-1660 www.mynah.com...

  • Page 20: Terminal Number

    Port 2 – Receive Data (RxD) Unused Port 2 – Data Terminal Ready (DTR) Port 1 – Data Set Ready (DSR) MYNAH Technologies ▪ 504 Trade Center Blvd ▪ Chesterfield, MO 63005 ▪ Telephone (636)681-1555 ▪ Fax (636) 681-1660 www.mynah.com...
  • Page 21 Port 2 – TxD + Unused Port 2 – TxD - Unused Port 2 – RxD + Unused Port 2 – RxD - MYNAH Technologies ▪ 504 Trade Center Blvd ▪ Chesterfield, MO 63005 ▪ Telephone (636)681-1555 ▪ Fax (636) 681-1660 www.mynah.com...

  • Page 22: Wiring Connections

    2 - RX+ 4 - TX- 7 - RX- 6 - RX+ 3 - TX+ 8 - RX- 8 - TX- MYNAH Technologies ▪ 504 Trade Center Blvd ▪ Chesterfield, MO 63005 ▪ Telephone (636)681-1555 ▪ Fax (636) 681-1660 www.mynah.com...

  • Page 23: Technical Support

    Martin Berutti Jane Wagner You can also send us your questions via e-mail. Our address is: support@mynah.com Thank you for using DeltaV. MYNAH Technologies ▪ 504 Trade Center Blvd ▪ Chesterfield, MO 63005 ▪ Telephone (636)681-1555 ▪ Fax (636) 681-1660 www.mynah.com...
