Page 1: User Manual
User Manual Night Vision & Remote Operation for Wireless Pan & Tilt IP Camera Model: PT308IP, PT312IP, PT315V, PT324IP, PT325IP, PT331V (Applicable for Windows XP, Windows Vista, Windows 7 and Windows 8) -
Page 2: Product Introduction
Packing Contents ● Sineoji IP Camera User Manual ● Power Adapter ● ● Mounting Bracket Ethernet cable ● ● Software CD ● Mounting Bracket 1. Product Introduction 1.1 Safety Instructions (1). Use the proper power source. Do not use this product with a power source exceeding the specified voltage (100-240V AC). -
Page 3: Product Specifications
1.2. Product Specifications High sensor CMOS Adopt optimized MJPEG video compression algorithm, realize high-definition images transmission in narrow bandwidth; Maximum support 4 users viewing at the same time, no limit for users if using forwarder Server function Built in Web Server, convenient for users to use standard browsing for ... - Page 4 1.4. Product Views 1.4.1 Front View...
- Page 5 1.4.2 Rear View Figure 1.2 Audio Out LAN PORT: RJ-45 interface. Antenna: Power input interface: connect direct current 5V Power TF Card Socket: Only applicable for models PT312IP, PT315V, PT325IP, PT331V ...
-
Page 6: Hardware Installation
1.5 Hardware Installation Follow the steps below to set up your camera hardware. Make sure to follow each step carefully to ensure that the camera operates properly 1. Install the Wi-Fi antenna (For wireless model). 2. Plug the power adaptor into camera 3. -
Page 7: Software Operation
2. Software operation 1.1 Search Tool Software 1.1.1 Search the IP address of the camera. Double click the Icon “ ” run this IP address search tool. Figure 2.1 Note: The software searches IP Servers automatically over LAN. There are 2 scenarios: 1. -
Page 8: Real-Time Video Demonstration
Make sure the “Subnet Mask”, “Gateway”, “DNS Server” is the same as your router or your current computer. 4. If you do not know how to configure your camera’s IP address. You can click “Update” button. The Search Tool software will assist you to configure a usable IP camera automatically. 2.1.2 Configuration of the Network Once your camera’s IP address’... - Page 9 Figure 3.1 Username: admin Password: NO PASSWORD. Input the correct user name and password, the sign In interface will pop-up. There are three modes to login (figure 3.2). Figure 3.2 (1) ActiveX Mode (For IE Browser): available in IE6.0 or above explorer (2) “RTSP Stream Mode”: available in Firefox, Safari, and Google browser.
-
Page 10: View Via Ie Browser
3.2. View via IE Browser. Select Active Mode (For IE Browser), and sign in. The first time when you login to the camera, you may be prompted with an ActiveX script as shown below. Please download the Ocx(or run in CD) and install, otherwise, the camera’s live video will not appear. - Page 11 Figure 3.4 Figure 3.3 Windows XP system Note: If there is still no live video after running ActiveX, please try to enable the ActiveX options of IE security settings, please do the follow steps: 1. Close the firewall of your computer. 2.
- Page 12 Figure 3.5 Figure 3.6 In Addition: you can also click “start” menu->“Internet Explorer”, choose “Internet attributes “ to enter, or via “Control Panel” ->“Internet Explorer”, enter to Security setting. 3. If there is still no image, please close your anti-virus software, and then try step 1 & 2 again.
-
Page 13: View Via Safari, Firefox, Google Browser
4. If the Active X is enabled, but yet with no live video with only a Red Cross in the center of the video screen, check the device status light. If it is yellow instead of green, please change the port number. Do not use port 80, enter other port such as99, 199 etc. Figure 3.7 NOTE: Make sure that the firewall or anti-virus software does not block the software or ActiveX. -
Page 14: Main Menu Interface Introduct Ion
The Control Interface in this mode is as bellow: 3.4. Main Menu interface introduct ion Active Mode(For IE Browser)” Interface: Figure 3.8... - Page 15 The Pan/Tilt Feature only works when the cameras have this Pan/Tilt function. This option enables log detection. After the online user clicks on this button, a log is entered into the camera’s Log Data documenting the IP address of the users who have accessed the IP camera.
-
Page 16: Administer Setting Instruction
These options enable single view, quad screen view, or 9 screen view: This function serves no purpose unless you have more than one camera connected and configured to your interface. * Please refer to section 8.1.1 Multi-Device Settings* 3.5. Administer Setting Instruction When you login as an Administrator, you will have the Administrator privileges. - Page 17 Figure 3.9 Figure 3.10...
-
Page 18: Network Settings
Network Settings 3.5.2 Figure 3.11 This sector is designed for DHCP and IP configuration and port forwarding. If you manually assign an IP address, please fill in the respective IP address, subnet mask, gateway, DNS server, Http port; 3.5.3 Wireless Settings 1. -
Page 19: Ddns Setting
Figure 3.12 3.5.4 Dynamic DNS Setting (DDNS) 3.5.4.1 DDNS Setting: (1): Click > “DDNS Service Settings”. Figure 3.13 (2): Choose the DDNS; there are 4 kinds of options: (1): Manufacturer’ DDNS: We provide a free DDNS: vipcam.org. This domain is provided by manufacturer. - Page 20 Figure 3.14 (2): The Third Party DDNS: This domain is provided by the 3rd party, such as Dyndns, Oray, 3322. If you use the third party DDNS, please choose the server you require, such as“3322.org” or“ dyndns.org” as below: Figure 3.15...
-
Page 21: Port Forwarding Settings
Figure 3.16 You have to register an account first, note down the username, password, host, and enter it. Note: Only one DDNS can be chosen, for example, should you use manufacturer’s DDNS, the 3rd party will not work. 3.5.4.2 Port forwarding settings: 1: Setting the IP address of the camera The default IP address of the camera is : Http://192.168.1.99:99... - Page 22 3.5.6 E-mail and FTP service Settings Figure 3.31 The above settings are a preparation for the alarm function. The sender should be entered the sender’s email address，recipient 1、2、3、4 is the recipient E-mail address；SMTP server will be the sender email SMTP server，e.g. the sender email address is abc@163.com，enter mail.163.com.
-
Page 23: Alarm Service Settings
Figure 3.32 The above setting is identical to the Mail Server Settings when motion detection alarm is triggered. It also sends images to the respective ftp server. Enter the FTP server, FTP port, FTP user, FTP password and the FTP upload directory. FTP mode has two options: PORT and POSV. If it requires a quick image upload, select it;... -
Page 24: Ptz Settings
Figure3.33 3.5.8 PTZ Settings This is catered for the Pan and Tilt function. The self-checking function can be cancel, but you will lose the presetting bit function. PTZ speed can be adjusted here. Figure 3.11... -
Page 25: Record & Capture Path
3.5.9 Record & Capture Path The IP Camera allows you to record video and capture images to your computer. Enter the desired record and capture directory and path that will be appropriate for you. Record file length (MB), Record time length(Minute), Reserved disk space(MB), Record cover. Figure 3.34 Record cover denotes when the specified disk is full, existing recording files will be deleted automatically. - Page 26 3.5.10.2 Reboot Device Selecting Reboot, a window appears, wait for 60 seconds before the camera starts to reboot. 3.5.10.3 Upgrade Firmware & WEB User Interface Do not upgrade the firmware unless you are encountering specific issues that need to be addressed and rectified via a firmware fix.
- Page 27 Video can be playback online via the browser. Press “Enter “button, choose the last sign in mode. You will see: 3.5.12 Back When you have completed inputting the parameters settings, hit the back button will bring you to the camera live home page.
-
Page 28: Warranty
Warranty Product carried a warranty of 2 years from the date of purchase. Warranty registration can be done via online at http://www.sineoji.com/support/product-registration. Ensure a copy of the proof of purchase is submitted online during the registration process. The Warranty will not apply in respect: a. - Page 29 To the full extent permitted by law: Sineoji will not be liable for any loss, damage or alterations to third party hardware, software, programs, data and/or information stored on any media or any part of the Product, no matter how occurring; or for any loss or damage arising from loss of use, loss of profits or revenue, or for any resulting indirect or consequential loss or damage.
