CFS RE1 Assembly Manual

_r_ts
1 Front Foot Tube
2 Upper Handlerbars
2 Lower Handlerbars
2 Pedal arms
2 Guide Rails
1 Console Mast
1 Console Mast Boot
1 Power Supply
2 Pedal Arm Sleeves
2 Crank Boots
2 Front Upper Handlebar Covers
2 Back Upper Handlebar Covers
1 Hardware Pack (contents listed below)
Tools (included)
• 5mm Allen Wrench
• 6mrnAHen Wrench
• Phillips Screw Driver
• 13/17mm Flat Wrench
H A R D W A R
\
\
K) 35mm Washer
(2 Pre-Attached)
Quantity: 2
G) 25ram Teflon Washer
Quantity: 4
D) 70ram Bolt
Quantity: 1
I) 17ram Nut
Quantity: 2
E
N) 22mm Wavy Washer
Quantity: 2
A) 20mm Bolt
Quantity: 2
L) 8mm screw
Quantity: 4
Q) 20ram screw
Quantity: 2
B) 15mm Bolt
Quantity: 2
O) 28 mm Washer
Quantity: 2
M) 25mm Washer
Quantity: 2
F) 13ram nut
Quantity: 1
E) Arc Washer Quantity: 3
C) !2mm Bolt
P) 15mm screw (2 Pre-Attached)
Quantity: 4 Quantity: 6
(3
