- Page 1 802A Manual Operation and Owner’s Manual for the 802A Model Automatic Mixer Printed in U.S.A. ____________________________________________________________________ Ivie Technologies Inc. 1605 NW State St. Orem, UT 84043 Tel: 801-766-7600 Fax: 801-766-8282 Email: ivie@ivie.com Website: www.ivie.com...
-
Page 2: Rear Panel Controls
802A, great emphasis was placed on simplicity of setup and ease of operation. The 802A can be set up using the front and rear panel controls, or it may be set up via a computer. Please note that a computer is NOT required at any time to either setup or operate the mixer. - Page 3 The mixer can be locked and unlocked with an ANK-1 Audio Net key, Ivie’s special “electronic key,” or by a computer with Audio Net™ Software. ™ Automatic/Manual Switch This switch selects an optional mode of operation when a remote control is connected to the 802A.
-
Page 4: Rear Panel Connections
A slide switch located inside the mixer sets the input for either mic level or line level input signals. As shipped from the factory, the inputs of the 802A are set for mic level. -
Page 5: Front Panel Controls
All of the front panel controls of the mixer can be remoted. All that is required is a standard, 10k pot which is connected to the remote control terminals on the rear panel of the 802A. One 10k pot controls one channel. Ivie Technologies manufactures a complete remote control, the model RMA-6, that can be used with the 802A, or individual remote controls can be connected to only those channels requiring remote control. - Page 6 Setting Up the Mixer The 802A is very easy to install and set up. There are no gain trim or threshold controls to be set. The automatic mixer portion of the mixer is set by adjusting the channel level controls as would be done for normal mixer operation.
-
Page 7: Specifications
Specifications Input channels 1-4: Transformer, balanced and isolated. Switchable between microphone or line input levels. Microphone input impedance: 1200 . Compatible with microphone sources of 600 or less. Line input impedance: 30k . Low cut filter: ---------- 6dB/octave, -3dB @ 100Hz Noise: ------------------- (EIN 20Hz to 20kHz) -125dBV (200 source) Sensitivity: -------------- 0.4mv in for +18dBm out Input Overload: --------- -9dBV (with 14 dB pad enabled). - Page 8 Ivie Technologies 802A Automatic Mixer ON- AUX1 TO PH PWR - ON COMMON AUX OUT Ground 14DB PD - IN MSTR AUX OUTPUT +RMT ON- LAST ON Link LEVEL HP FLT - IN See Manual AUTOMATIC AUDIO MAIN AUX 2...
