Clean/Overdrive
1. Clean/Overdrive Switch - LED on indicates OD Channel -- LED off indicates Clean Channel
2. Overdrive 1 / Overdrive 2 Switch
3. Solo Boost Switch
- LED on indicates Solo Volume control activated
Footswitch connections -- Two 1/4" TRS plugs on a 25' cable
After unpacking your new amp, Turn the amp around so the back faces you. Remove the four screws to
remove the back cover of the amp. You will find the tubes packaged tightly on the left side of the Amp.
Carefully remove the package and remove the tubes. You will have three preamp tubes and four power
Un-box the Power section tubes. Keep the boxes!! They are marked with tube ratings! You will see on the
base of the tube there is a "key" guide to align the tube into the socket. Starting with the tube socket on the
far right, Line up the key with the slot in the socket, From the top of the tube, firmly press
the tube into the socket until the base of the tube is flush with the Socket. Insert these tubes into the tube
sockets. The tubes are matched so you may install them in no particular order. After you install a tube
carefully hold the tube spring retainer and stretch it over the top of the tube and center it. These are light
metal and can bend. If you happen to bend them you can shape it to the tube while its installed. Reinstall
Please Check the Voltage selector on the back for proper Voltage selection! Please check the volume
control levels on all channels before powering on. After you plug in the amplifier, Flip the power switch
down to turn on. Wait for a minute for the tubes to warm, then turn on the Standby switch. The Amp is ready
This Amplifier will get VERY loud. Remember you only have one set of ears!
against failure of materials and workmanship. No other warranty applies. Tubes, transformers and speakers are
warranted for a period of ninety days. This warranty applies only if the amplifier has not been damaged by
accident, misuse or as a result of repair or modification. Splawn reserves the right to make any design changes
without notice or obligation to incorporate these changes in products previously purchased.
All warranty repairs are to be done by Splawn Amplification.
Overdrive 1/ Overdrive 2
Nitro Footswitch Operation
- LED on indicates OD2 gain boost -- LED off indicates OD1
Setting up the Amplifier:
section tubes.
Power Section Tubes:
the rear cover and get ready to fire this monster amplifier to life!
WARNING:
for explosive guitar sounds!
Dimensions
29" Wide, 11.5" Tall, 8.5" Deep, 50lbs
Limited Lifetime Warranty.
New Amplifiers are lifetime warranted to the original purchaser
Splawn Amplification
115 South Gaston St.
Dallas, NC 28034
Solo Boost
