Nitro Front Panel Controls - Splawn Amplification Nitro Owner's Manual

Thank you for purchasing your new Splawn amplifier. We have put together a little information that will help you
understand the amp and all of its functions. All of our amps are built in our shop in Dallas NC right here in the USA. We
build all of our speaker cabs and head boxes in house. Some parts of the amplifier are out sourced such as the
chassis's, circuit boards and transformers. The transformers are custom wound by Heyboer and are also made in the
USA. We hope that this amplifier will give you years of tonal pleasure.
_______________________________________OVERDRIVE CHANNEL_______________________________
POWER STANDBY RESONANCE PRESENCE BASS
ON ON
1. Power Switch -Switches main AC power on or off
2. Standby Switch
3. Resonance Control -Low frequency control on the output section
4. Presence Control
5. Bass Control -Controls the bass frequency on the overdrive channel
6. Middle Control -Controls the middle frequency on the overdrive channel
7. Treble Control -Controls the treble frequency on the overdrive channel
8. Solo Volume -Switchable volume control on the overdrive channel activated by the footswitch
9. Master Volume -Controls the overall volume of the overdrive channel
10. Gain Control -Controls the amout of pre-amp gain to the overdrive channel
11. Clean Bass Control
12. Clean Treble Control
13. Clean Volume Control
14. Clean Gain Control
MIDDLE
-Switches the high voltage on or off
-High frequency control on the output section
-Controls the bass frequency on the clean channel
-Controls the treble frequency on the clean channel
-Controls the overall volume of the clean channel
-Controls the amount of pre-amp gain to the clean channel
TREBLE SOLO VOLUME
N
Splawn
by
ITRO

Nitro Front Panel Controls

Splawn Amplification
115 South Gaston St.
Dallas, NC 28034
704-922-0020
www.splawnguitars.com
_____________CLEAN CHANNEL_______________
GAIN BASS TREBLE VOLUME GAIN
