- Page 1 IFS SFP Tranceivers User Manual P/N 1069181 • REV 02.00 • ISS 22AUG11...
- Page 2 Copyright © 2011 UTC Fire & Security. All rights reserved. Trademarks and Interlogix, IFS SFP Tranceivers Brand and logo are trademarks of patents UTC Fire & Security. Other trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products.
- Page 3 Safety Notices The fiber optic SFP transceiver modules are equipped with a Class 1 laser, which emits invisible radiation. Read the following safety warnings carefully. Class 1 Laser Product Complies with FDA Regulation 21 CFR 1040.10 and 1040.11 Class 1 radiation is present when the device or system is powered up.
-
Page 5: Table Of Contents
Content Overview 1 Checklist 2 Installing an IFS SFP Module 3 Connecting the fiber cable 3 Removing the SFP transceiver 4 SFP Specifications 5 Appendix A 8 Fiber Optical Cable Connection Parameters 8 IFS SFP Tranceivers User Manual... -
Page 7: Overview
SX/LX mini-GBIC interface. This user guide provides an overview of the various IFS SFPs (also known as mini-GBIC) transceiver modules available from Interlogix. This user guide also provides instructions for installing, connecting and removing these transceivers. These SFP transceiver modules are hot-pluggable, which means you can insert and remove these modules into any IFS network equipment with a mini-GBIC port without interrupting the host system. -
Page 8: Checklist
The SFP package should contain the following items: • The SFP Transceiver Module x1 • This User Manual x1 If any items are missing or damaged, please consult Interlogix or the dealer/distributor from whom you purchased your SFP transceiver module. IFS SFP Tranceivers User Manual... -
Page 9: Installing An Ifs Sfp Module
S30 Series and S35 Series optics operate with single mode fiber. LC type fiber connectors are required. Connecting the fiber cable 1. Insert the duplex LC connector from the network fiber cable into the SFP transceiver. IFS SFP Tranceivers User Manual... -
Page 10: Removing The Sfp Transceiver
Never pull out the SFP transceiver module without using the pull handle or the push bolts on the module. Directly pulling out the SFP module with force could damage the SFP module and mini-GIBIC slot of the network device. IFS SFP Tranceivers User Manual... -
Page 11: Sfp Specifications
(dBm) (dBm) (dBm) Single 20km 0 to + 50C S20-1SLC/A-20 1310/1550nm -14 ~ -8 Mode (12mi) (32 to 122F) Single 20km 0 to + 50C S25-1SLC/B-20 1550/1310nm -14 ~ -8 Mode (12mi) (32 to 122F) IFS SFP Tranceivers User Manual... - Page 12 (6.2mi) (-40 to 167F) Single 30km 0 to + 50C S30-2SLC-30 1310nm -2 ~ +3 Mode (18.6mi) (32 to 122F) Single 30km -40 to +75C S35-2SLC-30 1310nm -2 ~ +3 Mode (18.6mi) (-40 to 167F) IFS SFP Tranceivers User Manual...
- Page 13 0 to + 50C S30-1SLC/B-60 1490/1310nm 0 ~ +5 Mode (37mi) (32 to 122F) * Note: High Power Optic. There must be a minimum of 5dB of optical loss to the fiber for proper operation. IFS SFP Tranceivers User Manual...
-
Page 14: Appendix A
Fiber Type Cable Specification 1000Base-SX (850nm) Multi-mode 50/125 m or 62.5/125 m 1000Base-LX (1310nm) Single mode 9/125 m 1000Base-LX (1550nm) Single mode 9/125 m Multi-mode 50/125 m or 62.5/125 m 100Base-FX (1310nm) Single mode 9/125 m IFS SFP Tranceivers User Manual...
