Summary of Contents for Interlogix D7120
- Page 1 D7120 D7120-R3 D7120WDM D7120WDM-R3 D7130WDM D7130WDM-R3 IFS Fiber Module Installation & Operation Instructions P/N 1062848 • REV B • ISS 01AUG11...
- Page 2 D7130WDM OPTICAL ETHERNET TRANSCEIVER FIBER IN/OUT International Fiber Systems Incorporated -- AUTO NEGOTIATE 10 BASE -T / 100 BASE - TX -- SPEED -- DUPLEX FIBER LINK FIBER LINK CONTACT AUTO NEGOTIATE ON/OFF POWER POWER +12 VDC - 1 Simplex single mode fiber optic cable D7130WDM OPTICAL ETHERNET TRANSCEIVER...
- Page 3 D7100 Fiber Link LED illuminates Auto Negotiate ON/OFF LED illuminates Power LED illuminates DOWN SWITCH # Auto Negotiate Switch Speed Switch Duplex Switch FULL HALF Power Connector Fiber Link Contact Connector 10 Base-T / 100 Base-TX Connector Fiber Optic Connectors (1 or 2 depending on model number)
- Page 4 D7100 NOTES Descriptions of Operation a. Fiber Link LED OFF = No fiber connection GREEN = Fiber connection b. Auto-negotiate LED OFF = Auto-negotiate off GREEN = Auto - negotiate on c. - Default, recommended operation mode is auto - negotiate ON. When NOT using auto - negotiate mode, a cross over cable must be used for the copper link segment.
- Page 5 FCC Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesirable operation. Changes or modifications not expressly approved by International Fiber Systems, Inc.
- Page 6 Note: Be ready at the equipment before calling. Online Another great resource for assistance with your Interlogix product is our online publication library. To access the library, go to our website at the following location: http://www.interlogix.com/transmission Many Interlogix documents are provided as PDFs (portable document format). To read these documents, you will...
- Page 7 Product Disassembly Instructions for WEEE Per European Directive 2002/95/EC Waste Electrical and Electronic Equipment Required Tools: One number 2 Phillips (crosstip) screwdriver. One number 2 flat screwdriver. For the enclosed box version: 1. Locate and remove box cover securement screws. Usually, but not limited to, at least 4 screws.
- Page 8 Copyright © 2011 UTC Fire & Security. All rights reserved. Trademarks and Interlogix and IFS names and logos are trademarks of patents UTC Fire & Security. Other trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products.
