Skywalker SWTCS13 User Manual

Trampolines
Hide thumbs
Table of Contents

Advertisement

Quick Links

User's Manual
Model ______________
SWTCS13
WARNING
Read all precautions and
instructions in this manual before
using this equipment. Save this
manual for future reference.
Maximum user weight 275 lbs
IMPORTANT
Trampoline and Enclosures are
susceptible to winds. Be sure to
secure your trampoline and enclosure.
Wind Damage is not covered in the
warranty of your trampoline

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SWTCS13 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Skywalker SWTCS13

Summary of Contents for Skywalker SWTCS13

  • Page 1 User’s Manual Model ______________ SWTCS13 WARNING Read all precautions and instructions in this manual before using this equipment. Save this manual for future reference. Maximum user weight 275 lbs IMPORTANT Trampoline and Enclosures are susceptible to winds. Be sure to secure your trampoline and enclosure.

  • Page 2: Table Of Contents

    Model____________________ SWTCS13 A serial decal is found on one of the trampoline legs. Model number decal tag is located on the jumping mat. CONTENTS Important Precautions...........3 Warning Label Placement........4 Before You Begin..........4 Trampoline Safety Information......5 Enclosure Safety Information.......6 Methods of Accident Prevention......7 Use and Instructional Material......8...

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read and follow all of the warnings, precautions, and instructions in this manual before you use the trampoline enclosure. Warnings and instructions for care, maintenance, and use of this trampoline enclosure are included to promote safe, enjoyable use of this equipment. It is the responsibility of the owner and supervisors of the Do not attach anything to the enclosure barrier that is not a trampoline and enclosure to make sure all users obey the safety...

  • Page 4: Warning Label Placement

    Thank you for choosing your Skywalker Trampolines brand Trampoline. The Skywalker Trampoline square Trampolines are designed and crafted to provide many years of fun and fitness. This trampolines comes equipped with warnings and instructions for the assembly, care, maintenance, and use of the trampoline. This information must beread by all trampoline supervisors and users before any person is allowed to jump on the trampoline.

  • Page 5: Trampoline Safety Information

    TRAMPOLINE SAFETY INFORMATION In trampoline use, as in all active recreational sports, participants can be injured. However, there are steps that can be taken to reduce the risk of injury. In this section, primary accident patterns are identified and the responsibilities of supervisors and jumpers in accident prevention are described.

  • Page 6: Enclosure Safety Information

    ENCLOSURE SAFETY INFORMATION NEED FOR TRAMPOLINE ENCLOSURE SAFETY A trampoline enclosure is a recreational product. The information on this page and on pages identify important safety precautions. The precautions are not all-inclusive, because an enclosure can be used in ways that this manual cannot cover completely. To prevent pinches and cuts during enclosure use, a frame pad must be installed on the trampoline (See the trampoline manufacturer’s instructions).

  • Page 7: Methods Of Accident Prevention

    METHODS OF ACCIDENT PREVENTION The Supervisor's Role in Preventing Accidents It is the responsibility of the supervisors of trampoline users to provide knowledgeable and mature supervision. They need to know and enforce all of the rules and warnings printed in this manual to minimize the likelihood of accidents and injuries.
  • Page 8 • Wear clothing that does not have drawstrings, hooks, loops or anything else that could get caught while using the trampoline/enclosure and result in entanglement or strangulation, or both. • Do not attach anything to the netting that is not a Skywalker Trampolines approved accessory or part of the of the trampoline enclosure.

  • Page 9: Use And Instructional Material

    GETTING ON AND OFF THE TRAMPOLINE Climb onto and off of the trampoline. Do not jump onto or off of it. Do not use the trampoline as a springboard to jump to other objects or places. ENTERING AND EXITING THE TRAMPOLINE ENCLOSURE Un-zip and un-clip opening and place one knee on the frame pad and climb head first through the door and crawl to the center of the mat.

  • Page 10: Instructional Program And Model Lessons

    INSTRUCTIONAL PROGRAM AND MODEL LESSONS The following lessons are examples of an instructional program. They should follow a complete discussion and demonstration of body mechanics between the supervisor and the student(s). See pages 11 and 12 for descriptions of basic trampoline skills. Lesson 1 1.

  • Page 11: Basic Trampoline Skills

    BASIC TRAMPOLINE SKILLS Fundamental Bounce Knee Drop 1. Start from a standing position with your head erect 1. Start bouncing from a standing position, keeping your and your eyes on the frame pad. eyes on the frame pad. 2. Swing your arms forward and up in a circular motion. 2.
  • Page 12 BASIC TRAMPOLINE SKILLS Seat Drop Front Drop 1. Land in a sitting position with your legs parallel to the 1. Start from a low bounce and land on the mat in a mat. prone position. 2. Place your hands on the mat beside your hips. 2.

  • Page 14: Assembly

    ASSEMBLY ASSEMBLY (PUTTING THE TRAMPOLINE AND ENCLOSURE TOGETHER) IMPORTANT ASSEMBLY INFORMATION • Need phillips screw driver (included with trampoline) and 2 adjustable wrenches (for putting the trampoline together). A rubber mallet is also recommended to make assembly easier. • Assembly requires two adults. Keep children away from the trampoline and enclosure until they are completely put together. •...
  • Page 15 2. Assemble Male curved Leg Brace (6) to the Female leg (5) before assembling the rest of the legs. Secure Female leg (5) sections with #8 screws (12). Insert one end of the Leg Post (4) into the Leg Braces (5,6) assembled above.
  • Page 16 Gold Color Springs 5. Attach the Springs as follows: Hook one end of a Spring into a V-ring. (See the inset drawing.) Hook the Spring tool to the free end of the first Gold Color Spring. Using the Spring Tool pull the first Spring until it Springs reaches the frame.
  • Page 17 Safety Note: Do not use the trampoline without the Frame Pad. The Frame Pad comes in 2 pieces. The Frame Pad is designed to reduce the possibility of injuries due to jumpers coming in contact with the trampoline frame. If you do not have a Frame Pad, contact your dealer to obtain one.

  • Page 18: Enclosure Assembly

    Enclosure Assembly Slide an enclosure foam (8) onto the top curved tube (6). Lay two L-corner tubes(5), the top curved tube(6) and two middle tubes(7) on the ground as shown. Attach together using#8 screws(3) one by one, don’t tighten yet. Note: Top curved tube should be curved down.
  • Page 19 4. Locate one strap(11) with D-rings to the upper edge of the Netting. Lift the end of the strap(11) and insert it small belt through the small belt sewn on the upper edge of the netting,see the right drawing. Then Lift D-ring and hold it close to an L-tube(5)as shown in Inset Drawing A.
  • Page 20 Warning: Take care not to fall, use a ladder if needed. Attach the Netting (10) to the other L-tubes (5) and Inset Drawing A curved tubes(6) with the other Straps (11) in the same manner. 5. Tighten the Straps (1 1) attaching the Netting (10) to the L-tubes (5) and curved tubes(6) .

  • Page 21: Care And Maintenance

    CARE AND MAINTENANCE TRAMPOLINE ENCLOSURE CARE AND MAINTENANCE To avoid damage to the trampoline and enclosure, do not allow pets or animals inside the enclosure. Appropriate shoes should be worn inside the enclosure to reduce wear to the trampoline mat (bed). Follow the tram- poline manufacturer’s recommendations.
  • Page 22 WARNING TRAMPOLINE AND ENCLOSURE CARE AND MAINTENANCE Care To avoid damage to the trampoline and enclosure, do not allow pets or animals inside the enclosure. The trampoline is intended to be used by one person at a time who weighs not more than 275 pounds. The user should be either barefoot, wearing socks, or wearing gymnastic shoes.

  • Page 23: Exploded Drawing And Parts List

    EXPLODED DRAWING AND PARTS LIST FOR TRAMPOLINE Qty. Description Gold Color Springs Corner Frame Pieces Frame Pads Frame Tube with Square hole User 's Manual and Safety Placard Middle Tube #8 Screws Leg Posts M10X80 Bolt Female Curved Legs M10 Nut Male Curved Legs Bolt End Cap Stitched Bed with 84 V-Rings...
  • Page 24 EXPLODED DRAWING AND PARTS LIST FOR ENCLOSURE . y t . y t Bolt Foam t - f i t t a t t s ’ r Specifications are subject to change without notice. ORDERING REPLACEMENT PARTS To order replacement parts, visit our web site at www.skywalkertrampolines.com or call our toll-free Customer Care Hot Line at 1-866-603-Jump (5867), Monday through Friday, 8 a.m.

  • Page 25: Limited Warranty

    LIMITED WARRANTY Skywalker Holdings, LLC warranties its trampoline products to be free from defects in material and workmanship under normal use and service conditions. The steel frame is warranted for one (1) year after the date of purchase. All other parts are warranted for ninety (90) days after the date of purchase. Wind or weather damage is not warranted. All warranty coverage extends only to the original retail purchaser from the date of purchase.
