Force 10 CMG Router User Manual

Cmg router menu-driven user interface
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CMG Router
M
-D
U
I
ENU
RIVEN
SER
NTERFACE
U
M
SER
ANUAL
Part Number: 770-0080-BL
Product Release: 2.97
August 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CMG Router and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Force 10 CMG Router

Summary of Contents for Force 10 CMG Router

  • Page 1 CMG Router RIVEN NTERFACE ANUAL Part Number: 770-0080-BL Product Release: 2.97 August 2009...
  • Page 2 Technical Assistance Center: Force10 Networks, Inc. E-mail: access-support@Force10Networks.com 350 Holger Way Phone: (US) 866-887-4638 San Jose, CA 95134-1362 Phone (International/Direct): 1-707-665-4355 Phone: +1 (866) 571-2600 or +1 (408) 571-3500 www.Force10Networks.com Supporting Software Versions: CMG Router Release 2.97 Adit 600 Controller Release 10.1.1...

  • Page 3: Warranty Procedure

    REFACE Preface Warranty Force10 Networks, Inc. warrants to BUYER that Product Hardware will be free from substantial defect in material and workmanship under normal use in accordance with its Documentation and given proper installation and maintenance for period of five years from the date of shipment by Force10 Networks.
  • Page 4 Force10 Networks Customer Support Center via telephone during the warranty period and during normal business hours. Normal business hours for Force10 Networks Customer Support Center are 7:00 a.m. to 6:00 p.m. Mountain Standard Time, Monday through Friday, excluding weekends and standard Force10 Networks recognized holidays. CMG Router - Release 2.97...

  • Page 5: Limitation Of Warranty & Limitation Of Remedies

    PRODUCTS DURING AND AFTER THE WARRANTY PERIOD. IN NO EVENT WILL FORCE10 NETWORKS BE LIABLE FOR ANY SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, LOSS OF DATA, OR COMMERCIAL LOSSES EVEN IF FORCE10 NETWORKS HAS BEEN ADVISED THEREOF. CMG Router - Release 2.97...

  • Page 6: Warranty Product Returns

    4355 (International/Direct) for RMA number, repair/warranty information and shipping instructions. Be prepared to provide the following information: Force10 Networks serial number(s) from the system chassis or circuit card(s) Name of distributor or dealer from which you purchased the product Description of defect CMG Router - Release 2.97...

  • Page 7: Notices

    DAMAGE IF THE HAZARD IS NOT AVOIDED NOTE: A Note indicates information to help you understand how to perform a procedure or how the system works. Notes should be read before performing the required action. CMG Router - Release 2.97...
  • Page 8 Preface viii CMG Router - Release 2.97...

  • Page 9: Table Of Contents

    ABLE OF ONTENTS Table of Contents Preface Warranty ........... iii Warranty Procedure .
  • Page 10 AIS Feature..........3-54 CMG Router - Release 2.97...
  • Page 11 NAT Bypass Subnets ........5-30 CMG Router - Release 2.97...
  • Page 12 Address Tables ..........9-11 CMG Router - Release 2.97...
  • Page 13 Alarms ........... . A-5 CMG Router - Release 2.97...
  • Page 14 Clear Alarm ......... . . C-11 Glossary Index viii CMG Router - Release 2.97...
