Emerald Spa Great Lakes Spa 2008 Owner's Manual

Indoor - outdoor spa

Advertisement

Owner's Manual
2008
Rev 2.22.07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Great Lakes Spa 2008 and is the answer not in the manual?

Questions and answers

Summary of Contents for Emerald Spa Great Lakes Spa 2008

  • Page 1 Owner’s Manual 2008 Rev 2.22.07...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Important Safety Instructions .......................... …….. Location and Installation ..........................…….. Spa Set Up ..............................…….. Spa Operation ..............................…….. Spa Care and Maintenance ........................... …….. Winterizing, Ozone ............................…….. Water Care, Consumer Notice ........................…….. Troubleshooting ............................. …….. GFCI Load Center Wiring ..........................
  • Page 3: Save These Instructions

    12. WARNING– Do not use a spa or hot tub immediately following strenuous exercise. 13. WARNING– Prolonged immersion in a spa or hot tub may be injurious to your health. 14. CAUTION– Maintain water chemistry in accordance with manufacturer’s instruction. 15.
  • Page 4: Location And Installation

    LOCATION AND INSTALLATION Your Great Lakes Spa has been conveniently designed for use in either an indoor or outdoor setting. While selecting an appropriate location for your spa, there are important things to consider. Indoor Use Only • Humidity will not likely be a problem. However, just like in your bathroom, an exhaust fan would be a good idea. •...
  • Page 5: Spa Set Up

    SPA SET UP SPA SETUP Unpacking Completely unwrap your spa and dispose of the packaging materials. Remove any tape that holds down various components within the spa. Clean any dirt or dust from the interior of your spa with a damp cloth. Remove any stubborn stains with an acrylic spa cleaner or isopropyl alcohol (concentrations under 25%).
  • Page 6: Spa Operation

    SPA OPERATION Refer to the Control Manual operating instructions for the spa-side control unit. The operating functions of your spa controller will vary depending on the model of Great Lakes Spa you have purchased. Your Great Lakes Spa comes equipped with a variety of jets and water/air controls. Some of the jets allow you to control the amount of water flow by rotating the face of the jet.
  • Page 7 1-1/2” Mini Jets A forceful, steady stream of water/air is delivered from these jets when the pump is on high or low speed. Interchangeable Jet Faces The jet faces of the various styles of 5” jets and 3” jets can be easily interchanged with others of the same size. This allows you to customize your spa massage therapy.
  • Page 8: Spa Care And Maintenance

    SPA CARE AND MAINTENANCE Draining Your Spa Under normal usage, you should change the water in your spa every 3-4 months. To drain spas equipped with the Quick Drain™ System, first turn off electrical power to your spa. Screw on either the garden hose or 1- 1/4”...
  • Page 9: Winterizing, Ozone

    WINTERIZING If you live in an area where the danger of freezing exists, you must take extra precautions to insure that your spa will operate properly. If you plan to operate your spa throughout the winter, be sure that the thermostat is set to keep the water warm. If you intend on closing down your spa for the winter, you should follow the winterizing procedures listed below: Drain the spa as explained in the "Draining Your Spa"...
  • Page 10: Water Care, Consumer Notice

    WATER CARE Your Great Lakes Spa is equipped with what we believe is the finest filtering device available. We call it the Skim/Filter system, and it is one of the few skimmers available which actually skims the water surface. When your spa is operating, watch how the Skim/Filter bobs up and down with the water level.
  • Page 11: Troubleshooting

    TROUBLESHOOTING • Equipment Module Will Not Operate • Make sure the spa control is plugged into the circuit board of the equipment module. • Check the main circuit breaker panel. If the GFCI or circuit breaker has tripped, reset the breaker. If the circuit breaker trips repeatedly, contact your dealer.
  • Page 12: Gfci Load Center Wiring

    GFCI LOAD CENTER WIRING WHITE WHITE BLACK FROM HOUSE BREAKER BOX RED (HOT) GREEN OR BARE COPPER TO HOT TUB SYSTEM BOX GFCI LOAD CENTER NOTE: The white neutral wire from the back of the GFCI MUST be connected to an incoming line neutral. The internal mechanism of the GFCI requires this neutral connection.
  • Page 13: 120 Volt To 240 Volt Wiring Conversion

    Thank You! The employees of Great Lakes Spas would like to extend their sincere thanks to you for purchasing a Great Lakes Spa. We hope that you, your family, and friends will experience many enjoyable years of fun and relaxation in your Great Lakes Spa Please fill in the following information, it will be very important should you ever have questions or concerns regarding your spa.
  • Page 14: Warranty

    TEN-YEAR STRUCTURAL WARRANTY Emerald Spa Corporation warrants (parts and labor) the spa shell against water loss due to defects in the spa shell for a period not to exceed the lesser of ten (10) years from the date of purchase or ten (10) years six (6) months from the date of manufacture.
