LABORATORY VALVES WITH WALL FLANGE
Thank you for selecting American-Standard...the benchmark of fine quality for over 100 years.
To ensure that your installation proceeds smoothly--please read these instructions carefully
before you begin.
7274.580
ROUGHING-IN DIMENSIONS
1/16"-
1-1/4"
[2mm-32mm]
WARE THICKNESS
11/16" DIA.
[17mm]
3/8" NPT MALE
THREAD INLET
1-1/4"
[2mm-32mm]
WARE THICKNESS
11/16" DIA.
[17mm]
3/8" NPT MALE
THREAD INLET
INDEX AS REQUIRED
(AIR, GAS, VAC)
2-1/8
" [54mm]
2-1/8
"
DIA. FLANGE
[54mm]
INDEX AS REQUIRED
(AIR, GAS, VAC)
2-1/8
" [54mm]
"
2-1/8
DIA. FLANGE
[54mm]
Installation Instructions
7274.585
3-1/8"
[79mm]
5-1/2"
[140mm]
3-3/4"
[95mm]
6-5/8"
[168mm]
1-7/8"
[48mm]
7274.580
7274.585
3-1/4"
[83mm]
M 9 6 8 4 9 6
