QuickSpecs
Overview
HP supports, on select HP ProLiant servers, computational accelerator modules based on NVIDIA® Tesla™ Graphical Processing Unit
(GPU) technology.
The following Tesla Modules are available from HP, for use in certain HP SL-series servers.
NVIDIA Tesla M2070Q 2-Slot Passive Module
NVIDIA Tesla M2090 2-Slot Passive Module
NVIDIA Tesla K10 Dual GPU PCIe Module
NVIDIA Tesla K10 Rev B Dual GPU Module
NVIDIA Tesla K20 5 GB Module
NVIDIA Tesla K20X 6 GB Module
The NVIDIA Tesla M2070Q module can also be used in HP ProLiant WS460c workstation blades.
Based on NVIDIA's CUDA™ architecture, the Tesla Modules enable seamless integration of GPU computing with HP ProLiant servers for
high-performance computing and large data center, scale-out deployments. These Tesla Modules deliver all of the standard benefits
of GPU computing while enabling maximum reliability and tight integration with system monitoring and management tools such as HP
Insight Cluster Management Utility.
The Tesla M2070Q uses the NVIDIA Fermi GPU architecture that combines Tesla's high performance computing - found in the other
Tesla Modules - and the NVIDIA Quadro® professional-class visualization in the same GPU. The Tesla M2070Q is the ideal solution for
customers who want to deploy high performance computing in addition to advanced and remote visualization in the same datacenter.
The HP GPU Ecosystem includes HP Cluster Platform specification and qualification, HP-supported GPU-aware cluster software, and
also third-party GPU-aware cluster software for NVIDIA Tesla Modules on HP ProLiant Servers. In particular, the HP Insight Cluster
Management Utility (CMU) will monitor and display GPU health sensors such as temperature. CMU will also install and provision the GPU
drivers and the CUDA software. The HP HPC Linux Value Pack includes a GPU-enhanced version of IBM Platform LSF, with the capability
of scheduling jobs based on GPU requirements. This capability is also available for HP in other popular schedulers such as Altair PBS
Professional, and Adaptive Moab.
What's New
Support for the NVIDIA Tesla K10 Rev B Dual GPU Module
NVIDIA K10
DA - 13743 North America — Version 16 — September 30, 2013
NVIDIA Tesla GPU Modules for HP ProLiant Servers
NVIDIA K20, K20X
Page 1
Advertisement
Related Manuals for HP NVIDIA Tesla M2070Q
Summary of Contents for HP NVIDIA Tesla M2070Q
- Page 1 Management Utility (CMU) will monitor and display GPU health sensors such as temperature. CMU will also install and provision the GPU drivers and the CUDA software. The HP HPC Linux Value Pack includes a GPU-enhanced version of IBM Platform LSF, with the capability of scheduling jobs based on GPU requirements.
- Page 2 A0R41A NVIDIA Tesla M2090 6 GB Computational Accelerator A0J99A NOTE: 2-slot passively cooled Tesla modules with 6 GB memory. NOTE: Please see the HP ProLiant SL250s Gen8 or SL270s Gen8 server QuickSpecs for Technical Specifications and additional information. http://h18004.www1.hp.com/products/quickspecs/14232_na/14232_na.html http://h18004.www1.hp.com/products/quickspecs/14405_na/14405_na.html...
-
Page 3: Standard Features
Even applications with heavy data-transfer requirements, such as seismic processing, can maximize the computing efficiency by transferring data to local memory before it is needed. The high speed PCIe Gen 2.0 data transfer maximizes bandwidth between the HP ProLiant server and the Tesla processors. Performance of the K10 Module... - Page 4 "Exclusive mode" enables application-exclusive access to a particular GPU. CUDA environment variables enable cluster management software such as the Platform LSF job scheduler (available as part of HP HPC Linux Value Pack) to limit the Tesla GPUs an application can use.
- Page 5 NOTE: Consult an HP Solution Architect for precise configuration rules. HP Services and Support The NVIDIA Tesla GPU Module has one year for parts exchange only or the warranty of the server or chassis it is attached to and for which it is qualified.
-
Page 6: Optional Features
Protect your business beyond warranty with HP Care Pack Services When you buy HP Options, it's also a good time to think about what level of service you may need. HP Care Pack services provide total care and support expertise with committed response choices designed to meet your IT and business need. - Page 7 Provides problem resolution support across the stack of HW, firmware, and HP and 3rd party SW. In case the issue is with 3rd party SW, HP does known issue resolution. If HP cannot solve the issue, it will contact the third-party vendor and create a problem incident on your behalf http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA3-8232ENW.pdf...
- Page 8 The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives replaced by HP due to malfunction. It does not apply to any exchange of Disk or SSD/Flash Drives that have not failed. SSD/Flash Drives that are specified by HP as consumable parts and/or that have exceeded maximum supported lifetime and/or the maximum usage limit as set forth in the manufacturer's operating manual or the technical data sheet are not eligible for the defective media retention service feature option.
- Page 9 QuickSpecs NVIDIA Tesla GPU Modules for HP ProLiant Servers Related Options HP High Performance HP Insight Cluster Management Utility 1yr 24x7 Flexible License QL803B NOTE: This part number can be used to purchase one certificate for multiple licenses Cluster Models with a single activation key.
-
Page 10: Technical Specifications
To recycle your product, please go to: http://www.hp.com/go/green or contact your nearest HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner. The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. - Page 11 Windows and Microsoft are registered trademarks of Microsoft Corp., in the U.S. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
