Summary of Contents for Oaxis XpringSurf 703 M7003
- Page 1 XpringSurf 703 7" Tablet (Model No.: M7003) User Manual...
-
Page 2: Safety Precautions
M7003 User manual Safety Precautions On Battery • Charge the battery only in temperature that ranges from 0 to 35 • Do not charge Tablet PC if the battery is found damaged or leaking. On Operation • Never subject Tablet PC to extremes of light, temperature, moisture or vibration. -
Page 3: Table Of Contents
M7003 User manual Contents SAFETY PRECAUTIONS ……………………………………… CONTENTS …………………………………………………… CHAPTER 1 BASICS ………………………………………… PARTS AND CONTROL ………………………………………………… PACKET CONTENTS……………………………………………………… POWER ON AND OFF THE DEVICE …………………………………… CHARGING THE DEVICE ……………………………………………… TRANSFERRING CONTENTS …………………………………………… STAND BY /WAKE UP MODE …………………………………………… HOME SCREEN …………………………………………………………… MAIN MENU ………………………………………………………………... - Page 4 M7003 User manual FILE EXPLORER ………………………………………………………… MANAGING THIRD PARTY APPLICATIONS ………………………… MORE APPLICATIONS ………………………………………………… CHAPTER 3 SETTINGS ……………………………………… WIRELESS & NETWORKS ……………………………………………… SOUND SETTINGS ……………………………………………………… DISPLAY SETTINGS …………………………………………………… LOCATION & SECURITY………………………………………………… APPLICATIONS…………………………………………………………… PRIVACY SETTING ……………………………………………………… STORAGE SETTINGS …………………………………………………… LANGUAGE & KEYBOARD …………………………………………… DATE&...
-
Page 5: Chapter 1 Basics
Chapter 1 Basics M7003 is a Tablet PC with touch LCD. It supports Wi-Fi function and third party software. Parts and Control 1. Power button – Press and hold for 3 seconds to turn on. 2. Volume + button – Press to decrease volume. 3. -
Page 6: Packet Contents
Chapter 1 Basics Packet Contents • 1x Tablet PC • 1x Power cable • 1x USB cable • 1x User Manual Power On and Off the Tablet PC • Power Press and hold the button for 3 seconds to turn the Tablet PC on. •... -
Page 7: Transferring Contents
Chapter 1 Basics Battery Battery Charging full Transferring Contents From Computer • The device supports USB Mass Storage Device function. • To import contents (ebooks, video, audio, photo etc) into the device, connect the device to PC via the supplied USB cable. -
Page 8: Stand By /Wake Up Mode
Chapter 1 Basics From memory card This unit supports Micro SD card up to 32 GB To insert a Memory card Insert the card correctly with the contact pin facing downwards as illustrated below. Pushing the card in, then you should hear a click when the card is seated correctly. You may damage the card and the device if Micro SD card is not inserted correctly.To remove Micro SD card, push the card once again until it clicks. -
Page 9: Home Screen
Chapter 1 Basics Home screen When the device is turned on, it will enter into the home screen. Home button B. USB connection USB debugging D. Time Display Wi-Fi connection F. Battery indicator Volume – button H. Volume + button Return button J. -
Page 10: Customizing Home Screen
Chapter 1 Basics Customizing Home screen Adding icons on homescreen You can add shortcuts, widgets or folders to home screen. , select the desired options to add to homescreen. Moving icons on the home screen Touch and hold an icon to be moved until the icon is zoomed in. -
Page 11: Main Menu
Chapter 1 Basics Main menu All application icons are on the Main menu. • On home screen, tap to show the Main menu. • Tap an icon on the Main menu to launch the desired application. Touch screen or buttons •... -
Page 12: Onscreen Keyboard
Chapter 1 Basics Scrolling • Drag your finger up and down to scroll file list. • Flick to scroll quickly. • On webpage, drag up and down to scroll around the page be care for so as not to click the link . •... -
Page 13: Switching Screen Orientation
Chapter 1 Basics Once you’ve joined a Wi-Fi network manually, it automatically connects to it whenever the network is in range. Switching Screen orientation Screen orientation can be set to vertical or horizontal via the built-in G sensor. • Settings Display Auto ... -
Page 14: Chapter 2 Getting Started
Chapter 2 Getting Started Web browser View a webpage • Main menu Browser From , tap to launch web browser. • Tap the address bar at the top of the screen. • On address bar, type the web address and tap •... - Page 15 Chapter 2 Getting Started New Window: Open a new window at browser start page. Bookmarks...
- Page 16 Chapter 2 Getting Started • Bookmarks List all bookmarks, tap a bookmark to open the webpage. Touch and hold to display the option menu for bookmark. Add Bookmark to add last visited webpage as new bookmark. • Most visited Tap to display the most visited website list. •...
-
Page 17: Watching Videos
Chapter 2 Getting Started Watching Videos Playing videos • Main menu Video On the , tap to open video player. • Drag up and down to scroll through the file list. • Tap to select a video file for playback. •... -
Page 18: Controlling Video Playback
Chapter 2 Getting Started Controlling Video Playback when playing video, tap on the screen to pop up control toolbar. Play or Pause a video Play previous/next video Fast rewind or fast forward Touch and hold Tap anywhere or drag the Skip to any point in a video playheadon the progress bar. - Page 19 Chapter 2 Getting Started Notices • If a bookmark is added, it allows you to continue playing from the bookmark when you open the video file next time. • Video player supports subtitle file, please load the subtitle file to be displayed on the current video, unless the subtitle is integrated into the video itself.
-
Page 20: Playing Music
Chapter 2 Getting Started Playing Music About music library Main menu Music From , tap to enter into music library Sorting by artist Sorting by album All songs Sorting by Playlist Return to Now playing screen... -
Page 21: Playing Songs
Chapter 2 Getting Started Playing songs 1. From Main menu, tap Music to enter music library. 2. Tap on a desired tab to enter song list. 3. Drag up and down to scroll the song list. 4. Tap the desired songs to start playing. Note: If you want to exit music mode, tap to pause, then... - Page 22 Chapter 2 Getting Started the playhead on the a song progress bar. button or use the volume buttons Adjust the volume level on the unit. Display the current song list Set shuffle mode Set Repeat mode Display a song’s lyrics Display the music playback menu add the current playing...
-
Page 23: Sound Effects
Chapter 2 Getting Started Sound effects Sound effects -On music playback interface, tap . The available options are Normal, Classical, Jazz, Pop, Rock, Bassboost, User EQ. - Customizing sound effects Sound effects User EQ , slide to increase or decrease the frequency setting. -
Page 24: Viewing Photos
Chapter 2 Getting Started Viewing photos Main menu Gallery From , tap to enter photo viewer. Thumbnail View • All photos available in the internal memory and Micro SD card will be listed in thumbnail view. • Tap on the desired photo to full screen view. •... - Page 25 Chapter 2 Getting Started to zoom in/out. to start slide show, tap on screen to stop the slide show. to use the option menu. to return to thumbnail mode. Note: • In zoom in /out mode, drag up, down, left or right to move photo.
-
Page 26: Sound Recording
Chapter 2 Getting Started Sound Recording Main menu Sound Recorder From , tap to enter sound recording mode. Recording a voice file • Press to start recording a voice file. • Press to stop recording. • Press to play back the current recorded voice file. •... -
Page 27: E-Mail
Chapter 2 Getting Started Use the recording Discard Use the “ ” or “ ”, choose “ recording Discard ” to save the voice file; choose “ ” to discard the voice file. • A recording time indicator will appear during the recording. •... - Page 28 Chapter 2 Getting Started 4. If you have set successfully, enter your name to be displayed , complete then tap to start to use the mail. Using the mailbox • In the mailbox, drag up and down to scroll the mail list. •...
-
Page 29: File Explorer
Chapter 2 Getting Started 3. Touch and hold the desired account to pop up a option menu, Delete Account then tap Notice You can set multiple mail accounts, each time you use mail, the system will automatically jump to the default account. File Explorer •... -
Page 30: Edit Menu
Chapter 2 Getting Started About the tool bar and the Edit menu • Tool bar Home -return to the home Explorer screen. Level Up - return to the previous directory. Multi - choose more than one item Editor - Copy, delete, move or rename a file or folder. Back - go to previous screen. - Page 31 Chapter 2 Getting Started Copy / move files or folders From the file list, select the desired files/folders to be copied or moved. Editor Move Copy to show the edit menu, select Go to the target folder that you want to put the selected file or folder.
-
Page 32: Managing Third Party Applications
Chapter 2 Getting Started Note: if only copy/move/delete one file/folder, you can touch and hold on the desired file or folder, then follow the above steps to do. Managing third party applications This unit support third party applications (such as MSN, etc.), you can install or uninstall applications for the system. -
Page 33: More Applications
Chapter 2 Getting Started More Applications Alarms Main menu Clock From , tap to enter clock alarm setting screen. Set an alarm: Add alarm 1. On alarm setting screen, tap to start to alarm setting. Note: You can set multiple alarms. 2. - Page 34 Chapter 2 Getting Started Change settings for an alarm: tap on the time of the desired alarm to be changed. Delete an alarm: Alarm to enter into Alarm setting screen, Delete then tap the button at the bottom of the screen. Calculator Using the Calculator Tap numbers and functions in Calculator just as you would with a...
-
Page 35: Chapter 3 Settings
Chapter 3 Settings Settings From Main menu, choose , then tap the desired items to be configured to start Setting. Wireless & networks The Wi-Fi setting allows you manage networks, such as turn Wi-Fi on and join Wi-Fi networks. Turn on Wi-Fi: Wi-Fi Tap on to turn Wi-Fi on. -
Page 36: Display Settings
Chapter 3 Settings Display Settings Customize the display settings. The available options: Brightness - to adjust the brightness for the display. Auto-rotate screen - select to switch the view orientation Animation - all window animation are shown. Screen timeout - adjust the delay before the display screen automatically turns off. -
Page 37: Date& Time
Chapter 3 Settings Date& Time Set date, time, time zone and display format. Touch Panel Calibration Do touch screen calibration. Use your finger to carefully touch and hold on the center of target briefly. Repeat as the target around the screen to calibrate touch screen. About the device Display the information about M7003, such as product status, legal information, model number, firmware version, Build number... -
Page 38: Chapter 4 Troubleshooting
Chapter 4 Troubleshooting If the device does not function as it is expected, please try the following steps. The device is not responding or can’t be turned on. • Reset the device by pressing the reset button at the bottom. The device will be forced shutdown if it is on and you are required to restart the device again. -
Page 39: Chapter 5 Appendix
Chapter 5 Appendix Maintenance • If Tablet PC does get wet, turn off Tablet PC immediately. Wait for Tablet PC to dry completely before turning on again. • Clean the screen with a soft cloth; be careful not to wipe it with anything abrasive. -
Page 40: Battery Life
Chapter 5 Appendix Media File Format supported Ebook: txt,pdf,epub,pdb,fb2,html,rtf,chm Audio: mp3, wma, wav, aac, ogg, flac, ape, ogg Photo: jpg, bmp, gif, png Video: rm/rmvb, avi, mkv (xvid/h.264), mpg, mp4, 3gp, dat, mov,rmvb,avi,avs Record : 3gpp Connectivity Data transfer: Micro USB 2.0 High Speed Audio: 3.5mm audio jack Record : Microphone Storage: Micro SD Card... -
Page 41: Certification Information
Chapter 5 Appendix Physical properties Dimension: 203 X 120 X 15.0mm (approx) Weight: 352.4 g Design and specifications are subject to change without prior ※ notice Certification information On FCC This equipment has been tested and found to comply with limits for a Class B digital device, pursuant to Part 15 of the FCC rules. -
Page 42: Copyrights And Trademark Notice
Chapter 5 Appendix technician for help. WARNING: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THE DEVICE. ANY SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT. On CE The symbol means that the unit complies with European safety and electrical interference directives. -
Page 43: Disposal And Recycling Information
Chapter 5 Appendix Disposal and Recycling Information Your Tablet PC must be disposed of properly according to local laws and regulations. Because this product contains a battery, the product must be disposed of separately from household waste. When your Tablet PC reaches its end of life, contact your local authorities to learn about recycling options.
