Lorex SG15F6584 Quick Start Manual

STEP 1
SETTING UP YOUR MONITOR FIRST
Pac kag e C on te nts
1 - 15" Flatscreen Quad Monitor
4 - Color Cameras with Sunshade Housing
4 - 57 ft Extension Cables
4 - Camera Brackets
1 - Remote Control
1 - Ethernet Cable
1 - Set Up CD Rom
1 - Power Cord
1 - Owner's Manual
1 - Quick Installation Guide
1 - BROADBAND ROUTER REQUIRED - NOT INCLUDED
2
Connect one end of the ethernet
cable to a broadband router (not
included) and the other end to the
back of the monitor.
ROUTER (NOT INCLUDED)
4
Turn the Master
Power switch ON
(located at the back
of the Monitor).
Information in this document is subject to change without notice. As our products are subject to continuous improvement, Lorex Technology and our subsidiaries reserve the right to modify product design, specifications and prices, without notice and without incurring any obligation. E&OE © 2006 LOREX. All rights reserved.
SG15F6584
Page 1
BACK OF THE MONITOR
BACK OF THE MONITOR
1
Connect Cameras to
Monitor.
Connect the first camera to the
CH1 input. Follow the same
steps to connect the other 3
cameras to the CH2, CH3, CH4
camera inputs
3
Connect one end of
the power cord to the
monitor, the other
end to an electrical
outlet.
5
View Picture Image
on Monitor.
BUS IN ESS & HOM E SECURI TY
BACK OF THE MONITOR
BACK OF THE MONITOR
www. lo rex c c tv .c o m
