Summary of Contents for H&B DRX-430

  • Page 2 Precautions IMPORTANT The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

  • Page 3: Important Safety

    • READ INSTRUCTIONS - All the safety and operating instructions should be read before the product is operated. • RETAIN INSTRUCTIONS - The safety and operating instructions should be retained for future reference. • HEED WARNINGS - All warnings on the product and in the operating instructions should be adhered to.

  • Page 4: Table Of Contents

    Table of Contents Before You Start What's in the box ... 5 Putting the batteries in the remote control ... 5 Using the remote control ... 5 Compatible Discs ... 6 Controls & Display Front Panel ... 7 Display ... 8 Rear Panel ...

  • Page 5: Before You Start

    What's in the box Thank you for buying this product. Please confirm that the following accessories are in the box when you open it. Accessories Scart cable Remote control AA dry cell batteries x 2 RF cable Operating instruction Audio/Video cable (this manual) Putting the batteries in the remote control...

  • Page 6: Compatible Discs

    All DVD Video discs carry a region mark on the case somewhere that indicates which region of the world the disc is compatible with. Your DVD player also has a region mark, which you can find on the rear panel.

  • Page 7: Controls & Display

    Front Panel DISC TRAY Put a disc to be played in here. OPEN/CLOSE To open or close the disc tray. PLAY/PAUSE Press to start or pause a disc playing. STOP Press to stop a disc playing. RECORD Press to start a disc recording. FL DISPLAY Displays operation status.

  • Page 8: Display

    Controls & Display Display TIMER Recording Indicator Illuminates when timer recording is on. ANGLE Indicates the current disc being played is viewed as multi angle. This function only works for discs having scenes recorded at different angles. DOLBY DIGITAL Indicator Indicates Dolby Digital 5.1CH playback.

  • Page 9: Rear Panel

    Connect to external antenna. ANT OUT Connect to Antenna Input of TV. EURO AV OUT Connect to Euro AV input of TV. EURO AV IN/OUT Connect to Euro AV in/out of AV equipment such as VCR, DVD player, etc. Controls & Display...

  • Page 10: Remote Controller Unit

    Controls & Display Remote Controller Unit Controls & Display To repeat a certain section. ANGLE To view with a different frame angle. ARROW ( To select a menu item. AUDIO To select the audio language when playing a DVD disc. AV IN To select an external audio and video input to use for recording.
  • Page 11 EDIT-DISC To edit a disc : Rename disc, Erase disc, Overwrite disc. EDIT-TITLE To edit a title : Insert chapter, Remove chapter, Hide chapter. ENTER Used to select the menu item. FWD ( Press for fast forward scanning during playback. GOTO To move to a specific time in a track or title.
  • Page 12 Controls & Display SETUP To change the initial settings. SLOW To play the disc contnts in slow forward. STANDBY/ON ( ) Activates the unit POWER ON or into STANDBY. STOP ( ) To stop a disc playing. SUBTITLE To select the subtitle language. TIMER REC To set a timer recording.

  • Page 13: Connection

    Connection for Video Output Terminals Composite Video (CVBS) Output The composite video output is supported by most televisions. The composite video jack on TV is usually yellow and may be labeled video, CVBS, composite. EURO AV Output The Euro AV terminal can be connected to TV equipped with Euro AV connector. The audio transmitted on the Euro AV is stereo sound.

  • Page 14: Connection For Audio Output Terminals

    From the Digital Audio Output menu, select “RAW” or “LPCM” according to your decoder. Connection for A/V Input Terminals You can record programs from AV system such as VCR, DVD player, Camcorder, etc. Audio Input Connect the Audio Input to the Audio Output of AV system.

  • Page 15: Basic Playback

    Playing a DVD or VCD disc Press POWER button to turn on your DVD Recorder. Press OPEN/CLOSE button to open the disc tray. Put a disc on the disc tray with logo-printed side up. Press OPEN/CLOSE button again to close the disc tray. The DVDR will load the disc automatically.

  • Page 16: Playing A Picture Cd

    Basic Playback Playing a Picture CD Load a Picture CD. The JPEG file is played in order automatically. Press MENU button to see the file list. You can see 9 thumbnail pictures on TV screen. Select the desired picture by using button.

  • Page 17: Playing Mpeg4 Movie

    Playing MPEG4 Movie Load a MPEG4 disc. Press Enter button after selecting the desired movie using button. NOTE • Some of MPEG4 movie could not be played depending on encoding method. Basic Playback Basic Playback...

  • Page 18: Advanced Playback

    Advanced Playback Fast Forward/Backward Use this function to play the DISC contents in fast forward or fast reverse. During searching, audio will be muted (except Audio CD). Press button during play mode. Each time you press button, playback speed changes as below. Press PLAY button to resume normal playback.

  • Page 19: Program Playback (Audio Cd/Mp3)

    Program Playback (Audio CD/MP3) This feature lets you program the play order of folders, tracks on a disc. Load a Audio CD or MP3 disc. The first track is played back automatically. The track list is displayed on the TV screen. <Audio CD>...

  • Page 20: Osd (On Screen Display)

    Advanced Playback OSD (On Screen Display) You can display the playback status on TV screen as follows ; Title, Chapter number, Playing time. Press DISPLAY button during playback. Title, Chapter number, Audio language and elapsed time appear on TV screen. Press DISPLAY button again.

  • Page 21: Selecting Audio Languages (Dvd Only)

    Selecting Audio Languages (DVD only) It is possible to change the audio language to a different language from the one selected at the initial settings. This operation works only with discs on which multiple audio languages are recorded. If the loaded disc supports multiple audio languages, you can select the audio language.

  • Page 22: A-B Repeat (Dvd Only)

    Advanced Playback A-B Repeat (DVD only) Use this function to repeat playback of a selected segment. This is very useful for studying foreign languages because it repeats the selected segment until canceled. Press A-B button at the point where repeat play is to start. The starting point of your selected segment is set up.

  • Page 23: Switching The Camera Angle (Dvd Only)

    Switching the Camera Angle (DVD only) When a DVD contains recorded multiple angles of a scene, you can select the Angle function. Press ANGLE button during playing. Available angles of the current scene will be displayed on the top of screen and the angle is changed.

  • Page 24: Recording

    Recording Simple recording To record TV programs, you should search TV channels first. Load a DVD+RW or DVD+R disc with enough free space for the recording. Press AV IN button to choose the A/V input you want to record. Every time this button is pressed, A/V input is changed : If you want to record the TV program, select TV IN.

  • Page 25: Timer Recording

    Timer Recording For timer recordings, the clock, date, and stations must be set correctly. Load a DVD+RW or DVD+R disc with enough free space for the recording. Press TIMER REC button. Select an unused program by pressing button, then press ENTER button. Press ENTER button.

  • Page 26: Timer Review - Changing And Erasing Record Settings

    Recording NOTE • You can switch your DVD Recorder on again if you want to set the timer to record another program. Remember to switch the DVD Recorder off when you have finished. • To stop a timer recording which has already started, press STANDBY/ON button.

  • Page 27: Recording From A Digital Camcorder

    Recording from a digital camcorder You can record the audio and video signal from a DV camcorder via DV IN. Make sure your digital camcorder is connected to DV IN jack on the front panel. Also set the camcorder to PLAY (or VCR) mode. Load a DVD+RW or DVD+R disc with enough free space for the recording.

  • Page 28: Editing

    Editing Editing a DVD+RW or Editing a DVD+RW or DVD+R disc DVD+R disc Insert a recorded DVD+RW or DVD+R disc on the disc tray. Press EDIT-DISC button, the Disc Edit menu will show on the screen. <DVD+RW> <DVD+R> Play disc (DVD+RW/DVD+R) You can play back the entire disc from the beginning to the end.

  • Page 29: Erase Disc (Dvd+Rw Only)

    Erase disc (DVD+RW only) Press ENTER button after selecting “Erase disc” by using The pop-up menu will show on the screen. Press ENTER button to erase the contents of a disc after selecting “Yes” by using button. It takes a few minutes to erase the disc. NOTE •...

  • Page 30: Overwrite Disc (Dvd+Rw Only)

    Editing Overwrite disc (DVD+RW only) Press ENTER button after selecting “Overwrite disc” by using It will be changed from DVD mode to AV input mode. Press AV IN button to choose the A/V input you want to record. Every time this button is pressed, A/V input is changed : If you want to record the TV program, select TV IN.

  • Page 31: Finalize Disc (Dvd+R Only)

    Finalize disc (DVD+R only) If you want to make your DVD+R disc compatible with other DVD players, you should finalize the disc. Press ENTER button after selecting “Finalize disc” by using The pop-up menu will show on the screen. Press ENTER button to confirm after selecting “Yes”...

  • Page 32: Play Title (Dvd+Rw/Dvd+R)

    Editing Play title (DVD+RW/DVD+R) You can play back the selected title. Press ENTER button after selecting “Play title” by using button. It starts to play back from the selected title. Edit title (DVD+RW/DVD+R) Press ENTER button after selecting “Edit title” by using button.

  • Page 33: Rename Title (Dvd+Rw/Dvd+R)

    Rename title (DVD+RW/DVD+R) Press ENTER button after selecting “Rename title” by using The keyboard will show on the screen. Select a letter which you want to input by using button, and press ENTER button to confirm it. Repeat step 2. The maximum length of the disc name is 9 characters.

  • Page 34: Overwrite Title (Dvd+Rw Only)

    Editing Overwrite title (DVD+RW only) Press ENTER button after selecting “Overwrite title” by using It will be changed from DVD mode to AV input mode. Press AV IN button to choose the A/V input you want to record. Every time this button is pressed, A/V input is changed : If you want to record the TV program, select TV IN.

  • Page 35: Using The Setup Menu

    Once the initial settings have been completed, the DVD recorder can always be operated under the same conditions whenever the power is switched on. These settings are called SETUP data that are easily modified and stored using the SETUP menu. The SETUP menu includes the information for Playback, Record, Language, Channel Scan.

  • Page 36: Playback

    Using the Setup Menu Playback TV ASPECT RATIO If you have a widescreen TV, select the “16:9” setting. The widescreen DVD disc is shown using the full screen area. When playing the DVD disc recorded in conventional format(4:3), the settings on your TV will determine how the material is presented.

  • Page 37: Record

    Press ENTER button to confirm after selecting “OK”. A rating level change will be done. If you want to change the password, press ENTER button after selecting “NEW” in above step 3. Enter the new password in 4 digits by using 0 to 9 button.

  • Page 38: Language

    Using the Setup Menu Language OSD LANGUAGE This item is used to select the language for On-Screen Display messages that will be displayed on the TV screen. When your desired language is selected, all OSD messages are displayed in the selected language.
  • Page 39 NOTE • Performing a new channel search will erase and replace all previously stored channels. MODIFY CHANNEL INFORMATION (If there is no captured channel, this feature is not available.) Press ENTER button after selecting “Modify channel information” by pressing button. The information of the current channel will show on the screen.

  • Page 40: Clock

    Using the Setup Menu CHANNEL SWAPPING (If there is no captured channel, this feature is not available.) This feature lets you swap the channel assignments of different programs. Press ENTER button after selecting “SWAP” by pressing Select a preset station to swap using button, and press ENTER or button.

  • Page 41: Additional Information

    Specifications Supported disc types Supported video formats TV system Power requirements General Power consumption Weight Dimensions Operating temperature Operating humidity Recording format Recording Recordable discs Programs Clock Timer Power off memory AV connector input / output x 1 Euro AV connectors (21-pin connector) AV connector output x 1 Y (luminance) - Output level...

  • Page 42: Troubleshooting

    Additional Information Troubleshooting Incorrect operation is often mistaken for trouble or malfunction. If you think that there is something wrong with this component, check the points below. Sometimes the trouble may lie in another component. Inspect the other components and electrical appliances being used. If the trouble cannot be rectified after checking the items below, ask your nearest authorized service center or your dealer to carry out repair work.
  • Page 43 Problem The remote control doesn't seem to work. No audio, or audio is distorted. The analog audio is OK, but there appears to be no digital audio signal. Noticeable difference in DVD and CD volume. No DTS audio output. The disc containing the MP3 tracks won't play.

  • Page 44: Warranty And Support

    Do not spill liquids on the DVD player. If the DVD Player does not function normally, or if it emits unusual sounds or odors, pull out the plug immediately and contact an authorized technician.
  • Page 46 P/N : 72001021100...
